Isuzu WW
▶
TRUCKS
▶
CYJ
▶
11678 - CYJ RHD EURO5
▶
0 - Engine, Emission, Engine Electrical
▶
0-31 - THERMOSTAT AND HOUSING
▶
0-31 — THERMOSTAT AND HOUSING
(#160177) — 15 parça
Tümü
A - 6WG1 TC-N
B - 6WG1 TC-C
C - 6WG1 TC-S
12
66
14
12
2
66
20
1
82
82
60
50
50
60
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
THERMOSTAT
82 CELSIUS
8-98271-161-0
02
1
1504-1509
●
●
1
THERMOSTAT
82 CELSIUS
8-98319-254-0
02
1
1510-
●
●
1
THERMOSTAT
79 CELSIUS
1-13770-041-2
02
1
1504-
●
2
HOUSING; THERMOSTAT
8-98223-082-0
01
1
1504-
●
●
●
12
BOLT; HSG
M10X25 FLANGE
0-28151-025-0
05
1
1504-
●
●
●
14
PLUG; SW
PT3/8
8-94475-259-0
01
1
1504-
●
●
●
20
RING; SEAL
ID=59 OD=66.1
1-13779-011-0
02
1
1504-
●
●
●
50
BOLT; OUTLET PIPE
(A) M10X90 FLANGE
0-28151-090-0
04
1
1504-
●
●
●
50
BOLT; OUTLET PIPE
(B) M10X55 FLANGE
8-97365-449-0
02
1
1504-
●
●
●
60
GASKET; OUTLET PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=55.6
1-09623-452-0
01
1
1504-
●
●
●
60
GASKET; OUTLET PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=62.6
1-09623-505-0
01
1
1504-
●
●
●
66
GASKET; THERMOSTAT HSG
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)
1-13743-036-1
01
1
1504-
●
●
●
66
GASKET; THERMOSTAT HSG
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A)
8-98205-844-0
01
1
1504-
●
●
●
82
PIPE; WATER,HTR
(A)
8-98134-083-0
01
1
1504-
●
●
●
82
PIPE; WATER,HTR
(B)
8-98202-983-1
01
1
1504-
●
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
