Isuzu WW
▶
SUV
▶
UCR
▶
51617 - UCR/S JIANGXI
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-51 - REAR DOOR GLASS AND REGULATOR
▶
6-51 — REAR DOOR GLASS AND REGULATOR
(#160440) — 18 parça
Tümü
A - UCB6VC
B - UCS6VC
2
14
1
7
14
87
7
87
11
19
18
29
28
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
GLASS; RR DOOR
8-98189-288-1
01
1
1504-
●
●
1
GLASS; RR DOOR
8-98189-289-1
01
1
1504-
●
●
2
GLASS; RR DOOR,RR
8-98189-364-0
01
1
1504-
●
●
2
GLASS; RR DOOR,RR
8-98189-365-0
01
1
1504-
●
●
7
CHANNEL; GLASS RUN,RR DOOR
UPR
8-98202-651-1
01
1
1504-
●
●
7
CHANNEL; GLASS RUN,RR DOOR
UPR
8-98202-652-1
01
1
1504-
●
●
7
CHANNEL; GLASS RUN,RR DOOR
LWR
8-98203-623-0
01
1
1504-
●
●
7
CHANNEL; GLASS RUN,RR DOOR
LWR
8-98203-624-0
01
1
1504-
●
●
11
BOLT; GLASS
M6X10 FLANGE
8-98188-381-0
04
1
1504-
●
●
14
BOLT; RR DOOR GLASS
(A) M4X8 TAPPING
0-71240-408-0
02
1
1504-
●
●
14
BOLT; RR DOOR GLASS
(B) M6X8 FLANGE
8-98048-996-0
02
1
1504-
●
●
18
REGULATOR; WINDOW,RR DOOR
8-98211-011-1
01
1
1504-
●
●
18
REGULATOR; WINDOW,RR DOOR
8-98211-013-1
01
1
1504-
●
●
19
MOTOR; POWER WINDOW REG,RR DOOR
8-98167-091-1
01
1
1504-
●
●
19
MOTOR; POWER WINDOW REG,RR DOOR
8-98167-092-1
01
1
1504-
●
●
28
BOLT; WINDOW REG
M6X10 FLANGE
8-98188-381-0
06
1
1504-
●
●
29
SCREW; WINDOW REG
8-98195-236-0
06
1
1504-
●
●
87
NUT; WINDOW
M6 FLANGE
8-98049-362-0
04
1
1504-
●
●
