◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FVZ ▶ 11567 - FVZ/GVZ(INDONESIA) ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#131734) — 21 parça
çizim 389339
6 309 309 160 35 49
BalonParca AdiParca NoAdetTipApplied Date A B
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR(P10) IDN 		8-98082-437-0 01 1 1312-1403 ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR(P10) IDN 		8-98082-437-0 01 1 1404- ●
6 PLATE; CAUTION,SPARE TIRE
SPARE TIRE CARRIER LIFTING TYPE VAR1(SY8) IDN 		8-98082-437-0 01 1 1404- ●
35 PLATE; CAUTION,CAB
IDN 		8-98065-363-0 01 1 1312-1403 ●
35 PLATE; CAUTION,CAB
IDN 		8-98065-363-0 01 1 1404- ● ●
49 PLATE; CAUTION,FUSE BOX
IDN 		8-98122-353-0 01 1 1312-1403 ●
49 PLATE; CAUTION,FUSE BOX
IDN 		8-98122-353-0 01 1 1404- ● ●
160 PLATE; CAUTION,TOWING
IDN 		1-85888-737-1 01 1 1312-1403 ●
160 PLATE; CAUTION,TOWING
IDN 		1-85888-737-1 01 1 1404- ● ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) (A) 		1-85881-598-0 01 1 1312-1401 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) EXC. POWER TAKE OFF-FLYWHEEL(6SZ) (A) 		1-85881-598-0 01 1 1402-1403 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) EXC. POWER TAKE OFF-FLYWHEEL(6SZ) (A) 		1-85881-598-0 01 1 1404- ●
309 LABEL; M/T SHIFT
(A) 		1-85881-598-0 01 1 1404- ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) (B) 		8-98098-606-0 01 1 1312-1401 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) (B) 		8-98098-606-0 01 1 1312-1401 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) (B) 		8-98098-606-0 01 1 1402-1403 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) EXC. POWER TAKE OFF-FLYWHEEL(6SZ) (B) 		8-98098-606-0 01 1 1402-1403 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) (B) 		8-98098-606-0 01 1 1404-1404 ●
309 LABEL; M/T SHIFT
FULLER ES11109 DD M/T(Y5N) EXC. POWER TAKE OFF-FLYWHEEL(6SZ) (B) 		8-98098-606-0 01 1 1404-1404 ●
309 LABEL; M/T SHIFT
(B) 		8-98098-606-0 01 1 1404-1404 ●
309 LABEL; M/T SHIFT
(B) 		8-98098-606-0 01 1 1404-1404 ●
