1 |
CABLE; BATTERY
L=280
THA
|
8-97922-383-0 |
01 |
1 |
1402- |
| |
2 |
CABLE; BATTERY
L=305
THA
|
8-97924-521-1 |
01 |
1 |
1402- |
| |
8 |
CABLE; BATTERY,STARTER
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
L=2435
THA
|
8-97925-466-0 |
01 |
1 |
1402-1404 |
| |
8 |
CABLE; BATTERY,STARTER
6HK1-TCS ENG<80L>
ZF9S1110 M/T<Y5E>
WHEEL BASE 5500MM<55W>,WHEEL BASE 6300MM<63W>
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
L=2435
THA
|
8-97925-466-0 |
01 |
1 |
1405- |
| |
8 |
CABLE; BATTERY,STARTER
6HK1-TCN ENG<82L>
MZW6P M/T<RSZ>
WHEEL BASE 5500MM<55W>,WHEEL BASE 5800MM<58W>,
WHEELBASE 6300MM<63W>
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
L=2435
THA
|
8-97925-466-0 |
01 |
1 |
1405- |
| |
8 |
CABLE; BATTERY,STARTER
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
THA
|
8-97926-440-0 |
01 |
1 |
1402-1404 |
| |
8 |
CABLE; BATTERY,STARTER
6HK1-TCN ENG<82L>
MZW6P M/T<RSZ>
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
THA
|
8-97926-440-0 |
01 |
1 |
1405- |
| |
8 |
CABLE; BATTERY,STARTER
WHEEL BASE 5800MM<58W>,WHEEL BASE 6300MM<63W>,
WHEELBASE 7100MM<71W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
THA
|
8-97926-441-0 |
01 |
1 |
1402-1404 |
| |
8 |
CABLE; BATTERY,STARTER
6HK1-TCN ENG<82L>
MZW6P M/T<RSZ>
WHEEL BASE 5800MM<58W>,WHEEL BASE 6300MM<63W>,
WHEELBASE 7100MM<71W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
THA
|
8-97926-441-0 |
01 |
1 |
1405- |
| |
10 |
BOLT; BATTERY CABLE CLIP
M10X25 W/LK&PL WASHER
|
8-97087-205-0 |
01 |
1 |
1402- |
| |
11 |
WASHER; BATTERY CABLE EARTH
ID=10.5 OD=22 T=2.0
|
1-09503-265-0 |
01 |
1 |
1402- |
| |
12 |
NUT; BATTERY CABLE CLIP
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8 FLANGE
THA
|
0-91180-108-0 |
03 |
1 |
1402- |
| |
12 |
NUT; BATTERY CABLE CLIP
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
M8 FLANGE
THA
|
0-91180-108-0 |
04 |
1 |
1402- |
| |
12 |
NUT; BATTERY CABLE CLIP
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8 FLANGE
THA
|
0-91180-108-0 |
01 |
1 |
1402- |
| |
13 |
GROMMET; BATTERY CABLE
ID=32 OD=40 T=23
|
1-09332-112-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
(A)
|
8-98044-882-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(C)
L=145
|
1-47475-655-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(C)
L=95
|
1-82699-085-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(D)
|
8-98201-024-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(C)
L=95
|
1-82699-085-0 |
03 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(E)
|
8-98201-025-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(B)
L=55
|
1-47475-304-0 |
01 |
1 |
1402- |
| |
23 |
BRACKET; CABLE CLIP TO FRAME
(B)
L=55
|
1-47475-304-0 |
01 |
1 |
1402- |
| |
24 |
BOLT; BRKT TO FRAME
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8X30 FLANGE
THA
|
0-28650-830-0 |
03 |
1 |
1402- |
| |
24 |
BOLT; BRKT TO FRAME
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
M8X30 FLANGE
THA
|
0-28650-830-0 |
04 |
1 |
1402- |
| |
24 |
BOLT; BRKT TO FRAME
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8X25 FLANGE
THA
|
0-28650-825-0 |
01 |
1 |
1402- |
| |
28 |
NUT; BRKT TO FRAME
M8 FLANGE
THA
|
0-91180-108-0 |
02 |
1 |
1402- |
| |
28 |
NUT; BRKT TO FRAME
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8 FLANGE
THA
|
0-91180-108-0 |
03 |
1 |
1402- |
| |
28 |
NUT; BRKT TO FRAME
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
M8 FLANGE
THA
|
0-91180-108-0 |
04 |
1 |
1402- |
| |
28 |
NUT; BRKT TO FRAME
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
M8 FLANGE
THA
|
0-91180-108-0 |
01 |
1 |
1402- |
| |
33 |
CAP; INSULATOR
|
1-82699-431-0 |
01 |
1 |
1402- |
| |
57 |
WASHER; PL,BATTERY CABLE
ID=10.5 OD=22 T=1.6
|
0-91610-610-0 |
01 |
1 |
1402-1402 |
| |
79 |
CLIP; BATTERY CABLE
(A)
ID=19 L=24 H=21
|
1-09700-109-1 |
01 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(A)
ID=19 L=24 H=21
|
1-09700-109-1 |
01 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
(E)
ID=16 L=28
|
1-09700-872-0 |
01 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(D)
ID=13-18 L=26
|
1-09709-293-0 |
03 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(B)
ID=21 L=24
|
8-98019-191-0 |
02 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(C)
ID=20 L=70
|
1-09700-485-0 |
01 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(D)
ID=13-18 L=26
|
1-09709-293-0 |
02 |
1 |
1402- |
| |
79 |
CLIP; BATTERY CABLE
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(B)
ID=21 L=24
|
8-98019-191-0 |
03 |
1 |
1402- |
| |
80 |
BOLT; BATTERY CABLE CLIP
(B)
M8X16 FLANGE
THA
|
0-28050-816-0 |
01 |
1 |
1402- |
| |
80 |
BOLT; BATTERY CABLE CLIP
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(A)
M8X25 FLANGE
THA
|
0-28650-825-0 |
02 |
1 |
1402- |
| |
80 |
BOLT; BATTERY CABLE CLIP
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(A)
M8X25 FLANGE
THA
|
0-28650-825-0 |
01 |
1 |
1402- |
| |
80 |
BOLT; BATTERY CABLE CLIP
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
(A)
M8X25 FLANGE
THA
|
0-28650-825-0 |
01 |
1 |
1402- |
| |
80 |
BOLT; BATTERY CABLE CLIP
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
(A)
M8X25 FLANGE
THA
|
0-28650-825-0 |
04 |
1 |
1402- |
| |
107 |
CLIP; BAND
L=140
THA
|
8-97920-656-0 |
01 |
1 |
1402- |
| |
217 |
CLIP; BAND,CABLE
MZW6P M/T<RSZ>
BRAKE SYSTEM FULL AIR DUAL CIRCUIT<Z06>
L=250
|
5-09707-030-1 |
01 |
1 |
1402- |
| |
217 |
CLIP; BAND,CABLE
WHEEL BASE 5500MM<55W>
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT<Z05>
L=250
|
5-09707-030-1 |
01 |
1 |
1402- |
| |
222 |
BOLT; EARTH CABLE
M10X25 W/LK&PL WASHER
|
8-97087-205-0 |
01 |
1 |
1402- |
| |
223 |
NUT; EARTH CABLE
M10 FLANGE
THA
|
0-91180-210-0 |
01 |
1 |
1402- |
