Isuzu WW
▶
TRUCKS
▶
NPR
▶
51501 - NPR(MALAYSIA)
▶
0 - Engine, Emission, Engine Electrical
▶
0-41 - FUEL FILTER AND BRACKET
▶
0-41 — FUEL FILTER AND BRACKET
(#130802) — 78 parça
Tümü
A - 4HG1-T ENG
B - 4HK1-TCN ENG
◀
[041A] 4HG1 (32 parça)
[041A] 4HK1(NO.2) (27 parça)
[041A] 4HK1(NO.1) (19 parça)
▶
42
92
93
8
2
46
43
1
5
1
40
62
88
2
8
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
FILTER ASM; FUEL
(A)
8-97171-451-2
01
1
1311-
●
1
FILTER ASM; FUEL
FUEL FILTER DUAL(S6B) (B)
8-98006-454-0
01
1
1311-
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1312-1412
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1501-
●
●
1
FILTER ASM; FUEL
(C)
8-98162-903-3
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A)
8-97172-549-1
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
FUEL FILTER DUAL(S6B) (B)
8-97916-993-2
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1312-1412
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1501-
●
●
2
ELEMENT KIT; FUEL FILTER
(C)
8-98203-599-0
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(C) BEST VALUE PARTS
1-87610-093-1
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A) BEST VALUE PARTS
5-87610-041-0
01
1
1311-
●
5
BOLT; FUEL FILTER
FUEL FILTER DUAL(S6B) M10X40 FLANGE MAL
0-28651-040-0
02
1
1311-
●
8
COVER; FUEL FILTER
(A)
8-97172-543-1
01
1
1311-
●
8
COVER; FUEL FILTER
FUEL FILTER DUAL(S6B) (B)
8-97917-558-0
01
1
1311-
●
40
BRACKET; FUEL FILTER
(A)
8-98121-710-0
01
1
1311-1412
●
40
BRACKET; FUEL FILTER
FRAME STRAIGHT TYPE<7KJ> EXC. POOR QUALITY DIESEL FUEL(KF0) (A)
8-98121-710-0
01
1
1501-
●
40
BRACKET; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (B)
8-98107-354-3
01
1
1312-1405
●
40
BRACKET; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) EXC. VIN MODEL YEAR 2015<VZF> (B)
8-98107-354-3
01
1
1406-
●
42
BOLT; FUEL FILTER
M10X30 FLANGE
0-28751-030-0
02
1
1311-
●
43
BOLT; BRKT
M12X28 FLANGE
0-28181-228-0
02
1
1311-
●
46
BRACKET
8-97061-452-0
01
1
1311-
●
62
NUT; FUEL FILTER
FUEL FILTER DUAL(S6B) M10 FLANGE MAL
0-91180-110-0
02
1
1311-1311
●
62
NUT; FUEL FILTER
FUEL FILTER DUAL(S6B) M10 FLANGE MAL
0-91180-110-0
02
1
1312-
●
62
NUT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) M10 FLANGE MAL
0-91180-110-0
02
1
1312-
●
88
BOLT; BRKT,FUEL FILTER
M10X30 FLANGE
0-28651-030-0
02
1
1311-1311
●
88
BOLT; BRKT,FUEL FILTER
EXC. POOR QUALITY DIESEL FUEL(KF0) M10X30 FLANGE
0-28651-030-0
02
1
1312-
●
88
BOLT; BRKT,FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) M10X30 FLANGE
0-28651-030-0
02
1
1312-
●
92
CAP; FUEL FILTER
8-97172-548-0
01
1
1311-
●
92
CAP; FUEL FILTER
8-98034-314-0
01
1
1312-
●
93
CONNECTOR; FUEL FILTER
8-97172-546-1
01
1
1311-
●
93
CONNECTOR; FUEL FILTER
M8X10
8-98034-312-0
01
1
1312-
●
131
131
2
1
136
40
88
62
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
FILTER ASM; FUEL
(A)
8-97171-451-2
01
1
1311-
●
1
FILTER ASM; FUEL
FUEL FILTER DUAL(S6B) (B)
8-98006-454-0
01
1
1311-
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1312-1412
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1501-
●
●
1
FILTER ASM; FUEL
(C)
8-98162-903-3
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A)
8-97172-549-1
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
FUEL FILTER DUAL(S6B) (B)
8-97916-993-2
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1312-1412
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1501-
●
●
2
ELEMENT KIT; FUEL FILTER
(C)
8-98203-599-0
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(C) BEST VALUE PARTS
1-87610-093-1
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A) BEST VALUE PARTS
5-87610-041-0
01
1
1311-
●
40
BRACKET; FUEL FILTER
(A)
8-98121-710-0
01
1
1311-1412
●
40
BRACKET; FUEL FILTER
FRAME STRAIGHT TYPE<7KJ> EXC. POOR QUALITY DIESEL FUEL(KF0) (A)
8-98121-710-0
01
1
1501-
●
40
BRACKET; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (B)
8-98107-354-3
01
1
1312-1405
●
40
BRACKET; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) EXC. VIN MODEL YEAR 2015<VZF> (B)
8-98107-354-3
01
1
1406-
●
62
NUT; FUEL FILTER
FUEL FILTER DUAL(S6B) M10 FLANGE MAL
0-91180-110-0
02
1
1311-1311
●
62
NUT; FUEL FILTER
FUEL FILTER DUAL(S6B) M10 FLANGE MAL
0-91180-110-0
02
1
1312-
●
62
NUT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) M10 FLANGE MAL
0-91180-110-0
02
1
1312-
●
88
BOLT; BRKT,FUEL FILTER
M10X30 FLANGE
0-28651-030-0
02
1
1311-1311
●
88
BOLT; BRKT,FUEL FILTER
EXC. POOR QUALITY DIESEL FUEL(KF0) M10X30 FLANGE
0-28651-030-0
02
1
1312-
●
88
BOLT; BRKT,FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) M10X30 FLANGE
0-28651-030-0
02
1
1312-
●
131
PIPE; FILTER
POOR QUALITY DIESEL FUEL(KF0) NPTF3/8-18 OD=10
8-98122-953-0
02
1
1312-1412
●
131
PIPE; FILTER
POOR QUALITY DIESEL FUEL(KF0) NPTF3/8-18 OD=10
8-98122-953-0
02
1
1501-
●
●
136
CAP KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0)
8-98096-004-0
01
1
1312-1408
●
136
CAP KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0)
8-98279-324-0
01
1
1409-1412
●
136
CAP KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0)
8-98279-324-0
01
1
1501-
●
●
1
93
92
11
114
119
2
11
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
FILTER ASM; FUEL
(A)
8-97171-451-2
01
1
1311-
●
1
FILTER ASM; FUEL
FUEL FILTER DUAL(S6B) (B)
8-98006-454-0
01
1
1311-
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1312-1412
●
1
FILTER ASM; FUEL
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-980-1
01
1
1501-
●
●
1
FILTER ASM; FUEL
(C)
8-98162-903-3
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A)
8-97172-549-1
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
FUEL FILTER DUAL(S6B) (B)
8-97916-993-2
01
1
1311-
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1312-1412
●
2
ELEMENT KIT; FUEL FILTER
POOR QUALITY DIESEL FUEL(KF0) (D)
8-98095-983-0
01
1
1501-
●
●
2
ELEMENT KIT; FUEL FILTER
(C)
8-98203-599-0
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(C) BEST VALUE PARTS
1-87610-093-1
01
1
1312-
●
2
ELEMENT KIT; FUEL FILTER
(A) BEST VALUE PARTS
5-87610-041-0
01
1
1311-
●
11
GASKET; CASE TO BODY,FUEL FILTER
8-98203-600-0
01
1
1312-
●
92
CAP; FUEL FILTER
8-97172-548-0
01
1
1311-
●
92
CAP; FUEL FILTER
8-98034-314-0
01
1
1312-
●
93
CONNECTOR; FUEL FILTER
8-97172-546-1
01
1
1311-
●
93
CONNECTOR; FUEL FILTER
M8X10
8-98034-312-0
01
1
1312-
●
114
CASE ASM; FUEL FILTER
8-98039-987-1
01
1
1312-
●
119
PLUG; DRAIN,FUEL FILTER
8-98037-095-0
01
1
1312-
●
