15 |
CONNECTOR; AIR PIPE
(A)
DIN12 & M20 STRAIGHT
|
1-09660-877-0 |
05 |
1 |
1403- |
| |
15 |
CONNECTOR; AIR PIPE
(B)
M20 & RC3/8 STRAIGHT
|
1-09660-883-0 |
01 |
1 |
1403- |
| |
15 |
CONNECTOR; AIR PIPE
(C)
DIN12 & R3/8 ELBOW
|
1-09660-959-0 |
01 |
1 |
1403- |
| |
26 |
PIPE; AIR,UNION TO FLEX HOSE
L=257
THA
|
8-98175-904-0 |
01 |
1 |
1403- |
| |
28 |
NIPPLE; AIR PIPE
|
1-09654-128-1 |
01 |
1 |
1403- |
| |
28 |
NIPPLE; AIR PIPE
|
1-09654-128-1 |
02 |
1 |
1403- |
| |
29 |
NUT; NIPPLE
M20
|
0-91111-520-0 |
01 |
1 |
1403- |
| |
29 |
NUT; NIPPLE
M20
|
0-91111-520-0 |
02 |
1 |
1403- |
| |
30 |
WASHER; LK,NIPPLE
ID=20.2
|
0-91510-620-0 |
03 |
1 |
1403- |
| |
32 |
HOSE; FLEX,FRT
(A)
L=430
|
0-57847-430-1 |
02 |
1 |
1403- |
| |
32 |
HOSE; FLEX,FRT
(B)
L=470
|
0-57847-470-1 |
02 |
1 |
1403- |
| |
35 |
GASKET; FLEX HOSE
ID=11 OD=18
|
9-09572-510-0 |
04 |
1 |
1403- |
| |
35 |
GASKET; FLEX HOSE
ID=11 OD=18
|
9-09572-510-0 |
04 |
1 |
1403- |
| |
36 |
NUT; HOSE BRKT
M8 FLANGE
THA
|
0-91180-108-0 |
02 |
1 |
1403- |
| |
38 |
UNION; AIR PIPE
|
1-09654-128-1 |
01 |
1 |
1403- |
| |
39 |
NUT; PIPE UNION
M20
|
0-91111-520-0 |
01 |
1 |
1403- |
| |
40 |
WASHER; LK,PIPE UNION
ID=20.2
|
0-91510-620-0 |
01 |
1 |
1403- |
| |
48 |
NUT; UNION BRKT
(A)
M20
|
0-91111-520-0 |
02 |
1 |
1403- |
| |
48 |
NUT; UNION BRKT
(B)
M6 FLANGE
THA
|
0-91180-106-0 |
02 |
1 |
1403- |
| |
52 |
CONNECTOR; NYLON TUBE
(A)
DIN8 & R1/4 ELBOW
|
1-09660-956-0 |
02 |
1 |
1403- |
| |
52 |
CONNECTOR; NYLON TUBE
(B)
DIN12 & R1/4 ELBOW
|
1-09660-958-0 |
02 |
1 |
1403- |
| |
52 |
CONNECTOR; NYLON TUBE
(E)
DIN12 & R3/8 ELBOW
|
1-09660-959-0 |
01 |
1 |
1403- |
| |
52 |
CONNECTOR; NYLON TUBE
(C)
DIN8 R1/4 STRAIGHT
|
1-09660-963-0 |
02 |
1 |
1403- |
| |
52 |
CONNECTOR; NYLON TUBE
(D)
DIN12 & R1/4 STRAIGHT
|
1-09660-967-0 |
02 |
1 |
1403- |
| |
53 |
UNION; ELBOW
(A)
M20
|
0-92135-212-0 |
03 |
1 |
1403- |
| |
53 |
UNION; ELBOW
(B)
DIN12X2 & R3/8 3WAY
|
1-09661-131-0 |
01 |
1 |
1403- |
| |
65 |
BRACKET; FLEX HOSE
(A)
|
1-47479-676-0 |
02 |
1 |
1403- |
| |
65 |
BRACKET; FLEX HOSE
(B)
|
8-98094-075-0 |
01 |
1 |
1403- |
| |
65 |
BRACKET; FLEX HOSE
(C)
THA
|
8-98166-035-0 |
01 |
1 |
1403- |
| |
66 |
BOLT; HOSE BRKT
(A)
M8X25 FLANGE
THA
|
0-28650-825-0 |
02 |
1 |
1403- |
| |
66 |
BOLT; HOSE BRKT
(B)
M8X30 FLANGE
THA
|
0-28650-830-0 |
06 |
1 |
1403- |
| |
68 |
NUT; UNION
M20
|
0-91111-520-0 |
01 |
1 |
1403- |
| |
98 |
TUBE; NYLON
(A)
THA
|
8-98166-040-0 |
01 |
1 |
1403- |
| |
98 |
TUBE; NYLON
(C)
THA
|
8-98175-502-0 |
02 |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=4000 OD=6
THA
|
1-87411-002-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=6000 OD=8
THA
|
1-87411-008-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=8000 OD=8
THA
|
1-87411-009-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=2000 OD=12
THA
|
1-87411-011-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=4000 OD=12
THA
|
1-87411-012-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=6000 OD=12
THA
|
1-87411-013-0 |
AR |
1 |
1403- |
| |
98 |
TUBE; NYLON
(B)
SERVICED BY L=8000 OD=12
THA
|
1-87411-014-0 |
AR |
1 |
1403- |
| |
114 |
UNION; NYLON TUBE
(A)
DIN12 & R3/8 ELBOW
|
1-09660-959-0 |
01 |
1 |
1403- |
| |
114 |
UNION; NYLON TUBE
(B)
|
8-98057-394-1 |
01 |
1 |
1403- |
| |
122 |
CONNECTOR; FLEX HOSE
M20 & PT3/8
|
1-09660-731-1 |
02 |
1 |
1403- |
| |
122 |
CONNECTOR; FLEX HOSE
M20 & PT3/8
|
1-09660-731-1 |
02 |
1 |
1403- |
| |
149 |
BOLT; UNION
M8X20 FLANGE
THA
|
0-28650-820-0 |
01 |
1 |
1403- |
| |
150 |
ADAPTER; CONT,NEUTRAL BUS STOP
(A)
DIN12 & M20 STRAIGHT
|
1-09660-877-0 |
01 |
1 |
1403- |
| |
150 |
ADAPTER; CONT,NEUTRAL BUS STOP
(B)
M20 & RC3/8 STRAIGHT
|
1-09660-883-0 |
01 |
1 |
1403- |
