Isuzu WW
▶
PICKUP
▶
TFR
▶
51579 - TFR/TFS THAILAND
▶
2 - Clutch, Transmission, Trans Axle
▶
2-06 - CLUTCH SLAVE CYLINDER
▶
2-06 — CLUTCH SLAVE CYLINDER
(#148267) — 27 parça
Tümü
A - 4JK1-TCS ENG
B - 4JK1-TCX ENG
C - 4JJ1-TCX ENG
◀
[206A] M/T MUA;4X4 (9 parça)
[206A] M/T MUX (9 parça)
[206A] M/T MUA;4X2 (9 parça)
▶
1
1
3
5
7
8
2
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
CYLINDER; SLAVE,CLU
4X2<TFB***> M/T MUA 5 SPEED 5H<MWQ> (A) THA
8-97945-177-0
01
1
1409-
●
●
●
1
CYLINDER; SLAVE,CLU
M/T MUX 5 SPEED 5S<MZJ> (C) THA
8-97946-624-2
01
1
1409-
●
1
CYLINDER; SLAVE,CLU
4X4<TFS***> M/T MUA 5 SPEED 5H<MWQ> (B) THA
8-97946-625-1
01
1
1409-
●
●
●
2
REPAIR KIT; CLU SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
5-87832-048-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ> THA
8-97945-722-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUX 5 SPEED 5S<MZJ> THA
8-98187-063-0
01
1
1409-
●
5
SPRING ASM; PISTON,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
8-97942-801-0
01
1
1409-
●
●
●
7
SCREW; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> M8X10 IMA
8-98020-477-0
01
1
1409-
●
●
●
8
CAP; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> OD=10 IMA
8-97940-638-0
01
1
1409-
●
●
●
5
3
1
2
8
7
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
CYLINDER; SLAVE,CLU
4X2<TFB***> M/T MUA 5 SPEED 5H<MWQ> (A) THA
8-97945-177-0
01
1
1409-
●
●
●
1
CYLINDER; SLAVE,CLU
M/T MUX 5 SPEED 5S<MZJ> (C) THA
8-97946-624-2
01
1
1409-
●
1
CYLINDER; SLAVE,CLU
4X4<TFS***> M/T MUA 5 SPEED 5H<MWQ> (B) THA
8-97946-625-1
01
1
1409-
●
●
●
2
REPAIR KIT; CLU SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
5-87832-048-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ> THA
8-97945-722-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUX 5 SPEED 5S<MZJ> THA
8-98187-063-0
01
1
1409-
●
5
SPRING ASM; PISTON,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
8-97942-801-0
01
1
1409-
●
●
●
7
SCREW; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> M8X10 IMA
8-98020-477-0
01
1
1409-
●
●
●
8
CAP; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> OD=10 IMA
8-97940-638-0
01
1
1409-
●
●
●
1
5
3
1
7
8
2
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
CYLINDER; SLAVE,CLU
4X2<TFB***> M/T MUA 5 SPEED 5H<MWQ> (A) THA
8-97945-177-0
01
1
1409-
●
●
●
1
CYLINDER; SLAVE,CLU
M/T MUX 5 SPEED 5S<MZJ> (C) THA
8-97946-624-2
01
1
1409-
●
1
CYLINDER; SLAVE,CLU
4X4<TFS***> M/T MUA 5 SPEED 5H<MWQ> (B) THA
8-97946-625-1
01
1
1409-
●
●
●
2
REPAIR KIT; CLU SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
5-87832-048-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ> THA
8-97945-722-0
01
1
1409-
●
●
●
3
ROD; PUSH,SLAVE CYL
M/T MUX 5 SPEED 5S<MZJ> THA
8-98187-063-0
01
1
1409-
●
5
SPRING ASM; PISTON,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA
8-97942-801-0
01
1
1409-
●
●
●
7
SCREW; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> M8X10 IMA
8-98020-477-0
01
1
1409-
●
●
●
8
CAP; BLEEDER,SLAVE CYL
M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> OD=10 IMA
8-97940-638-0
01
1
1409-
●
●
●
