1 |
LEVER ASM; PTO & DUMP CONT
DUMP CONTROL LEVER<RC4>
|
1-38300-100-6 |
01 |
1 |
9207- |
● |
|
| |
3 |
BOLT; BRKT,DUMP CONT LEVER
DUMP CONTROL LEVER<RC4>
M6X16 W/LK&PL WASHER
|
0-50140-616-0 |
04 |
1 |
9207- |
● |
|
| |
21 |
WASHER; PL,CONT LEVER
DUMP CONTROL LEVER<RC4>
ID=8.4
|
9-09160-508-0 |
01 |
1 |
9207- |
● |
|
| |
36 |
BOLT; PTO BRKT
TRANSMISSION FRONT PTO<RC2>
M10X32 W/LK WASHER
|
1-09029-001-1 |
01 |
1 |
9207- |
● |
|
| |
37 |
WASHER; PL,PTO BRKT
TRANSMISSION FRONT PTO<RC2>
ID=10.5
|
9-09164-510-0 |
01 |
1 |
9207- |
● |
|
| |
44 |
NUT; BRKT
TRANSMISSION FRONT PTO<RC2>
M10
|
9-09110-510-0 |
01 |
1 |
9207- |
● |
|
| |
46 |
BRACKET; PTO,TRANS SIDE
TRANSMISSION FRONT PTO<RC2>
|
1-38329-049-0 |
01 |
1 |
9207- |
● |
|
| |
47 |
GASKET; FLEX HOSE
PTO CONTROL<SV6>
ID=11 OD=18
|
9-09572-510-0 |
02 |
1 |
9207- |
● |
● |
| |
48 |
HOSE; FLEX,PTO
TRANSMISSION FRONT PTO<RC2>
(A)
L=570
|
0-07150-570-0 |
01 |
1 |
9207- |
● |
|
| |
48 |
HOSE; FLEX,PTO
TRANSMISSION SIDE PTO WO/LEVER(SH5)
PTO CONTROL<SV6>
(B)
L=360
|
0-07150-360-0 |
01 |
1 |
9207- |
● |
● |
| |
56 |
PATCH; DUMP CONT BRKT
DUMP CONTROL LEVER<RC4>
|
1-79998-219-0 |
01 |
1 |
9207- |
● |
|
| |
93 |
NUT; BRKT FIX
TRANSMISSION FRONT PTO<RC2>
M10
|
9-09110-410-0 |
02 |
1 |
9207- |
● |
|
| |
94 |
BRACKET; SELECT,TRANS CONT
TRANSMISSION FRONT PTO<RC2>
|
1-33657-356-1 |
01 |
1 |
9207- |
● |
|
| |
95 |
BRACKET; SHIFT,TRANS CONT
TRANSMISSION FRONT PTO<RC2>
|
1-33657-415-0 |
01 |
1 |
9207- |
● |
|
| |
96 |
NUT
TRANSMISSION FRONT PTO<RC2>
M12 FLANGE
|
0-91150-212-0 |
02 |
1 |
9207- |
● |
|
| |
98 |
BOLT; BRKT FIX
TRANSMISSION FRONT PTO<RC2>
M10X20 FLANGE
|
0-28081-020-0 |
01 |
1 |
9207- |
● |
|
| |
98 |
BOLT; BRKT FIX
TRANSMISSION FRONT PTO<RC2>
M10X25 FLANGE
|
0-28081-025-0 |
01 |
1 |
9207- |
● |
|
| |
117 |
CYLINDER ASM; AIR
TRANSMISSION FRONT PTO<RC2>
|
1-38370-002-0 |
01 |
1 |
9207- |
● |
|
| |
118 |
PIN; PLATE
TRANSMISSION FRONT PTO<RC2>
|
9-08213-620-0 |
02 |
1 |
9207- |
● |
|
| |
119 |
PLATE; FRT PTO,CONT LEVER
TRANSMISSION FRONT PTO<RC2>
|
1-38379-011-0 |
02 |
1 |
9207- |
● |
|
| |
120 |
WASHER; PL,PLATE
TRANSMISSION FRONT PTO<RC2>
ID=6.4
|
9-09160-506-0 |
02 |
1 |
9207- |
● |
|
| |
121 |
RING; SNAP
TRANSMISSION FRONT PTO<RC2>
ID=4
|
9-09185-404-0 |
02 |
1 |
9207- |
● |
|
| |
122 |
BOLT; PLATE
TRANSMISSION FRONT PTO<RC2>
|
9-01051-060-0 |
02 |
1 |
9207- |
● |
|
| |
123 |
BRACKET; WITH BOLT
TRANSMISSION FRONT PTO<RC2>
|
1-38379-009-0 |
01 |
1 |
9207- |
● |
|
| |
124 |
NUT; PLATE
TRANSMISSION FRONT PTO<RC2>
M10
|
9-09110-410-0 |
04 |
1 |
9207- |
● |
|
| |
125 |
WASHER; LK,PLATE
TRANSMISSION FRONT PTO<RC2>
ID=10.2
|
9-09150-510-0 |
04 |
1 |
9207- |
● |
|
| |
126 |
PLATE; AIR CYL
TRANSMISSION FRONT PTO<RC2>
|
1-38379-019-0 |
01 |
1 |
9207- |
● |
|
| |
127 |
CYLINDER; AIR
TRANSMISSION FRONT PTO<RC2>
|
1-38377-004-0 |
01 |
1 |
9207- |
● |
|
| |
128 |
WASHER; LK,PLATE
TRANSMISSION FRONT PTO<RC2>
ID=10.5 OD=18
|
9-09160-510-0 |
02 |
1 |
9207- |
● |
|
| |
129 |
NIPPLE; AIR CYL
TRANSMISSION FRONT PTO<RC2>
|
1-38379-012-0 |
01 |
1 |
9207- |
● |
|
| |
176 |
WASHER; LK,BRKT
TRANSMISSION FRONT PTO<RC2>
ID=10.2
|
9-09150-510-0 |
02 |
1 |
9207- |
● |
|
| |
186 |
BRACKET; SHIFT,SELECT BASE
TRANSMISSION FRONT PTO<RC2>
|
1-33657-397-2 |
01 |
1 |
9207- |
● |
|
| |
214 |
RING; SNAP,LK BOLT
DUMP CONTROL LEVER<RC4>
(B)
ID=6
|
9-09185-406-0 |
01 |
1 |
9207- |
● |
|
| |
214 |
RING; SNAP,LK BOLT
DUMP CONTROL LEVER<RC4>
(A)
ID=8
|
9-09185-408-0 |
01 |
1 |
9207- |
● |
|
