Isuzu WW
▶
TRUCKS
▶
FRR
▶
11122 - FRR THAILAND
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-01 - FRONT BUMPER
▶
6-01 — FRONT BUMPER
(#13751) — 25 parça
32
311
32
1
301
93
94
312
34
672
101
84
72
70
30
103
32
42
321
229
322
1
674
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
BUMPER ASM; FRT
WHITE THA
8-97407-725-3
01
1
0808-
30
BRACKET; FRT BUMPER
8-97611-515-4
01
1
0808-
30
BRACKET; FRT BUMPER
8-97611-516-4
01
1
0808-
32
BOLT; BRKT,BUMPER
M10X35 FLANGE THA
0-28651-035-0
06
1
0808-
34
NUT; BRKT,BUMPER
M10 FLANGE THA
0-91180-210-0
02
1
0808-
42
BOLT; BUMPER
M10X30
8-94324-205-0
04
1
0808-
70
BRACKET; LICENSE PLATE,FRT
8-97611-492-1
02
1
0808-
72
NUT; BRKT
M6 FLANGE THA
0-91180-106-0
02
1
0808-
84
HOOK
8-98035-644-1
01
1
0808-
93
WASHER; LK,HOOK
ID=14.2
0-91510-814-0
02
1
0808-
94
NUT; HOOK
M14 THA
0-91110-514-0
02
1
0808-
101
STEP; BUMPER
8-97611-540-0
01
1
0808-
101
STEP; BUMPER
8-97611-541-0
01
1
0808-
103
NUT; BUMPER STEP
M6 FLANGE THA
0-91180-106-0
04
1
0808-
229
GROMMET
D=7X7 L=7.5 THA
5-09983-007-0
02
1
0808-
301
BOLT; HOOK TO FRAME
M14X60
0-10861-460-0
02
1
0808-
311
BOLT; BRKT
M14X45 FLANGE THA
0-28851-445-0
02
1
1210-1212
311
BOLT; BRKT
M14X35 FLANGE
0-28851-435-0
02
1
0808-1008
311
BOLT; BRKT
M14X45 FLANGE THA
0-28851-445-0
02
1
1009-
312
NUT; BRKT
M14 FLANGE THA
0-91180-214-0
02
1
0808-
321
COVER; BUMPER FRT SIDE
8-97616-293-0
01
1
0808-
321
COVER; BUMPER FRT SIDE
8-97616-294-0
01
1
0808-
322
SCREW; COVER FIX
M5X16 TAPPING HEXALOBULAR
0-72180-516-0
02
1
0808-
672
STUD; STEP
M6X20
8-97611-666-0
04
1
0808-
674
BRACKET; BUMPER,PLATE
8-97611-491-1
01
1
0808-
