1 |
00.646 CRANKSHAFT
THAILAND
|
8-97311-632-1 |
01 |
1 |
1409- |
| |
1 |
00.646 CRANKSHAFT
JAPAN
|
8-97388-828-4 |
01 |
1 |
1409- |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
GREEN
|
8-97388-502-0 |
05 |
1 |
1409- |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLACK
|
8-97388-503-0 |
05 |
1 |
1409- |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLUE
|
8-97388-504-0 |
05 |
1 |
1409- |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
YELLOW
|
8-97388-505-0 |
05 |
1 |
1409- |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
RED
|
8-97388-506-0 |
05 |
1 |
1409- |
| |
12 |
00.666 FLYWHEEL
A/T 5 SPEED-AISIN(MA1)
|
8-98132-505-0 |
01 |
1 |
1409- |
| |
12 |
00.666 FLYWHEEL
M/T MUX 5 SPEED 5S(MZJ)
|
8-98186-653-1 |
01 |
1 |
1409-1409 |
| |
12 |
00.666 FLYWHEEL
M/T MUX 5 SPEED 5S(MZJ)
|
8-98283-475-0 |
01 |
1 |
1410- |
| |
14 |
00.662 WASHER; PULLEY DAMPER
ID=16.5 OD=45 T=12
|
5-09503-127-1 |
01 |
1 |
1409- |
| |
28 |
00.728 GEAR; CR/SHF
Z=44
|
8-97312-199-1 |
01 |
1 |
1409- |
| |
31 |
00.662 KEY; FEATHER,CR/SHF
00.729
JAPAN
|
8-94201-641-0 |
01 |
1 |
1409- |
| |
31 |
00.662 KEY; FEATHER,CR/SHF
00.729
THAILAND
|
9-08030-743-0 |
01 |
1 |
1409- |
| |
35 |
00.673 GEAR; RING
Z=122
|
8-94364-395-1 |
01 |
1 |
1409- |
| |
38 |
00.862 WASHER; FLYWHEEL
A/T 5 SPEED-AISIN(MA1)
|
8-98195-090-0 |
01 |
1 |
1409- |
| |
38 |
00.862 WASHER; FLYWHEEL
M/T MUX 5 SPEED 5S(MZJ)
00.669
|
8-94133-970-1 |
01 |
1 |
1409- |
| |
40 |
00.669 BOLT; FLYWHEEL
A/T 5 SPEED-AISIN(MA1)
M13X78
|
8-97080-561-1 |
08 |
1 |
1409- |
| |
40 |
00.669 BOLT; FLYWHEEL
M/T MUX 5 SPEED 5S(MZJ)
M13X36
|
8-97941-069-0 |
08 |
1 |
1409- |
| |
42 |
00.095 WASHER; THRUST,CR/SHF
|
8-97354-055-1 |
02 |
1 |
1409- |
| |
43 |
00.662 BOLT; CR/SHF PULLEY
M16X43
|
8-97373-852-1 |
01 |
1 |
1409- |
| |
49 |
00.669 BEARING; PILOT
M/T MUX 5 SPEED 5S(MZJ)
00.096
NSK
|
8-97920-344-2 |
01 |
1 |
1409- |
| |
49 |
00.669 BEARING; PILOT
M/T MUX 5 SPEED 5S(MZJ)
NACHI
|
8-97922-552-1 |
01 |
1 |
1409- |
| |
56 |
00.659 PULLEY; CR/SHF DAMPER
2-GROOVE
|
8-98183-902-0 |
01 |
1 |
1409- |
| |
61 |
00.659 PULLEY; FAN DRIVE
1-GROOVE
|
8-98131-628-0 |
01 |
1 |
1409- |
| |
63 |
00.629 PISTON
GRADE=A
|
8-98133-458-1 |
04 |
1 |
1409- |
| |
63 |
00.629 PISTON
GRADE=B
|
8-98133-459-1 |
04 |
1 |
1409- |
| |
63 |
00.629 PISTON
GRADE=C
|
8-98133-460-1 |
04 |
1 |
1409- |
| |
64 |
00.629 PISTON; O/S=0.50
|
8-98132-711-1 |
04 |
1 |
1409- |
| |
67 |
00.629 PISTON; O/S=0.25
|
8-98132-710-1 |
04 |
1 |
1409- |
| |
68 |
00.643 RING SET; PISTON,STANDARD
|
8-98171-044-0 |
04 |
1 |
1409- |
| |
69 |
00.643 RING SET; PISTON,O/S=0.50
|
8-98171-046-0 |
04 |
1 |
1409- |
| |
71 |
00.643 RING SET; PISTON,O/S=0.25
|
8-98171-045-0 |
04 |
1 |
1409- |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
|
8-97388-735-0 |
04 |
1 |
1409- |
| |
83 |
00.636 PIN; PISTON
|
8-98150-333-0 |
04 |
1 |
1409- |
| |
84 |
00.603 ROD ASM; CONN
|
8-97357-716-3 |
04 |
1 |
1409- |
| |
85 |
00.613 BUSHING; CONNROD
AFTER PRESS FITTING,SHAPE THE BUSHING.
|
8-97383-066-0 |
04 |
1 |
1409- |
| |
86 |
00.623 BOLT; CONNROD
M11X44.5
|
8-98048-538-0 |
08 |
1 |
1409- |
| |
87 |
00.613 PIN; CONNROD BIG END
OD=5 L=8
|
9-08160-508-0 |
08 |
1 |
1409- |
| |
100 |
00.666 PLATE; FLEX
A/T 5 SPEED-AISIN(MA1)
|
8-98192-379-0 |
01 |
1 |
1409- |
| |
126 |
00.639 RING; SNAP,PISTON PIN
OD=37.5
|
8-94460-687-0 |
08 |
1 |
1409- |
| |
172 |
02.383 ROTOR; CRANK SENSOR
|
8-98163-693-0 |
01 |
1 |
1409- |
| |
203 |
01.150 PIN; ROTOR
00.613
OD=5 L=8
|
9-08160-508-0 |
01 |
1 |
1409- |
| |
204 |
01.150 BOLT; ROTOR
|
8-97944-142-1 |
03 |
1 |
1409- |
| |
215 |
00.629 PISTON; O/S=0.75
|
8-98132-712-1 |
04 |
1 |
1409- |
| |
217 |
00.643 RING SET; PISTON,O/S=0.75
|
8-98171-047-0 |
04 |
1 |
1409- |
