24 |
CLIP; FUEL HOSE
FUEL TANK 400L<SDH>
ID=20 L=70
|
1-09701-033-0 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
FUEL TANK 400L<SDH>
(D)
L=920
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(D)
L=900
|
8-98157-879-0 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
WHEEL BASE 5800MM(58W)
FUEL TANK 200L FRAME SIDE<N20>
(D)
L=730
|
8-98205-834-0 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
FUEL TANK 400L<SDH>
(C)
L=60
SERVICED BY L=3000
|
0-01259-300-0 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
(A)
|
8-98078-196-2 |
01 |
1 |
1401- |
| |
29 |
HOSE; FUEL
(B)
|
8-98078-197-1 |
01 |
1 |
1401- |
| |
39 |
PIPE; FUEL
FUEL TANK 400L<SDH>
(A)
|
8-98009-438-1 |
01 |
1 |
1401- |
| |
39 |
PIPE; FUEL
(B)
NPTF3/8-18 OD=10
|
8-98122-953-0 |
02 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 400L<SDH>
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
02 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(E)
L=250
|
5-09707-030-1 |
02 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5800MM(58W)
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(F)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5800MM(58W)
(F)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
WHEEL BASE 5800MM(58W)
FUEL TANK 200L FRAME SIDE<N20>
(E)
L=250
|
5-09707-030-1 |
05 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(C)
ID=14
|
1-09704-102-0 |
06 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(D)
ID=16
|
8-94238-568-0 |
02 |
1 |
1401- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=13
|
8-94238-571-0 |
06 |
1 |
1401- |
| |
47 |
PIPE; FUEL,RETURN
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=539
|
8-98117-709-0 |
01 |
1 |
1401- |
| |
47 |
PIPE; FUEL,RETURN
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(B)
L=688
|
8-98129-921-0 |
01 |
1 |
1401- |
| |
47 |
PIPE; FUEL,RETURN
WHEEL BASE 5800MM(58W)
(B)
L=688
|
8-98129-921-0 |
01 |
1 |
1401- |
| |
55 |
COVER; PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
02 |
1 |
1401- |
| |
55 |
COVER; PIPE,FUEL TANK
FUEL TANK 400L<SDH>
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
03 |
1 |
1401- |
| |
62 |
BOLT; CLIP FIX
FUEL TANK 400L<SDH>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1401- |
| |
64 |
NUT; CLIP
FUEL TANK 400L<SDH>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1401- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
FUEL TANK 400L<SDH>
L=1600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1401- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
L=300
|
8-98157-878-0 |
01 |
1 |
1401- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
WHEEL BASE 5800MM(58W)
FUEL TANK 200L FRAME SIDE<N20>
L=1380
|
8-98186-528-0 |
01 |
1 |
1401- |
| |
80 |
BOLT; CLIP,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(B)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1401- |
| |
80 |
BOLT; CLIP,FUEL TANK
WHEEL BASE 5800MM(58W)
(B)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1401- |
| |
80 |
BOLT; CLIP,FUEL TANK
(A)
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1401- |
| |
83 |
NUT; CLIP,FUEL TANK
FUEL TANK 400L<SDH>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
1401- |
| |
83 |
NUT; CLIP,FUEL TANK
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1401- |
| |
83 |
NUT; CLIP,FUEL TANK
WHEEL BASE 5800MM(58W)
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(D)
|
8-98126-612-0 |
01 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(A)
L=50
|
1-47475-299-2 |
01 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
WHEEL BASE 5800MM(58W)
(A)
L=50
|
1-47475-299-2 |
01 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(C)
|
8-98129-922-0 |
01 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
WHEEL BASE 5800MM(58W)
(C)
|
8-98129-922-0 |
01 |
1 |
1401- |
| |
97 |
BRACKET; CLIP
(B)
|
8-98053-654-0 |
01 |
1 |
1401- |
| |
124 |
CLIP; HOSE
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
L=250
|
5-09707-030-1 |
01 |
1 |
1401- |
| |
174 |
PIPE; FUEL,FEED,FRT
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=548
|
8-98117-708-0 |
01 |
1 |
1401- |
| |
174 |
PIPE; FUEL,FEED,FRT
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(B)
L=685
|
8-98129-920-0 |
01 |
1 |
1401- |
| |
174 |
PIPE; FUEL,FEED,FRT
WHEEL BASE 5800MM(58W)
(B)
L=685
|
8-98129-920-0 |
01 |
1 |
1401- |
| |
303 |
BOLT; BRKT
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(A)
M10X35 FLANGE
|
0-28651-035-0 |
02 |
1 |
1401- |
| |
303 |
BOLT; BRKT
WHEEL BASE 5000MM(50W)
FUEL TANK 400L<SDH>
(B)
M8X35 FLANGE
|
0-28650-835-0 |
02 |
1 |
1401- |
| |
303 |
BOLT; BRKT
WHEEL BASE 5800MM(58W)
(B)
M8X35 FLANGE
|
0-28650-835-0 |
02 |
1 |
1401- |
| |
304 |
NUT; BRKT
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1401- |
| |
304 |
NUT; BRKT
(A)
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
1401- |
| |
304 |
NUT; BRKT
(B)
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1401- |
| |
373 |
CLAMP; HOSE,FUEL
FUEL TANK 400L<SDH>
ID=16
|
8-94238-568-0 |
02 |
1 |
1401- |
| |
623 |
PLATE; STUD BOLT
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
|
8-98126-633-0 |
01 |
1 |
1401- |
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 400L<SDH>
L=800
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1401- |
| |
634 |
HOSE; RUBBER RETURN
WHEEL BASE 5000MM(50W)
FUEL TANK 200L FRAME SIDE<N20>
L=1050
|
8-98128-212-0 |
01 |
1 |
1401- |
| |
634 |
HOSE; RUBBER RETURN
WHEEL BASE 5800MM(58W)
FUEL TANK 200L FRAME SIDE<N20>
L=810
|
8-98186-973-0 |
01 |
1 |
1401- |
