◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FTS ▶ 11311 - FTS(MIDDLE EAST) ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#15935) — 13 parça
çizim 15427
69 4 6 6
BalonParca AdiParca NoAdetTipApplied Date A B
4 LABEL; ENG MAINTENANCE 8-94395-931-0 01 1 9905- ● ●
6 PLATE; CAUTION,SPARE TIRE
SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> (A) 		1-85883-114-0 01 1 9905-0708 ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> (A) 		1-85883-114-0 01 1 9905-0708 ●
6 PLATE; CAUTION,SPARE TIRE
SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> (B) 		8-98082-441-0 01 1 0709- ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> (B) 		8-98082-441-0 01 1 0709- ●
69 PLATE; CAUTION,STARTER SW 1-85887-537-0 01 1 9905-0302 ● ●
69 PLATE; CAUTION,STARTER SW
EXC. STARTER SWITCH DELETION<E5D> 		1-85887-537-0 01 1 0303- ● ●
çizim 64559
51 49 51 60
BalonParca AdiParca NoAdetTipApplied Date A B
49 PLATE; CAUTION,FUSE BOX 1-85878-224-0 01 1 9905- ● ●
51 PLATE; CAUTION,WARNING
(B) 		1-85878-225-0 01 1 9905- ● ●
51 PLATE; CAUTION,WARNING
(A) 		1-85880-707-1 01 1 9905-9905 ● ●
51 PLATE; CAUTION,WARNING
(A) 		1-85880-709-1 01 1 9906- ● ●
60 PLATE; CAUTION,CAB TILT 1-85883-169-0 01 1 9905-9905 ● ●
60 PLATE; CAUTION,CAB TILT 1-85883-172-0 01 1 9906- ● ●
