1 |
SHOE; BRK,RR
LEADING
|
1-47170-204-0 |
01 |
1 |
0105- |
| |
1 |
SHOE; BRK,RR
TRAILING
|
1-47170-205-0 |
01 |
1 |
0105- |
| |
1 |
SHOE; BRK,RR
LEADING
|
1-47170-202-0 |
01 |
1 |
0105- |
| |
1 |
SHOE; BRK,RR
TRAILING
|
1-47170-203-0 |
01 |
1 |
0105- |
| |
2 |
LINING SET; RR BRK,STANDARD
TRAILING
|
1-88310-393-0 |
01 |
1 |
0105- |
| |
2 |
LINING SET; RR BRK,STANDARD
LEADING
|
1-88310-823-0 |
01 |
1 |
0105- |
| |
3 |
LINING SET; RR BRK,OVER SIZE
TRAILING
|
1-88310-394-0 |
01 |
1 |
0105- |
| |
3 |
LINING SET; RR BRK,OVER SIZE
LEADING
|
1-88310-824-0 |
01 |
1 |
0105- |
| |
4 |
BUSHING; BRK SHOE,RR WHEEL
|
1-47112-012-0 |
04 |
1 |
0105- |
| |
5 |
LINING; RR BRK SHOE,STANDARD
TRAILING
T=16
|
1-47125-563-0 |
04 |
1 |
0105- |
| |
5 |
LINING; RR BRK SHOE,STANDARD
LEADING WO/INDICATOR HOLE
|
1-47126-084-0 |
04 |
1 |
0105- |
| |
5 |
LINING; RR BRK SHOE,STANDARD
LEADING W/INDICATOR HOLE
|
1-47126-088-0 |
04 |
1 |
0105- |
| |
6 |
LINING; RR BRK SHOE,OVER SIZE
TRAILING
T=17
|
1-47125-564-0 |
04 |
1 |
0105- |
| |
6 |
LINING; RR BRK SHOE,OVER SIZE
LEADING WO/INDICATOR HOLE
|
1-47126-085-0 |
04 |
1 |
0105- |
| |
6 |
LINING; RR BRK SHOE,OVER SIZE
LEADING W/INDICATOR HOLE
|
1-47126-089-0 |
04 |
1 |
0105- |
| |
7 |
RIVET; LINING,RR BRK
L=19.5
|
1-09732-035-0 |
AR |
1 |
0105- |
| |
8 |
PIN; RETURN SPRING,RR BRK SHOE
(A)
|
1-09744-074-0 |
04 |
1 |
0105- |
| |
8 |
PIN; RETURN SPRING,RR BRK SHOE
(B)
|
1-47119-029-0 |
04 |
1 |
0105- |
| |
9 |
SPRING; RETURN,BRK SHOE
(A)
|
1-09583-210-0 |
02 |
1 |
0105- |
| |
9 |
SPRING; RETURN,BRK SHOE
(B)
|
1-09583-277-2 |
02 |
1 |
0105- |
| |
10 |
RING; SNAP,SPR PIN
ID=7
|
9-09185-407-0 |
02 |
1 |
0105- |
| |
11 |
PIN; ANCHOR,RR WHEEL BRK
L=121.5
|
1-47131-039-0 |
04 |
1 |
0105- |
| |
12 |
ROLLER; CAM,BRK SHOE
|
1-47113-005-0 |
04 |
1 |
0105- |
| |
13 |
CLIP; ROLLER PIN,BRK SHOE
|
9-47119-022-0 |
04 |
1 |
0105- |
| |
14 |
PIN; CAM ROLLER,BRK SHOE
|
1-09744-061-0 |
04 |
1 |
0105- |
| |
27 |
COVER; CHECK HOLE,DRUM COVER
|
1-09333-151-0 |
04 |
1 |
0105- |
| |
30 |
BOLT; DRUM COVER
M10X12
|
1-47159-187-0 |
12 |
1 |
0105- |
| |
32 |
WASHER; LK
(A)
|
1-47119-050-0 |
02 |
1 |
0105- |
| |
32 |
WASHER; LK
(B)
ID=10.2
|
9-09150-510-0 |
04 |
1 |
0105-0603 |
| |
32 |
WASHER; LK
(B)
ID=10.2
|
0-91510-510-0 |
04 |
1 |
0604- |
| |
34 |
NIPPLE; GREASE,CHAMBER BRKT
(A)
PT1/8 STRAIGHT
|
9-09031-010-0 |
02 |
1 |
0105-0512 |
| |
34 |
NIPPLE; GREASE,CHAMBER BRKT
(A)
PT1/8 STRAIGHT
|
0-90301-410-0 |
02 |
1 |
0601- |
| |
34 |
NIPPLE; GREASE,CHAMBER BRKT
(B)
PT1/8 ELBOW 67.5?
|
9-09031-110-0 |
02 |
1 |
0105-0512 |
| |
34 |
NIPPLE; GREASE,CHAMBER BRKT
(B)
PT1/8 ELBOW 67.5?
|
0-90301-510-0 |
02 |
1 |
0601- |
| |
45 |
BRACKET; ANCHOR PIN,W/BUSHING
|
1-47137-128-1 |
02 |
1 |
0105- |
| |
46 |
RING; SPACER,CM/SHF,RR BRK
|
1-47143-005-0 |
02 |
1 |
0105- |
| |
48 |
SEAL; OIL,CM/SHF,RR BRK
|
1-09625-228-0 |
02 |
1 |
0105- |
| |
49 |
BUSHING; CM/SHF,RR BRK
|
1-47146-009-0 |
02 |
1 |
0105- |
| |
50 |
CAMSHAFT; BRK,RR BRK
AUTO ADJUSTER BRAKE<BCU>
|
1-47141-129-0 |
01 |
1 |
0105- |
| |
50 |
CAMSHAFT; BRK,RR BRK
AUTO ADJUSTER BRAKE<BCU>
|
1-47141-128-0 |
01 |
1 |
0105- |
| |
50 |
CAMSHAFT; BRK,RR BRK
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-47141-134-0 |
01 |
1 |
0105- |
| |
50 |
CAMSHAFT; BRK,RR BRK
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-47141-133-0 |
01 |
1 |
0105- |
| |
52 |
BOLT; ANCHOR BRKT
M14X50
|
1-09040-066-0 |
02 |
1 |
0105- |
| |
53 |
BOLT; LOCK PLATE
M10X16
|
0-20801-016-0 |
02 |
1 |
0105-0512 |
| |
53 |
BOLT; LOCK PLATE
M10X16
|
0-20851-016-0 |
02 |
1 |
0601- |
| |
54 |
WASHER; LK,ANCHOR PIN,RR BRK
|
1-47133-011-0 |
02 |
1 |
0105- |
| |
55 |
PLATE; LK,RR WHEEL CYL
|
1-47133-005-0 |
02 |
1 |
0105- |
| |
61 |
INDICATOR; WEAR,RR BRK SHOE
|
1-82480-174-0 |
02 |
1 |
0105- |
| |
63 |
ADJUSTER ASM; SLACK,RR BRK
AUTO ADJUSTER BRAKE<BCU>
|
1-48270-098-0 |
01 |
1 |
0105- |
| |
63 |
ADJUSTER ASM; SLACK,RR BRK
AUTO ADJUSTER BRAKE<BCU>
|
1-48270-097-0 |
01 |
1 |
0105- |
| |
63 |
ADJUSTER ASM; SLACK,RR BRK
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-48270-078-1 |
01 |
1 |
0105- |
| |
63 |
ADJUSTER ASM; SLACK,RR BRK
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-48270-077-1 |
01 |
1 |
0105- |
| |
65 |
SPACER; SLACK ADJ,BRK
|
1-47143-014-0 |
02 |
1 |
0105- |
| |
66 |
PIN; JAW JOINT
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-09744-088-0 |
02 |
1 |
0105- |
| |
67 |
NUT; POWER CHAMBER FIX
M16
|
9-99110-416-0 |
08 |
1 |
0105-0512 |
| |
67 |
NUT; POWER CHAMBER FIX
M16
|
0-91110-516-0 |
08 |
1 |
0601- |
| |
68 |
WASHER; LK,CHAMBER
ID=16.2
|
9-09150-516-0 |
08 |
1 |
0105-0603 |
| |
68 |
WASHER; LK,CHAMBER
ID=16.2
|
0-91510-516-0 |
08 |
1 |
0604-0802 |
| |
68 |
WASHER; LK,CHAMBER
ID=16.2
|
0-91510-816-0 |
08 |
1 |
0803- |
| |
69 |
JOINT; JAW
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-09768-060-1 |
02 |
1 |
0105- |
| |
70 |
NUT; LK,JAW JOINT
M16
|
9-99111-416-0 |
02 |
1 |
0105-0512 |
| |
70 |
NUT; LK,JAW JOINT
M16
|
0-91111-516-0 |
02 |
1 |
0601- |
| |
71 |
WASHER; PL,JAW JOINT
EXC. AUTO ADJUSTER BRAKE<BCU>
ID=17 OD=32
|
9-09160-616-0 |
02 |
1 |
0105- |
| |
72 |
PIN; SPLIT
EXC. AUTO ADJUSTER BRAKE<BCU>
OD=3.7 L=28
|
9-08114-028-0 |
02 |
1 |
0105-0606 |
| |
72 |
PIN; SPLIT
EXC. AUTO ADJUSTER BRAKE<BCU>
OD=3.7 L=28
|
0-81124-028-0 |
02 |
1 |
0607- |
| |
73 |
COLLAR; FELT RING,CM/SHF
|
1-47143-016-0 |
02 |
1 |
0105- |
| |
74 |
BUSHING; SLACK ADJ
AUTO ADJUSTER BRAKE<BCU>
|
1-48279-078-0 |
06 |
1 |
0105- |
| |
74 |
BUSHING; SLACK ADJ
EXC. AUTO ADJUSTER BRAKE<BCU>
|
1-09330-041-0 |
02 |
1 |
0105- |
| |
75 |
RING; FELT,CM/SHF
|
1-09620-009-0 |
02 |
1 |
0105- |
| |
78 |
BUSHING; BRKT
|
1-47146-008-0 |
02 |
1 |
0105- |
| |
79 |
BRACKET; CM/SHF
|
9-47145-013-0 |
04 |
1 |
0105- |
| |
80 |
GASKET; BUSHING
ID=39.7
|
9-09561-340-0 |
04 |
1 |
0105- |
| |
81 |
NUT
M10
|
9-09110-410-0 |
04 |
1 |
0105-0512 |
| |
81 |
NUT
M10
|
0-91110-510-0 |
04 |
1 |
0601- |
| |
82 |
NUT
M16
|
9-99110-516-0 |
04 |
1 |
0105-0512 |
| |
82 |
NUT
M16
|
0-91110-516-0 |
04 |
1 |
0601- |
| |
83 |
WASHER; PL
AUTO ADJUSTER BRAKE<BCU>
|
1-48279-033-0 |
02 |
1 |
0105- |
| |
83 |
WASHER; PL
ID=16.2
|
9-09851-672-2 |
08 |
1 |
0105- |
| |
84 |
BOLT; BRKT TO CASE
M16X40
|
9-92061-640-0 |
04 |
1 |
0105-0512 |
| |
84 |
BOLT; BRKT TO CASE
M16X40
|
0-20951-640-0 |
04 |
1 |
0601- |
| |
85 |
BOLT; CM/SHF BRKT
M10X20
|
0-20801-020-0 |
04 |
1 |
0105-0512 |
| |
85 |
BOLT; CM/SHF BRKT
M10X20
|
0-20851-020-0 |
04 |
1 |
0601- |
| |
88 |
CLIP; BRKT
|
1-09589-018-0 |
02 |
1 |
0105- |
| |
89 |
NUT; CHAMBER
M20
|
9-99111-420-0 |
02 |
1 |
0105-0411 |
| |
90 |
BRACKET; CHAMBER
|
1-42129-449-0 |
01 |
1 |
0105- |
| |
90 |
BRACKET; CHAMBER
|
1-42129-450-0 |
01 |
1 |
0105- |
| |
91 |
BOLT; CHAMBER
M8X12 W/LK WASHER
|
0-50040-812-0 |
02 |
1 |
0105-0411 |
| |
92 |
WASHER; LK,CHAMBER
ID=8.2
|
9-09150-508-0 |
02 |
1 |
0105-0411 |
| |
93 |
WASHER; PL,CHAMBER
ID=17 OD=32
|
9-09160-616-0 |
08 |
1 |
0105- |
| |
195 |
RING; SNAP,CM/SHF
|
9-09180-038-0 |
02 |
1 |
0105- |
| |
196 |
DISTANCE; CM/SHF
|
1-47143-004-0 |
01 |
1 |
0105- |
| |
198 |
NIPPLE; GREASE,SLACK ADJ
EXC. AUTO ADJUSTER BRAKE<BCU>
PT1/8 ELBOW 67.5?
|
9-09031-110-0 |
02 |
1 |
0105-0512 |
| |
198 |
NIPPLE; GREASE,SLACK ADJ
EXC. AUTO ADJUSTER BRAKE<BCU>
PT1/8 ELBOW 67.5?
|
0-90301-510-0 |
02 |
1 |
0601- |
| |
204 |
CONNECTOR; SPR CHAMBER
PT3/8 & M27 ELBOW
|
1-09650-118-1 |
02 |
1 |
0105-0411 |
| |
204 |
CONNECTOR; SPR CHAMBER
M16 & PT3/8 ELBOW
|
1-09650-438-0 |
04 |
1 |
0412- |
| |
204 |
CONNECTOR; SPR CHAMBER
M20 & PT3/8 ELBOW
|
1-09660-686-0 |
02 |
1 |
0105-0411 |
| |
210 |
BOLT; BRKT FIX
M16X30
M16X30 FLANGE
|
0-28981-630-0 |
04 |
1 |
0105-0509 |
| |
210 |
BOLT; BRKT FIX
M16X30 FLANGE
|
0-28891-630-0 |
04 |
1 |
0510- |
| |
210 |
BOLT; BRKT FIX
M16X50 FLANGE
|
0-28991-650-0 |
04 |
1 |
0105-0509 |
| |
210 |
BOLT; BRKT FIX
M16X50 FLANGE
|
0-28891-650-0 |
04 |
1 |
0510-0512 |
| |
210 |
BOLT; BRKT FIX
M16X50 FLANGE
|
0-28861-650-0 |
04 |
1 |
0601- |
| |
230 |
NIPPLE; SPR CHAMBER
M20 & PT1/4
|
9-09902-386-0 |
02 |
1 |
0105-0411 |
| |
231 |
NUT; CONNECTOR
M27
|
9-09840-286-0 |
02 |
1 |
0105-0411 |
| |
241 |
HOLDER
|
1-47119-096-0 |
02 |
1 |
0105- |
| |
256 |
COVER; INDICATOR
|
1-09333-147-0 |
02 |
1 |
0105- |
| |
298 |
GASKET
EXC. AUTO ADJUSTER BRAKE<BCU>
ID=23.3
|
9-09561-223-0 |
02 |
1 |
0105- |
| |
338 |
PLATE; DISTANCE
|
1-42129-463-0 |
01 |
1 |
0105-0506 |
| |
338 |
PLATE; DISTANCE
|
1-42129-462-0 |
01 |
1 |
0105-0506 |
| |
338 |
PLATE; DISTANCE
|
1-42129-505-0 |
02 |
1 |
0507- |
