4-31 — STEERING COLUMN AND SHAFT
(#139379) — 24 parça
103
102
105
148
66
172
348
96
172
348
95
1
79
291
231
291
66
251
203
2
104
66
148
33
35
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
STEERING UNIT
SEE FIG-NO 4-40 FOR COMPONENT. THA
8-97948-358-0
01
1
1405-
2
SHAFT ASM; STRG
MANUAL TILT CAB<RWZ> THA
8-97948-361-1
01
1
1405-
33
BOLT; STRG SHAFT TO UNIT
M8X30
8-97359-615-0
01
1
1405-
35
WASHER; LK,STRG SHAFT
ID=8.2 THA
0-91510-808-0
01
1
1405-
66
BOLT; STRG COLUMN
(B) M8X20 FLANGE THA
0-28650-820-0
02
1
1405-
66
BOLT; STRG COLUMN
(A) M5X18 TAPPING
0-72180-518-0
04
1
1405-
66
BOLT; STRG COLUMN
(B) M8X24.5 W/LK&PL WASHER
8-98051-939-0
02
1
1405-
79
CLIP; STRG COLUMN COVER
L=19 BLACK
8-94363-776-0
02
1
1405-
95
BOLT; STRG UNIT
M12X47 FLANGE
8-98055-055-0
04
1
1405-
96
NUT; STRG UNIT
M12 FLANGE
8-97359-618-0
02
1
1405-
102
LOCK ASM; STRG
THA
8-97948-271-0
01
1
1405-
103
SWITCH; IGNITION
THA
8-98045-349-0
01
1
1405-
104
BOLT; STRG LOCK TO COLUMN
M8X20 TORQUE SHEAR BOLT
8-97321-385-0
02
1
1405-
105
SCREW; IGN SW
THA
8-98045-346-0
02
1
1405-
148
NUT; COLUMN TO BRKT
M8 W/DISHED WASHER
8-97329-625-0
03
1
1405-
172
BRACKET; STRG
(B)
8-98055-061-0
01
1
1405-
172
BRACKET; STRG
(A)
8-98078-803-0
01
1
1405-
203
BOOT; STRG COLUMN LWR
MANUAL TILT CAB<RWZ> THA
8-97948-997-0
01
1
1405-
231
SEAL; RUBBER,STRG COLUMN
MANUAL TILT CAB<RWZ> THA
8-97949-002-0
01
1
1405-
251
COVER; LWR
MANUAL TILT CAB<RWZ> THA
8-97948-999-0
01
1
1405-
291
GROMMET; STRG SHAFT COVER
(A) H=15
8-94463-268-1
04
1
1405-
291
GROMMET; STRG SHAFT COVER
(B)
8-98029-442-1
02
1
1405-
348
CLIP; BRKT,STRG
(A) ID=5-12 L=18
1-09709-287-0
01
1
1405-
348
CLIP; BRKT,STRG
(B) ID=5-12 L=22
1-09709-288-0
01
1
1405-
