Sayfa 3-25 - Isuzu EPC

22 22 12 21 23 23

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
12	BOLT; CONT VALVE,BRK LOCK POWER BRAKE LOCK SYSTEM(J50) M8X20 FLANGE	0-28680-820-0	02	1	0105-0508	●	●
21	BRACKET; CONT VLV,BRK LOCK POWER BRAKE LOCK SYSTEM(J50)	1-82569-283-1	01	1	0105-0508	●	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (A) M8X30 FLANGE	0-28680-830-0	02	1	0105-0508	●	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (B) M10X30 FLANGE	0-28681-030-0	02	1	0105-0508	●	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (A) M8 FLANGE	0-91150-108-0	02	1	0105-0508	●	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (B) M10 FLANGE	0-91150-210-0	02	1	0105-0508	●	●

32 32 32 32 32 26 1 30

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	BOX; CONT,BRK LOCK POWER BRAKE LOCK SYSTEM(J50)	1-82550-311-0	01	1	0105-0508	●	●
26	UNION; CONT VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AIR DRYER<PS7> M22 & PT3/4 ELBOW	1-09650-277-0	01	1	0105-	●	●
30	NUT POWER BRAKE LOCK SYSTEM(J50) M6 FLANGE	0-91150-106-0	02	1	0105-0508	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) PE-SERIES ENG<1A0> (A) DIN12 & R3/8 ELBOW	1-09660-959-0	01	1	0105-0108	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) PE-SERIES ENG<1A0> (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0105-0108	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) NEW ZEALAND EQUIPMENT(PK5) (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0105-0108	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) NEW ZEALAND EQUIPMENT(PK5) (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0109-	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) NEW ZEALAND EQUIPMENT(PK5) (A) DIN12 & R3/8 ELBOW	1-09660-959-0	04	1	0105-	●	●
