Isuzu WW
▶
SUV
▶
UCR
▶
51520 - UCR/UCS(MIDDLE EAST)
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-10 - CAUTION PLATE AND LABEL
▶
7-10 — CAUTION PLATE AND LABEL
(#147157) — 31 parça
Tümü
A - UCB6VC
B - UCS6VC
◀
[710A] NO.3 (4 parça)
[710A] NO.1 (12 parça)
[710A] NO.2 (15 parça)
▶
321
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
321
08.808 LABEL; WARNING,POWER
ACCESSORY SOCKET FRT CONSOLE<KC5> (A)
8-98183-494-1
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
(A)
8-98183-494-1
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
ACCESSORY SOCKET FRT CONSOLE<KC5> (B)
8-98215-396-0
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
(B)
8-98215-396-0
01
1
1408-
●
8
214
135
179
2
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
2
03.680 LABEL; FUEL CAUTION
8-98147-133-0
01
1
1408-1510
●
●
8
03.680 LABEL; FUSE
PASSIVE ENTRY AND START SYSTEM<AP3> (A)
8-98281-134-0
01
1
1408-
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-136-0
01
1
1408-1510
●
●
8
03.680 LABEL; FUSE
PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-136-0
01
1
1511-
●
●
8
03.680 LABEL; FUSE
EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (A)
8-98281-132-0
01
1
1408-
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98239-994-0
01
1
1408-1408
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-097-0
01
1
1409-1510
●
●
8
03.680 LABEL; FUSE
EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-097-0
01
1
1511-
●
●
135
08.808 PLATE; CAUTION,ENGINE
4JJ1-TCX ENG(LS0)
8-98200-830-0
01
1
1511-
●
●
135
08.808 PLATE; CAUTION,ENGINE
4JK1-TCX ENG(LR0)
8-98200-831-0
01
1
1408-
●
●
179
08.808 PLATE; CAUTION,SERVICE
8-97356-568-0
01
1
1408-
●
●
214
08.808 LABEL; JACK
8-97943-121-0
01
1
1408-
●
●
8
109
88
16
321
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
8
03.680 LABEL; FUSE
PASSIVE ENTRY AND START SYSTEM<AP3> (A)
8-98281-134-0
01
1
1408-
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-136-0
01
1
1408-1510
●
●
8
03.680 LABEL; FUSE
PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-136-0
01
1
1511-
●
●
8
03.680 LABEL; FUSE
EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (A)
8-98281-132-0
01
1
1408-
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98239-994-0
01
1
1408-1408
●
●
8
03.680 LABEL; FUSE
4JK1-TCX ENG(LR0) EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-097-0
01
1
1409-1510
●
●
8
03.680 LABEL; FUSE
EXC. PASSIVE ENTRY AND START SYSTEM<AP3> (B)
8-98281-097-0
01
1
1511-
●
●
16
08.808 PLATE; CAUTION,SIR
AIR BAG DRIVER & PASSENGER(AK5)
8-97378-569-0
01
1
1408-
●
16
08.808 PLATE; CAUTION,SIR
8-97378-569-0
01
1
1408-
●
88
08.808 LABEL; ANTI THEFT
REMOTE CONT DOOR LOCK W/ANTI THEFT<7KY>
8-98141-993-2
02
1
1408-
●
●
109
08.808 PLATE; CAUTION,TIRE PLACARD
8-98197-215-0
01
1
1408-
●
●
321
08.808 LABEL; WARNING,POWER
ACCESSORY SOCKET FRT CONSOLE<KC5> (A)
8-98183-494-1
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
(A)
8-98183-494-1
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
ACCESSORY SOCKET FRT CONSOLE<KC5> (B)
8-98215-396-0
01
1
1408-
●
321
08.808 LABEL; WARNING,POWER
(B)
8-98215-396-0
01
1
1408-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
