1 |
AXLE; FRT
FRT AXLE GRESE NON MENTENANCE<B3L>
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
|
1-43111-113-0 |
01 |
1 |
9203-9302 |
| |
1 |
AXLE; FRT
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
|
1-43111-113-1 |
01 |
1 |
9303-9312 |
| |
1 |
AXLE; FRT
|
1-43111-113-1 |
01 |
1 |
9401- |
| |
1 |
AXLE; FRT
EXC. FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-43111-102-1 |
01 |
1 |
9203-9302 |
| |
1 |
AXLE; FRT
FRT AXLE GRESE NON MENTENANCE<B3L>
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
|
1-43111-102-1 |
01 |
1 |
9203-9302 |
| |
1 |
AXLE; FRT
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
|
1-43111-102-2 |
01 |
1 |
9303-9312 |
| |
2 |
KNUCKLE; FRT AXLE
|
1-43132-071-0 |
01 |
1 |
9203-9404 |
| |
2 |
KNUCKLE; FRT AXLE
|
1-43132-087-0 |
01 |
1 |
9405- |
| |
2 |
KNUCKLE; FRT AXLE
|
1-43131-071-1 |
01 |
1 |
9203-9404 |
| |
2 |
KNUCKLE; FRT AXLE
|
1-43131-087-0 |
01 |
1 |
9405- |
| |
3 |
KING PIN SET
FRT AXLE GRESE NON MENTENANCE<B3L>
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
|
1-87830-640-0 |
02 |
1 |
9203-9302 |
| |
3 |
KING PIN SET
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
|
1-87830-640-0 |
02 |
1 |
9303-9404 |
| |
3 |
KING PIN SET
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
|
1-87830-738-0 |
02 |
1 |
9405-9412 |
| |
3 |
KING PIN SET
|
1-87830-738-0 |
02 |
1 |
9501- |
| |
3 |
KING PIN SET
EXC. FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-87830-039-5 |
02 |
1 |
9203-9302 |
| |
3 |
KING PIN SET
FRT AXLE GRESE NON MENTENANCE<B3L>
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
|
1-87830-039-5 |
02 |
1 |
9203-9302 |
| |
3 |
KING PIN SET
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
|
1-87830-039-5 |
02 |
1 |
9303-9404 |
| |
3 |
KING PIN SET
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
|
1-87830-737-0 |
02 |
1 |
9405-9412 |
| |
5 |
PIN; KNUCKLE TO DRUM COVER
|
1-09740-072-0 |
02 |
1 |
9203- |
| |
6 |
SEAL; KING PIN
|
9-09926-024-0 |
04 |
1 |
9203- |
| |
8 |
BEARING; NEEDLE,KING PIN
(A)
NTN
|
9-00096-242-0 |
04 |
1 |
9203- |
| |
8 |
BEARING; NEEDLE,KING PIN
(B)
NTN
|
9-00096-243-0 |
02 |
1 |
9203- |
| |
9 |
PLUG; KNUCKLE
|
9-09201-363-0 |
02 |
1 |
9203-9404 |
| |
11 |
RING; SNAP,KNUCKLE PLUG
|
9-09950-204-0 |
02 |
1 |
9203- |
| |
17 |
BOLT; STOPPER KNUCKLE
M18X53
|
1-09009-066-0 |
02 |
1 |
9203- |
| |
18 |
NUT; STOPPER BOLT,KNUCKLE
M18
|
9-99110-518-0 |
02 |
1 |
9203- |
| |
21 |
NIPPLE; GREASE,KING PIN
(A)
PT1/8 ELBOW 67.5?
|
9-09031-110-0 |
02 |
1 |
9203- |
| |
21 |
NIPPLE; GREASE,KING PIN
(B)
PT1/8 ELBOW
|
9-09031-210-0 |
02 |
1 |
9203- |
| |
25 |
BEARING; THRUST,KING PIN
FRT AXLE GRESE NON MENTENANCE<B3L>
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
NSK
|
1-09829-043-0 |
02 |
1 |
9203-9302 |
| |
25 |
BEARING; THRUST,KING PIN
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3)
NSK
|
1-09829-043-2 |
02 |
1 |
9303-9412 |
| |
25 |
BEARING; THRUST,KING PIN
NSK
|
1-09829-043-2 |
02 |
1 |
9501- |
| |
25 |
BEARING; THRUST,KING PIN
EXC. FRT AXLE GRESE NON MENTENANCE<B3L>
NTN
|
1-09829-027-1 |
02 |
1 |
9203-9302 |
| |
25 |
BEARING; THRUST,KING PIN
FRT AXLE GRESE NON MENTENANCE<B3L>
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
NTN
|
1-09829-027-1 |
02 |
1 |
9203-9302 |
| |
25 |
BEARING; THRUST,KING PIN
EXC. NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA
EQUIPMENT(RR3)
NTN
|
1-09829-027-1 |
02 |
1 |
9303-9412 |
| |
30 |
WASHER; THRUST,KING PIN
T=4.875 -4.900
|
1-43171-185-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=4.900 -4.925
|
1-43171-186-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=4.925 -4.950
|
1-43171-187-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=4.950 -4.975
|
1-43171-188-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=4.975 -5.000
|
1-43171-189-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.000 -5.025
|
1-43171-190-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.025 -5.050
|
1-43171-191-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.050 -5.075
|
1-43171-192-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.075 -5.100
|
1-43171-193-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.100 -5.125
|
1-43171-194-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.125 -5.150
|
1-43171-195-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.150 -5.175
|
1-43171-196-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.175 -5.200
|
1-43171-197-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.200 -5.225
|
1-43171-198-0 |
AR |
1 |
9203- |
| |
30 |
WASHER; THRUST,KING PIN
T=5.225 -5.250
|
1-43171-199-0 |
AR |
1 |
9203- |
| |
32 |
BOLT; KEY,KING PIN
|
1-43116-002-1 |
02 |
1 |
9203- |
| |
33 |
NUT; KEY BOLT
M10
|
9-09110-410-0 |
02 |
1 |
9203- |
| |
34 |
WASHER; LK,KEY BOLT
ID=10.2
|
9-09150-510-0 |
02 |
1 |
9203- |
| |
36 |
ARM; KNUCKLE
|
1-43133-057-1 |
01 |
1 |
9203-9404 |
| |
36 |
ARM; KNUCKLE
|
1-43133-063-0 |
01 |
1 |
9405- |
| |
37 |
BOLT; KNUCKLE ARM
(B)
M22X179
|
1-09000-578-0 |
01 |
1 |
9203- |
| |
37 |
BOLT; KNUCKLE ARM
(A)
M22X167
|
9-09806-847-2 |
01 |
1 |
9203- |
| |
40 |
NUT; KNUCKLE ARM
M22
|
9-09844-670-0 |
02 |
1 |
9203- |
| |
44 |
COVER; KING PIN
|
1-43175-014-1 |
02 |
1 |
9203- |
| |
45 |
GASKET; KING PIN COVER
|
1-42319-044-0 |
02 |
1 |
9203- |
| |
48 |
BOLT; COVER
M12X20 W/LK WASHER
|
0-50041-220-0 |
08 |
1 |
9203-9501 |
| |
48 |
BOLT; COVER
M12X16 FLANGE
|
0-28081-216-0 |
08 |
1 |
9502- |
| |
58 |
ARM; TIE ROD
|
1-43135-036-0 |
01 |
1 |
9203-9308 |
| |
58 |
ARM; TIE ROD
|
1-43135-021-1 |
01 |
1 |
9309-9404 |
| |
58 |
ARM; TIE ROD
|
1-43135-044-0 |
01 |
1 |
9405- |
| |
58 |
ARM; TIE ROD
|
1-43134-036-0 |
01 |
1 |
9203-9308 |
| |
58 |
ARM; TIE ROD
|
1-43134-021-1 |
01 |
1 |
9309-9404 |
| |
58 |
ARM; TIE ROD
|
1-43134-044-0 |
01 |
1 |
9405- |
| |
59 |
NUT; TIE ROD ARM
M22
|
9-09844-670-0 |
04 |
1 |
9203- |
| |
60 |
BOLT; TIE ROD ARM
M22X180.5
|
1-09070-117-0 |
04 |
1 |
9203- |
| |
61 |
ROD END; TIE ROD
FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-43150-627-1 |
01 |
1 |
9203-9302 |
| |
61 |
ROD END; TIE ROD
|
1-43150-627-2 |
01 |
1 |
9303- |
| |
61 |
ROD END; TIE ROD
FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-43150-626-1 |
01 |
1 |
9203-9302 |
| |
61 |
ROD END; TIE ROD
|
1-43150-626-2 |
01 |
1 |
9303- |
| |
61 |
ROD END; TIE ROD
EXC. FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-43150-662-1 |
01 |
1 |
9203-9302 |
| |
61 |
ROD END; TIE ROD
EXC. FRT AXLE GRESE NON MENTENANCE<B3L>
|
1-43150-661-1 |
01 |
1 |
9203-9302 |
| |
66 |
NUT; TIE ROD END
M24 SLOTTED
|
1-09442-020-0 |
02 |
1 |
9203- |
| |
67 |
WASHER; LK,TIE ROD END
ID=12.2
|
9-09150-512-0 |
04 |
1 |
9203-9207 |
| |
67 |
WASHER; LK,TIE ROD END
ID=12.2
|
9-09150-812-0 |
04 |
1 |
9208-9410 |
| |
68 |
BOLT; TIE ROD END
M12X55
|
9-91061-255-0 |
04 |
1 |
9203- |
| |
74 |
NUT; TIE ROD END
M12
|
9-99110-412-0 |
04 |
1 |
9203-9207 |
| |
74 |
NUT; TIE ROD END
M12
|
9-99110-512-0 |
04 |
1 |
9208- |
| |
80 |
PIN; SPLIT,ROD END
OD=4.6 L=35
|
9-08115-035-0 |
02 |
1 |
9203- |
| |
81 |
ROD; TIE
|
9-43151-119-1 |
01 |
1 |
9203-9308 |
| |
81 |
ROD; TIE
|
9-43151-120-1 |
01 |
1 |
9309- |
| |
82 |
BAR; STAB,FRT SUSP
FRONT STABILIZER SHAFT<F59>
|
1-51770-072-1 |
01 |
1 |
9203-9406 |
| |
82 |
BAR; STAB,FRT SUSP
FRONT STABILIZER SHAFT<F59>
NEW ZEALAND EQUIPMENT(PK5)
|
1-51770-072-1 |
01 |
1 |
9407- |
| |
82 |
BAR; STAB,FRT SUSP
FRONT STABILIZER SHAFT<F59>
AUSTRALIA EQUIPMENT(RR3)
W/BUSH
|
1-51770-041-2 |
01 |
1 |
9407- |
| |
90 |
BUSHING; RUBBER,STAB BAR
FRONT STABILIZER SHAFT<F59>
|
1-51779-067-0 |
02 |
1 |
9203-9406 |
| |
90 |
BUSHING; RUBBER,STAB BAR
FRONT STABILIZER SHAFT<F59>
NEW ZEALAND EQUIPMENT(PK5)
|
1-51779-067-0 |
02 |
1 |
9407- |
| |
90 |
BUSHING; RUBBER,STAB BAR
FRONT STABILIZER SHAFT<F59>
AUSTRALIA EQUIPMENT(RR3)
|
1-51779-066-0 |
02 |
1 |
9407- |
| |
91 |
BUSHING; RUBBER,STAB BAR
FRONT STABILIZER SHAFT<F59>
|
1-51779-084-0 |
04 |
1 |
9203- |
| |
110 |
CLAMP; STAB TO ROD
FRONT STABILIZER SHAFT<F59>
(A)
|
1-51789-027-1 |
02 |
1 |
9203- |
| |
110 |
CLAMP; STAB TO ROD
FRONT STABILIZER SHAFT<F59>
(B)
|
1-51789-028-1 |
02 |
1 |
9203- |
| |
111 |
BOLT; CLAMP TO ROD
FRONT STABILIZER SHAFT<F59>
M12X30
|
0-20801-230-0 |
02 |
1 |
9203- |
| |
111 |
BOLT; CLAMP TO ROD
FRONT STABILIZER SHAFT<F59>
M12X50
|
0-20801-250-0 |
04 |
1 |
9203- |
| |
112 |
BUSHING; ROD
FRONT STABILIZER SHAFT<F59>
|
9-51631-050-0 |
04 |
1 |
9203- |
| |
114 |
ROD; STAB BAR
FRONT STABILIZER SHAFT<F59>
|
1-51773-065-0 |
02 |
1 |
9203- |
| |
115 |
WASHER; CENTER,STAB TO FRAME
FRONT STABILIZER SHAFT<F59>
(A)
ID=16.8
|
1-51631-022-0 |
04 |
1 |
9203- |
| |
115 |
WASHER; CENTER,STAB TO FRAME
FRONT STABILIZER SHAFT<F59>
(B)
|
9-51631-051-0 |
04 |
1 |
9203- |
| |
116 |
NUT; LK,STAB TO FRAME
FRONT STABILIZER SHAFT<F59>
M14
|
9-99111-414-0 |
04 |
1 |
9203- |
| |
127 |
NUT; CLAMP
FRONT STABILIZER SHAFT<F59>
M12
|
9-99110-412-0 |
06 |
1 |
9203- |
| |
128 |
WASHER; LK,CLAMP
FRONT STABILIZER SHAFT<F59>
ID=12.2
|
9-09150-512-0 |
06 |
1 |
9203- |
| |
305 |
COVER; KNUCKLE
|
1-43175-021-0 |
02 |
1 |
9405- |
