12 |
NUT; UNION
EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO
WO/LEVER(SH5)
M12
|
0-91111-512-0 |
01 |
1 |
1411- |
| |
35 |
NUT; BRKT
EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO
WO/LEVER(SH5)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1411- |
| |
80 |
UNION; 3 WAY
ZF9S1110 M/T(Y5E)
H.S.A SYSTEM<6EP>
RIGID SEAT WO/ARM REST<TAZ>
EXC. PTO ZF TRANS RR(BDM)
M12 & PT1/4 3WAY
|
1-09656-586-1 |
01 |
1 |
1411- |
| |
80 |
UNION; 3 WAY
ZF9S1110 M/T(Y5E)
AIR SUSP DRIVER SEAT<A56>
EXC. PTO ZF TRANS RR(BDM)
M12 & PT1/4 3WAY
|
1-09656-586-1 |
01 |
1 |
1411- |
| |
123 |
BRACKET; UNION
EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO
WO/LEVER(SH5)
|
8-98118-545-0 |
01 |
1 |
1411- |
| |
202 |
ADAPTER
ZF9S1110 M/T(Y5E)
H.S.A SYSTEM<6EP>
RIGID SEAT WO/ARM REST<TAZ>
EXC. PTO ZF TRANS RR(BDM)
DIN6 & M12 STRAIGHT
|
1-09661-379-0 |
01 |
1 |
1411- |
| |
202 |
ADAPTER
ZF9S1110 M/T(Y5E)
AIR SUSP DRIVER SEAT<A56>
EXC. PTO ZF TRANS RR(BDM)
DIN6 & M12 STRAIGHT
|
1-09661-379-0 |
01 |
1 |
1411- |
| |
221 |
BOLT; BRKT
EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO
WO/LEVER(SH5)
M8X35 FLANGE
|
0-28650-835-0 |
02 |
1 |
1411- |
| |
229 |
ADAPTER; NYLON TUBE
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
DIN8 & M12 STRAIGHT
|
1-09660-873-0 |
01 |
1 |
1411- |
| |
258 |
CONNECTOR; NYLON TUBE
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
DIN8X2 & PT1/4 DOUBLE ELBOW
|
8-98179-708-0 |
01 |
1 |
1411- |
| |
296 |
TUBE; NYLON
SERVICED BY L=2000 OD=6
|
1-87411-001-0 |
AR |
1 |
1411- |
| |
296 |
TUBE; NYLON
SERVICED BY L=2000 OD=8
|
1-87411-006-0 |
AR |
1 |
1411- |
| |
296 |
TUBE; NYLON
SERVICED BY L=4000 OD=8
|
1-87411-007-0 |
AR |
1 |
1411- |
| |
296 |
TUBE; NYLON
SERVICED BY L=6000 OD=8
|
1-87411-008-0 |
AR |
1 |
1411- |
| |
296 |
TUBE; NYLON
SERVICED BY L=2000 OD=12
|
1-87411-011-0 |
AR |
1 |
1411- |
| |
305 |
UNION ASM; NYLON TUBE
EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO
WO/LEVER(SH5)
M12 & RC1/4X2 2WAY
|
8-98120-049-0 |
01 |
1 |
1411- |
| |
367 |
TUBE; CORRUGATE
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
SERVICED BY L=2000 ID=10
|
1-87411-019-0 |
01 |
1 |
1411- |
| |
374 |
CONNECTOR
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
H.S.A SYSTEM<6EP>
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
(C)
DIN6 & R1/4 ELBOW
|
1-09661-067-0 |
01 |
1 |
1411- |
| |
374 |
CONNECTOR
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
AIR SUSP DRIVER SEAT<A56>
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5),H.S.A
SYSTEM<6EP>
(C)
DIN6 & R1/4 ELBOW
|
1-09661-067-0 |
01 |
1 |
1411- |
| |
374 |
CONNECTOR
ZF9S1110 M/T(Y5E)
EXC. PTO ZF TRANS RR(BDM)
(A)
M12 & PT1/4 ELBOW
|
1-09650-430-0 |
01 |
1 |
1411- |
| |
374 |
CONNECTOR
ZF9S1110 M/T(Y5E)
EXC. PTO ZF TRANS RR(BDM)
(B)
DIN8 & R1/4 ELBOW
|
1-09660-956-0 |
01 |
1 |
1411- |
| |
434 |
CLIP
AIR SUSP DRIVER SEAT<A56>
(B)
ID=7 L=20
|
0-95234-635-0 |
01 |
1 |
1411- |
| |
434 |
CLIP
(A)
ID=16 L=20
|
0-95235-536-0 |
02 |
1 |
1411- |
| |
435 |
BOLT; CLIP
AIR SUSP DRIVER SEAT<A56>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1411- |
| |
435 |
BOLT; CLIP
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1411- |
| |
436 |
NUT; CLIP
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1411- |
| |
436 |
NUT; CLIP
AIR SUSP DRIVER SEAT<A56>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1411- |
| |
465 |
PLUG
MZW6P M/T(RSZ),FULLER FSO5206B OD M/T(Y4V)
RIGID SEAT WO/ARM REST<TAZ>
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5),H.S.A
SYSTEM<6EP>
PT1/4
|
9-99204-513-0 |
01 |
1 |
1411- |
