2 |
DRUM; PARKING BRK
|
1-46211-019-0 |
01 |
1 |
1312- |
| |
8 |
FLANGE; PARKING BRK
|
8-98153-193-0 |
01 |
1 |
1312- |
| |
13 |
BRACE; PARKING BRK
|
9-46239-002-0 |
01 |
1 |
1312-1402 |
| |
13 |
BRACE; PARKING BRK
|
9-46239-002-0 |
01 |
1 |
1403-1405 |
| |
13 |
BRACE; PARKING BRK
|
9-46239-002-0 |
01 |
1 |
1406- |
| |
17 |
SHOE; PARKING BRK
|
1-46220-022-1 |
02 |
1 |
1312-1402 |
| |
17 |
SHOE; PARKING BRK
|
1-46220-022-1 |
02 |
1 |
1403-1405 |
| |
17 |
SHOE; PARKING BRK
|
1-46220-022-1 |
02 |
1 |
1406- |
| |
18 |
LINING; BRK,PARKING
|
1-46225-023-0 |
02 |
1 |
1312-1402 |
| |
18 |
LINING; BRK,PARKING
|
1-46225-023-0 |
02 |
1 |
1403-1405 |
| |
18 |
LINING; BRK,PARKING
|
1-46225-023-0 |
02 |
1 |
1406- |
| |
19 |
RIVET; LINING,PARKING BRK
|
1-09732-058-0 |
32 |
1 |
1312-1402 |
| |
19 |
RIVET; LINING,PARKING BRK
|
1-09732-058-0 |
32 |
1 |
1403-1405 |
| |
19 |
RIVET; LINING,PARKING BRK
|
1-09732-058-0 |
32 |
1 |
1406- |
| |
20 |
SPRING; RETURN,SECONDARY,PARKING BRK
|
9-09942-434-0 |
02 |
1 |
1312-1402 |
| |
20 |
SPRING; RETURN,SECONDARY,PARKING BRK
|
9-09942-434-0 |
02 |
1 |
1403-1405 |
| |
20 |
SPRING; RETURN,SECONDARY,PARKING BRK
|
9-09942-434-0 |
02 |
1 |
1406- |
| |
21 |
SPRING; RETURN,PARKING BRK SHOE
|
9-09942-516-0 |
01 |
1 |
1312-1402 |
| |
21 |
SPRING; RETURN,PARKING BRK SHOE
|
9-09942-516-0 |
01 |
1 |
1403-1405 |
| |
21 |
SPRING; RETURN,PARKING BRK SHOE
|
9-09942-516-0 |
01 |
1 |
1406- |
| |
23 |
SCREW; ADJ,PARKING BRK SHOE
|
1-46240-003-0 |
01 |
1 |
1312-1402 |
| |
23 |
SCREW; ADJ,PARKING BRK SHOE
|
1-46240-003-0 |
01 |
1 |
1403-1405 |
| |
23 |
SCREW; ADJ,PARKING BRK SHOE
|
1-46240-003-0 |
01 |
1 |
1406- |
| |
32 |
PLATE; SUPPORT,PARKING BRK
|
1-46213-039-0 |
01 |
1 |
1312- |
| |
33 |
SHAFT; CAM,PARKING BRK
|
1-46251-010-0 |
01 |
1 |
1312-1402 |
| |
33 |
SHAFT; CAM,PARKING BRK
|
1-46251-010-0 |
01 |
1 |
1403-1405 |
| |
33 |
SHAFT; CAM,PARKING BRK
|
1-46251-010-0 |
01 |
1 |
1406- |
| |
37 |
NUT; SUPPORT PLATE
M14 FLANGE
|
8-97365-444-0 |
04 |
1 |
1312- |
| |
39 |
COVER; DUST,PARKING BRK
|
1-46213-038-0 |
01 |
1 |
1312- |
| |
40 |
LEVER; CM/SHF,PARKING BRK
|
1-46252-046-0 |
01 |
1 |
1312-1402 |
| |
40 |
LEVER; CM/SHF,PARKING BRK
|
1-46252-046-0 |
01 |
1 |
1403-1405 |
| |
40 |
LEVER; CM/SHF,PARKING BRK
|
1-46252-046-0 |
01 |
1 |
1406- |
| |
42 |
SPRING; RETURN,LEVER
|
1-09583-104-0 |
01 |
1 |
1312-1402 |
| |
42 |
SPRING; RETURN,LEVER
|
1-09583-104-0 |
01 |
1 |
1403-1405 |
| |
42 |
SPRING; RETURN,LEVER
|
1-09583-104-0 |
01 |
1 |
1406- |
| |
46 |
WASHER; LEVER
|
9-09855-362-0 |
01 |
1 |
1312-1402 |
| |
46 |
WASHER; LEVER
|
9-09855-362-0 |
01 |
1 |
1403-1405 |
| |
46 |
WASHER; LEVER
|
9-09855-362-0 |
01 |
1 |
1406- |
| |
81 |
COVER; CHECK HOLE,PARKING BRK
|
1-46219-030-0 |
02 |
1 |
1312- |
| |
111 |
BOLT; COVER,CHECK HOLE
M8X20 W/LK WASHER
|
0-50740-820-0 |
02 |
1 |
1312-1402 |
| |
111 |
BOLT; COVER,CHECK HOLE
M8X20 W/LK WASHER
|
0-50740-820-0 |
02 |
1 |
1403- |
| |
114 |
STUD; SUPPORT PLATE
(B)
M14X22 WO/DRY-ROCK
|
8-98014-137-0 |
03 |
1 |
1312- |
| |
114 |
STUD; SUPPORT PLATE
(A)
M14X22 W/DRY-ROCK
|
8-98014-138-0 |
01 |
1 |
1312- |
| |
198 |
BOLT; KNURL
M16X55
|
8-98023-172-0 |
04 |
1 |
1312- |
| |
207 |
BOLT; LEVER
|
8-98061-595-0 |
01 |
1 |
1312- |
| |
208 |
NUT; LEVER
M10
|
0-91111-510-0 |
01 |
1 |
1312- |
| |
209 |
WASHER; SP,LEVER
ID=10.2
|
0-91510-510-0 |
01 |
1 |
1312- |
