Isuzu WW
▶
TRUCKS
▶
FVR
▶
11240 - FVR-RHD(EUROPE)EURO5
▶
2 - Clutch, Transmission, Trans Axle
▶
2-53 - TRANSMISSION OIL COOLER SYSTEM
▶
2-53 — TRANSMISSION OIL COOLER SYSTEM
(#144010) — 4 parça
Tümü
A - FGD5MV
B - FGR5MV
265
255
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
255
GASKET; SENSOR
6HK1-TCC ENG(81L) MZW6P M/T(RSZ) P60 PROP SHAFT(C2M) 15" CLUTCH(RE9) TRANSMISSION SIDE PTO WO/LEVER(SH5) PTO CONTROL<SV6> MANUAL TRANSMISSION<X9C> ID=12.2
9-09571-412-0
01
1
1405-
●
●
255
GASKET; SENSOR
6HK1-TCC ENG(81L) MZW6P M/T(RSZ) P60 PROP SHAFT(C2M) 15" CLUTCH(RE9) MANUAL TRANSMISSION<X9C> EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO WO/LEVER(SH5),PTO CONTROL<SV6> ID=12.2
9-09571-412-0
01
1
1405-
●
●
265
PLUG; HOLE
6HK1-TCC ENG(81L) MZW6P M/T(RSZ) P60 PROP SHAFT(C2M) 15" CLUTCH(RE9) TRANSMISSION SIDE PTO WO/LEVER(SH5) PTO CONTROL<SV6> MANUAL TRANSMISSION<X9C> M12X9
0-92002-412-0
01
1
1405-
●
●
265
PLUG; HOLE
6HK1-TCC ENG(81L) MZW6P M/T(RSZ) P60 PROP SHAFT(C2M) 15" CLUTCH(RE9) MANUAL TRANSMISSION<X9C> EXC. PTO ZF TRANS RR(BDM),TRANSMISSION SIDE PTO WO/LEVER(SH5),PTO CONTROL<SV6> M12X9
0-92002-412-0
01
1
1405-
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
