Isuzu WW
▶
SUV
▶
UCR
▶
51506 - UCR RHD (INDIA)
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-55 - REAR DOOR TRIM
▶
6-55 — REAR DOOR TRIM
(#132651) — 39 parça
◀
[655A] NO.1 (25 parça)
[655A] NO.2 (14 parça)
▶
86
3
1
6
89
87
13
62
10
88
49
88
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
PAD; TRIM,RR DOOR
CLOTH TRIM COVER<7PG> BEIGE
8-97404-654-0
01
1
1312-
1
PAD; TRIM,RR DOOR
CLOTH TRIM COVER<7PG> BEIGE
8-97404-655-0
01
1
1312-
1
PAD; TRIM,RR DOOR
EXC. CLOTH TRIM COVER<7PG> BEIGE
8-97406-960-0
01
1
1312-
1
PAD; TRIM,RR DOOR
EXC. CLOTH TRIM COVER<7PG> BEIGE
8-97406-961-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(A)
8-97357-593-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(A)
8-97357-594-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(B) BEIGE
8-97404-644-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(B) BEIGE
8-97404-645-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(C)
8-97357-587-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(C)
8-97357-588-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(D)
8-97357-595-3
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(D)
8-97357-596-3
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(E)
8-97357-599-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(E)
8-97357-600-1
01
1
1312-
6
CLIP; DOOR PAD
8-97182-223-0
48
1
1312-
10
SCREW; ARM REST
M5X14
8-94152-495-0
04
1
1312-
13
GROMMET; SCREW,ARM REST
IMA
8-94152-494-0
04
1
1312-
49
SEAL; DOOR
OD=25 BLACK IMA
1-76798-019-0
02
1
1312-
62
BRACKET
8-93358-284-2
01
1
1312-
62
BRACKET
8-93358-285-2
01
1
1312-
86
DRINK HOLDER
BEIGE
8-97405-978-3
02
1
1312-
87
DEFLECTOR; RR DOOR
8-97357-247-1
01
1
1312-
87
DEFLECTOR; RR DOOR
8-97357-248-1
01
1
1312-
88
PLUG; DOOR
8-98009-500-0
04
1
1312-
89
RETAINER; RR DOOR
H=16.7
8-97022-017-0
14
1
1312-
3
3
3
3
45
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
3
WEATHERSTRIP; RR DOOR
(A)
8-97357-593-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(A)
8-97357-594-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(B) BEIGE
8-97404-644-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(B) BEIGE
8-97404-645-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(C)
8-97357-587-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(C)
8-97357-588-0
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(D)
8-97357-595-3
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(D)
8-97357-596-3
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(E)
8-97357-599-1
01
1
1312-
3
WEATHERSTRIP; RR DOOR
(E)
8-97357-600-1
01
1
1312-
45
FINISHER; RR DOOR
BODY SIDE MOLDING CHROME<8NL>
8-98152-893-0
01
1
1312-
45
FINISHER; RR DOOR
BODY SIDE MOLDING CHROME<8NL>
8-98152-894-0
01
1
1312-
45
FINISHER; RR DOOR
EXC. BODY SIDE MOLDING CHROME<8NL>
8-97357-591-0
01
1
1312-
45
FINISHER; RR DOOR
EXC. BODY SIDE MOLDING CHROME<8NL>
8-97357-592-0
01
1
1312-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
