1 |
COVER ASM; RR,GEN
ASM PART: A = 8-97351-573-0
|
8-98230-321-0 |
01 |
1 |
- |
| |
1 |
COVER ASM; RR,GEN
ASM PART: B = 8-97351-574-1
|
8-98230-322-0 |
01 |
1 |
- |
| |
2 |
ROTOR; GEN
ASM PART: B = 8-97351-574-1
|
8-97249-330-1 |
01 |
1 |
- |
| |
2 |
ROTOR; GEN
ASM PART: A = 8-97351-573-0
|
8-97302-700-0 |
01 |
1 |
- |
| |
3 |
BEARING; ROTOR,GEN
(A) ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97062-744-0 |
01 |
1 |
- |
| |
3 |
BEARING; ROTOR,GEN
(B) ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-98146-442-0 |
01 |
1 |
- |
| |
10 |
RECTIFIER; GEN
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-98230-331-0 |
01 |
1 |
- |
| |
17 |
COVER ASM; FRT,GEN
ASM PART: B = 8-97351-574-1
|
8-97249-334-0 |
01 |
1 |
- |
| |
17 |
COVER ASM; FRT,GEN
ASM PART: A = 8-97351-573-0
|
8-97302-703-0 |
01 |
1 |
- |
| |
18 |
NUT; PULLEY,GEN
ASM PART: A = 8-97351-573-0
|
8-97083-293-0 |
01 |
1 |
- |
| |
19 |
PULLEY; GEN
ASM PART: A = 8-97351-573-0
|
8-97083-292-0 |
01 |
1 |
- |
| |
19 |
PULLEY; GEN
ASM PART: B = 8-97351-574-1
|
8-97249-335-0 |
01 |
1 |
- |
| |
22 |
STATOR; GEN
ASM PART: B = 8-97351-574-1
|
8-97249-331-1 |
01 |
1 |
- |
| |
22 |
STATOR; GEN
ASM PART: A = 8-97351-573-0
|
8-97302-701-0 |
01 |
1 |
- |
| |
44 |
SEAL; RR COVER,GEN
THA ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-94156-589-0 |
01 |
1 |
- |
| |
90 |
PUMP ASM; VAC,GEN
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97351-707-0 |
01 |
1 |
- |
| |
91 |
BODY; VAC PUMP
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97148-117-0 |
01 |
1 |
- |
| |
96 |
VALVE ASM; VAC PUMP
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97148-118-0 |
01 |
1 |
- |
| |
99 |
GASKET; VAC PUMP
(A), ID=18 OD=24
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
5-19679-002-0 |
02 |
1 |
- |
| |
99 |
GASKET; VAC PUMP
(B), ID=12 OD=24
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
5-19679-003-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(A), THA
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-94156-608-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(B) ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97083-304-0 |
01 |
1 |
- |
| |
108 |
ROTOR; VAC PUMP
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97148-115-1 |
01 |
1 |
- |
| |
109 |
VANE; VAC PUMP
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97083-298-0 |
03 |
1 |
- |
| |
121 |
COVER; RR,VAC PUMP
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97148-116-0 |
01 |
1 |
- |
| |
123 |
GUIDE; BRUSH
ASM PART: A = 8-97351-573-0, B = 8-97351-574-1
|
8-97062-644-0 |
01 |
1 |
- |
