2 |
05.812 BOLT; BRK DRUM
M6X16 CK-HEAD
|
0-36410-616-0 |
02 |
1 |
1407- |
● |
● |
| |
3 |
05.809 ROTOR; DISC BRK,RR
VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-98115-794-1 |
02 |
1 |
1407- |
● |
|
| |
3 |
05.809 ROTOR; DISC BRK,RR
|
8-98115-794-1 |
02 |
1 |
1407- |
|
● |
| |
4 |
05.816 HOLDER; BRG,AXLE SHAFT
EXC. VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-98103-450-3 |
02 |
1 |
1407- |
● |
|
| |
4 |
05.816 HOLDER; BRG,AXLE SHAFT
VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-98191-376-0 |
02 |
1 |
1407- |
● |
|
| |
4 |
05.816 HOLDER; BRG,AXLE SHAFT
|
8-98191-376-0 |
02 |
1 |
1407- |
|
● |
| |
9 |
05.812 PIN; WHEEL,RR AXLE
M12X42.5 RH THREAD
|
8-97944-831-1 |
12 |
1 |
1407- |
● |
● |
| |
14 |
05.816 NUT; BRG HOLDER TO CASE
M12 FLANGE
|
0-91180-212-0 |
08 |
1 |
1407- |
● |
● |
| |
16 |
05.822 SEAL; OIL,RR HUB,OUTER
|
8-98134-394-0 |
02 |
1 |
1407- |
● |
● |
| |
18 |
05.822 RETAINER; RR AXLE
EXC. VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-97239-868-0 |
02 |
1 |
1407- |
● |
|
| |
18 |
05.822 RETAINER; RR AXLE
VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-98009-341-0 |
02 |
1 |
1407- |
● |
|
| |
18 |
05.822 RETAINER; RR AXLE
|
8-98009-341-0 |
02 |
1 |
1407- |
|
● |
| |
25 |
05.420 SHAFT; AXLE,RR
|
8-98080-678-2 |
02 |
1 |
1407- |
● |
● |
| |
40 |
05.387 SEAL; OIL,REAR AXLE
|
8-97323-297-0 |
02 |
1 |
1407- |
● |
● |
| |
49 |
05.387 CASE; RR AXLE
EXC. VAC POWER 4 WHL DISC BRAKE<JF8>
|
8-98191-429-4 |
01 |
1 |
1407- |
● |
|
| |
49 |
05.387 CASE; RR AXLE
VAC POWER 4 WHL DISC BRAKE<JF8>
ELECTRONIC TRACTION CONTROL<NW9>
|
8-98191-432-4 |
01 |
1 |
1407- |
● |
● |
| |
49 |
05.387 CASE; RR AXLE
VAC POWER 4 WHL DISC BRAKE<JF8>
EXC. ELECTRONIC TRACTION CONTROL<NW9>
|
8-98191-431-4 |
01 |
1 |
1407- |
● |
● |
| |
58 |
05.508 PLUG; DRAIN,AXLE CASE
M16X12.5
|
8-97307-060-0 |
01 |
1 |
1407- |
● |
● |
| |
59 |
05.400 GASKET; DRAIN PLUG
01.252
ID=16.2 OD=24
|
9-09571-416-0 |
01 |
1 |
1407- |
● |
● |
| |
60 |
05.387 BREATHER; RR AXLE CASE
L=29
|
8-98006-960-0 |
01 |
1 |
1407- |
● |
● |
| |
63 |
05.400 PLUG; OIL FILLER,AXLE CASE
|
8-97307-059-1 |
01 |
1 |
1407- |
● |
● |
| |
64 |
05.400 GASKET; OIL FILLER,AXLE CASE
ID=20 OD=30
|
8-94462-734-0 |
01 |
1 |
1407- |
● |
● |
| |
69 |
05.387 STUD; AXLE CASE
M10X31 L=43
|
8-98022-413-0 |
02 |
1 |
1407- |
● |
● |
| |
70 |
05.387 NUT; CARRIER
00.833
M10
|
0-91110-510-0 |
02 |
1 |
1407-1509 |
● |
● |
| |
70 |
05.387 NUT; CARRIER
04.085
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1510- |
● |
● |
| |
71 |
05.389 WASHER; LK,FINAL DRIVE SETTING
02.277
ID=10.2
|
0-91510-810-0 |
02 |
1 |
1407-1509 |
● |
● |
| |
79 |
05.387 BOLT; COVER TO CASE
(A)
M10X30 W/LK WASHER
|
0-50561-030-0 |
07 |
1 |
1407-1509 |
● |
● |
| |
79 |
05.387 BOLT; COVER TO CASE
04.085
(A)
M10X30 FLANGE
|
0-28061-030-0 |
07 |
1 |
1510- |
● |
● |
| |
79 |
05.387 BOLT; COVER TO CASE
(B)
M10X90 W/LK WASHER
|
0-50561-090-0 |
01 |
1 |
1407-1509 |
● |
● |
| |
79 |
05.387 BOLT; COVER TO CASE
(B)
M10X90
|
0-28061-090-0 |
01 |
1 |
1510- |
● |
● |
| |
163 |
05.422 RING; SNAP,AXLE SHAFT
ID=38.5 T=1.75
|
9-09180-042-0 |
AR |
1 |
1407- |
● |
● |
| |
163 |
05.422 RING; SNAP,AXLE SHAFT
ID=38.5 T=2.00
|
9-09952-253-0 |
AR |
1 |
1407- |
● |
● |
| |
199 |
05.855 BEARING; RR AXLE
|
8-97216-797-2 |
02 |
1 |
1407- |
● |
● |
| |
217 |
05.002 BOLT; RR BRK
VAC POWER 4 WHL DISC BRAKE<JF8>
06.056
M12X25 FLANGE
|
8-98033-645-0 |
04 |
1 |
1407- |
● |
|
| |
217 |
05.002 BOLT; RR BRK
06.056
M12X25 FLANGE
|
8-98033-645-0 |
04 |
1 |
1407- |
|
● |
| |
270 |
05.855 SHIM; RETAINER
05.537
T=0.24
|
9-41519-109-0 |
AR |
1 |
1407- |
● |
● |
| |
278 |
05.822 CATCHER; OIL
|
8-98103-447-2 |
02 |
1 |
1407- |
● |
● |
