2 |
04.166 RING; RET,FRT BRK,2ND BRK,A/T
ID=148
|
8-98189-627-0 |
01 |
1 |
1409- |
| |
4 |
04.163 DISC ASM; CLU & FACING,2ND BRK,A
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-625-0 |
04 |
1 |
1412- |
| |
4 |
04.163 DISC ASM; CLU & FACING,2ND BRK,A
|
8-98189-625-0 |
04 |
1 |
1409-1411 |
| |
4 |
04.163 DISC ASM; CLU & FACING,2ND BRK,A
4JK1-TCX ENG(LR0)
|
8-98189-625-0 |
03 |
1 |
1412- |
| |
8 |
04.166 SPRING; RETURN,FRT BRK,A/T
4JK1-TCX ENG(LR0)
|
8-98189-769-0 |
01 |
1 |
1412- |
| |
8 |
04.166 SPRING; RETURN,FRT BRK,A/T
|
8-98189-622-0 |
01 |
1 |
1409-1411 |
| |
8 |
04.166 SPRING; RETURN,FRT BRK,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-622-0 |
01 |
1 |
1412- |
| |
10 |
04.166 PISTON; BRK,FRT,2ND BRK,A/T
4JK1-TCX ENG(LR0)
|
8-98189-768-0 |
01 |
1 |
1412- |
| |
10 |
04.166 PISTON; BRK,FRT,2ND BRK,A/T
|
8-98189-618-0 |
01 |
1 |
1409-1411 |
| |
10 |
04.166 PISTON; BRK,FRT,2ND BRK,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-618-0 |
01 |
1 |
1412- |
| |
11 |
04.166 GASKET; BRK PISTON,FRT,INNER,A/T
ID=117
|
8-98189-621-0 |
01 |
1 |
1409- |
| |
15 |
04.166 PLATE; BRK CUSHION,A/T
|
8-98189-635-0 |
01 |
1 |
1409- |
| |
18 |
04.166 PISTON; LOW & REV BRK,A/T
|
8-98189-644-0 |
01 |
1 |
1409- |
| |
20 |
04.166 SLEEVE; BRK REACTION,A/T
|
8-98189-652-0 |
01 |
1 |
1409- |
| |
22 |
04.166 GASKET; BRK PISTON,RR,INNER,A/T
ID=67
|
8-98189-645-0 |
01 |
1 |
1409- |
| |
23 |
04.166 GASKET; BRK PISTON,RR,OUTER,A/T
ID=116
|
8-98189-646-0 |
01 |
1 |
1409- |
| |
26 |
04.166 GASKET; BRK PISTON,FRT,OUTER,A/T
ID=137
|
8-98189-620-0 |
01 |
1 |
1409- |
| |
27 |
04.166 PISTON; BRK,RR,2ND BRK,A/T
|
8-98189-629-0 |
01 |
1 |
1409- |
| |
31 |
04.163 PLATE; CLU BACKING,2ND BRK,A/T
T=2.0
|
8-98189-626-0 |
03 |
1 |
1409- |
| |
42 |
04.265 RACE; THRUST BRG,A/T
|
8-98189-614-0 |
01 |
1 |
1409- |
| |
44 |
04.265 RING; RET
04.485
(A)
ID=160
|
8-97184-521-0 |
01 |
1 |
1409- |
| |
44 |
04.265 RING; RET
(B)
ID=162
|
8-98189-637-0 |
01 |
1 |
1409- |
| |
44 |
04.265 RING; RET
(C)
ID=61
|
8-98189-655-0 |
01 |
1 |
1409- |
| |
46 |
04.166 PISTON; BRK
4JK1-TCX ENG(LR0)
(A)
|
8-98189-767-0 |
01 |
1 |
1412- |
| |
46 |
04.166 PISTON; BRK
(A)
|
8-98189-600-0 |
01 |
1 |
1409-1411 |
| |
46 |
04.166 PISTON; BRK
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
(A)
|
8-98189-600-0 |
01 |
1 |
1412- |
| |
46 |
04.166 PISTON; BRK
(B)
|
8-98189-643-0 |
01 |
1 |
1409- |
| |
47 |
04.166 CYLINDER; BRK
(A)
|
8-98189-601-0 |
01 |
1 |
1409- |
| |
47 |
04.166 CYLINDER; BRK
(B)
|
8-98189-630-0 |
01 |
1 |
1409- |
| |
48 |
04.166 GASKET; BRK
(A)
ID=143
|
8-98189-604-0 |
01 |
1 |
1409- |
| |
48 |
04.166 GASKET; BRK
(B)
ID=149
|
8-98189-631-0 |
01 |
1 |
1409- |
| |
48 |
04.166 GASKET; BRK
(C)
ID=128
|
8-98189-649-0 |
01 |
1 |
1409- |
| |
48 |
04.166 GASKET; BRK
(D)
ID=132
|
8-98189-650-0 |
01 |
1 |
1409- |
| |
49 |
04.166 GASKET; BRK PISTON
(A)
ID=127
|
8-98189-605-0 |
01 |
1 |
1409- |
| |
49 |
04.166 GASKET; BRK PISTON
(B)
ID=137
|
8-98189-620-0 |
01 |
1 |
1409- |
| |
49 |
04.166 GASKET; BRK PISTON
(C)
ID=79
|
8-98189-647-0 |
01 |
1 |
1409- |
| |
50 |
04.166 SPRING; BRK PISTON RETURN
|
8-98189-606-0 |
01 |
1 |
1409- |
| |
51 |
04.163 DISC; BRK
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
(A)
OD=158
|
8-98189-607-0 |
04 |
1 |
1412- |
| |
51 |
04.163 DISC; BRK
(A)
OD=158
|
8-98189-607-0 |
04 |
1 |
1409-1411 |
| |
51 |
04.163 DISC; BRK
4JK1-TCX ENG(LR0)
(A)
OD=158
|
8-98189-607-0 |
03 |
1 |
1412- |
| |
51 |
04.163 DISC; BRK
(B)
OD=140
|
8-98189-656-0 |
08 |
1 |
1409- |
| |
52 |
04.166 PLATE; BRAKE
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
(A)
T=2.4
|
8-98189-608-0 |
04 |
1 |
1412- |
| |
52 |
04.166 PLATE; BRAKE
(A)
T=2.4
|
8-98189-608-0 |
04 |
1 |
1409-1411 |
| |
52 |
04.166 PLATE; BRAKE
4JK1-TCX ENG(LR0)
(A)
T=2.4
|
8-98189-608-0 |
03 |
1 |
1412- |
| |
52 |
04.166 PLATE; BRAKE
(B)
ID=125
|
8-98189-657-0 |
07 |
1 |
1409- |
| |
53 |
04.166 FLANGE; BRAKE
(A)
T=2.0
|
8-98189-609-0 |
AR |
1 |
1409- |
| |
53 |
04.166 FLANGE; BRAKE
(A)
T=2.2
|
8-98189-610-0 |
AR |
1 |
1409- |
| |
53 |
04.166 FLANGE; BRAKE
(A)
T=2.4
|
8-98189-611-0 |
AR |
1 |
1409- |
| |
53 |
04.166 FLANGE; BRAKE
(A)
T=2.6
|
8-98189-612-0 |
AR |
1 |
1409- |
| |
53 |
04.166 FLANGE; BRAKE
(B)
T=9.0
|
8-98189-658-0 |
01 |
1 |
1409- |
| |
54 |
04.163 CLUTCH ASM; 1WAY
|
8-98189-613-0 |
01 |
1 |
1409- |
| |
55 |
04.162 WASHER; THRUST
(A)
|
8-98189-615-0 |
01 |
1 |
1409- |
| |
55 |
04.162 WASHER; THRUST
(B)
|
8-98189-640-0 |
01 |
1 |
1409- |
| |
56 |
04.166 CYLINDER; BRAKE
|
8-98189-619-0 |
01 |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(B)
T=2.3
|
8-98189-623-0 |
01 |
1 |
1409-1411 |
| |
57 |
04.166 FLANGE; BRAKE
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
(B)
T=2.3
|
8-98189-623-0 |
01 |
1 |
1412- |
| |
57 |
04.166 FLANGE; BRAKE
(C)
T=4.6
|
8-98189-624-0 |
01 |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=1.8
|
8-98189-659-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=1.97
|
8-98189-660-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.11
|
8-98189-661-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.25
|
8-98189-662-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.39
|
8-98189-663-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.53
|
8-98189-664-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.67
|
8-98189-665-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.81
|
8-98189-666-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=2.95
|
8-98189-667-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=3.09
|
8-98189-668-0 |
AR |
1 |
1409- |
| |
57 |
04.166 FLANGE; BRAKE
(A)
T=3.23
|
8-98189-669-0 |
AR |
1 |
1409- |
| |
58 |
04.163 CLUTCH ASM; 1WAY
|
8-98189-639-0 |
01 |
1 |
1409- |
| |
59 |
04.166 FLANGE; BRAKE NO3
|
8-98189-636-0 |
01 |
1 |
1409- |
| |
60 |
04.163 DISC ASM; BRAKE
|
8-98189-634-0 |
01 |
1 |
1409- |
| |
61 |
04.166 RING; SNAP,BRK
(A)
ID=125
|
8-98189-632-0 |
01 |
1 |
1409- |
| |
61 |
04.166 RING; SNAP,BRK
(B)
ID=173
|
8-98189-633-0 |
01 |
1 |
1409- |
| |
62 |
04.166 SPRING; BRK PISTON
|
8-98189-628-0 |
01 |
1 |
1409- |
| |
63 |
04.166 SPRING; 1ST & REVS BRAKE RETURN
|
8-98189-654-0 |
01 |
1 |
1409- |
