Isuzu WW
▶
TRUCKS
▶
NLR
▶
51502 - NLR(MALAYSIA)
▶
4 - Propeller Shaft, Axles, Steering, Suspension
▶
4-31 - STEERING COLUMN AND SHAFT
▶
4-31 — STEERING COLUMN AND SHAFT
(#132485) — 30 parça
103
105
236
102
103
105
102
66
348
148
2
104
172
1
96
66
172
148
33
35
203
348
95
251
251
79
291
231
291
66
296
20
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
STEERING UNIT
SEE FIG-NO 4-40 FOR COMPONENT.
8-98101-297-3
01
1
1401-
2
SHAFT ASM; STRG
MANUAL TILT CAB<RWZ> BLACK
8-97418-801-2
01
1
1401-
2
SHAFT ASM; STRG
EXC. MANUAL TILT CAB<RWZ> BLACK
8-97405-355-8
01
1
1401-
20
COVER; STRG SHAFT
EXC. MANUAL TILT CAB<RWZ> BLACK
8-97405-159-0
01
1
1401-
33
BOLT; STRG SHAFT TO UNIT
M8X30
8-97359-615-0
01
1
1401-
35
WASHER; LK,STRG SHAFT
ID=8.2
0-91510-808-0
01
1
1401-
66
BOLT; STRG COLUMN
(B) M8X20 FLANGE MAL
0-28650-820-0
02
1
1401-
66
BOLT; STRG COLUMN
(A) M5X18 TAPPING MAL
0-72180-518-0
04
1
1401-
66
BOLT; STRG COLUMN
(B) M8X24.5 W/LK&PL WASHER MAL
8-98051-939-0
02
1
1401-
79
CLIP; STRG COLUMN COVER
L=19 BLACK
8-94363-776-0
02
1
1401-
95
BOLT; STRG UNIT
M12X47 FLANGE
8-98055-055-0
04
1
1401-
96
NUT; STRG UNIT
M12 FLANGE
8-97359-618-0
02
1
1401-
102
LOCK ASM; STRG
4JB1-TC ENG(RDT) (B)
8-98006-150-0
01
1
1401-
102
LOCK ASM; STRG
4JJ1-TCC ENG(RDU) (A)
8-97387-036-0
01
1
1402-
103
SWITCH; IGNITION
8-98045-349-0
01
1
1401-
104
BOLT; STRG LOCK TO COLUMN
M8X20 TORQUE SHEAR BOLT
8-97321-385-0
02
1
1401-
105
SCREW; IGN SW
8-98045-346-0
02
1
1401-
148
NUT; COLUMN TO BRKT
M8 W/DISHED WASHER MAL
8-97329-625-0
03
1
1401-
172
BRACKET; STRG
(B)
8-98055-061-0
01
1
1401-
172
BRACKET; STRG
(A)
8-98078-803-0
01
1
1401-
203
BOOT; STRG COLUMN LWR
8-98137-331-0
01
1
1401-
231
SEAL; RUBBER,STRG COLUMN
8-98137-329-0
01
1
1401-
236
SWITCH; DOOR WARNING,STRG LOCK
4JJ1-TCC ENG(RDU)
8-98045-350-0
01
1
1402-
251
COVER; LWR
MANUAL TILT CAB<RWZ> (B) BLACK
8-97418-804-0
01
1
1401-
251
COVER; LWR
EXC. MANUAL TILT CAB<RWZ> (A) BLACK
8-97417-049-0
01
1
1401-
291
GROMMET; STRG SHAFT COVER
(A) H=15 MAL
8-94463-268-1
04
1
1401-
291
GROMMET; STRG SHAFT COVER
(B)
8-98029-442-1
02
1
1401-
296
CLIP; COVER
EXC. MANUAL TILT CAB<RWZ> BLACK
8-97868-409-0
01
1
1401-
348
CLIP; BRKT,STRG
(A) ID=5-12 L=18
1-09709-287-0
01
1
1401-
348
CLIP; BRKT,STRG
(B) ID=5-12 L=22
1-09709-288-0
01
1
1401-
