3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
EXC. STEERING WHEEL LEATHER<NP5>,STRG WHL AUDIO
CONTROL SW<8NE>
BLACK
THA
|
8-97416-797-3 |
01 |
1 |
1410- |
● |
|
| |
3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
STRG WHL AUDIO CONTROL SW<8NE>
BLACK
THA
|
8-97424-481-0 |
01 |
1 |
1310- |
● |
|
| |
3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STRG WHL AUDIO CONTROL SW<8NE>
BLACK
THA
|
8-97424-481-0 |
01 |
1 |
1310- |
|
● |
| |
3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
EXC. STRG WHL AUDIO CONTROL SW<8NE>
BLACK
THA
|
8-97424-479-0 |
01 |
1 |
1310- |
● |
|
| |
3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
EXC. STRG WHL AUDIO CONTROL SW<8NE>
BLACK
THA
|
8-97424-479-0 |
01 |
1 |
1310- |
|
● |
| |
3 |
WHEEL; STRG
AIR BAG DRIVER & PASSENGER DELETE<AK6>
BLACK
THA
|
8-97416-799-3 |
01 |
1 |
1310- |
● |
|
| |
5 |
NUT; STRG WHEEL TO SHAFT
M12 W/TOOTH WASHER
IMA
|
8-94455-487-1 |
01 |
1 |
1310- |
● |
● |
| |
20 |
SHROUD; PAD,STRG WHEEL
AIR BAG DRIVER & PASSENGER DELETE<AK6>
BLACK
THA
|
8-97416-804-4 |
01 |
1 |
1310- |
● |
|
| |
30 |
COWL; STEERING
IMMOBILIZER SYSTEM<7KC>
(B)
BLACK
THA
|
8-97416-794-6 |
01 |
1 |
1310- |
● |
● |
| |
30 |
COWL; STEERING
(A)
BLACK
THA
|
8-97416-863-4 |
01 |
1 |
1310- |
● |
● |
| |
30 |
COWL; STEERING
EXC. IMMOBILIZER SYSTEM<7KC>
(B)
BLACK
THA
|
8-97416-795-6 |
01 |
1 |
1310- |
● |
● |
| |
37 |
SCREW; STRG COWL UPR
(A)
M4X12 W/PL WASHER
THA
|
0-36210-412-0 |
01 |
1 |
1310- |
● |
● |
| |
37 |
SCREW; STRG COWL UPR
(B)
M5X16 TAPPING
THA
|
8-98167-449-0 |
02 |
1 |
1310- |
● |
● |
| |
54 |
CLIP; HARNESS
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
THA
|
8-98165-703-0 |
01 |
1 |
1310-1409 |
● |
|
| |
54 |
CLIP; HARNESS
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
THA
|
8-98165-703-0 |
01 |
1 |
1310-1409 |
|
● |
| |
54 |
CLIP; HARNESS
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
EXC. STEERING WHEEL LEATHER<NP5>,STRG WHL AUDIO
CONTROL SW<8NE>
THA
|
8-98165-703-0 |
01 |
1 |
1410- |
● |
|
| |
54 |
CLIP; HARNESS
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
THA
|
8-98165-703-0 |
01 |
1 |
1410- |
● |
|
| |
54 |
CLIP; HARNESS
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
THA
|
8-98165-703-0 |
01 |
1 |
1410- |
|
● |
| |
83 |
SCREW; LWR COVER TO WHEEL
M4X10 TAPPING
THA
|
0-71240-410-0 |
02 |
1 |
1310- |
● |
● |
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
BLACK
THA
|
8-97416-856-1 |
01 |
1 |
1310-1409 |
● |
|
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
BLACK
THA
|
8-97416-856-1 |
01 |
1 |
1310-1409 |
|
● |
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
EXC. STEERING WHEEL LEATHER<NP5>,STRG WHL AUDIO
CONTROL SW<8NE>
BLACK
THA
|
8-97416-856-1 |
01 |
1 |
1410- |
● |
|
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
BLACK
THA
|
8-97416-856-1 |
01 |
1 |
1410- |
● |
|
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
BLACK
THA
|
8-97416-856-1 |
01 |
1 |
1410- |
|
● |
| |
90 |
COVER ASM; STRG WHEEL,LWR
AIR BAG DRIVER & PASSENGER DELETE<AK6>
EXC. STEERING WHEEL LEATHER<NP5>,STRG WHL AUDIO
CONTROL SW<8NE>
BLACK
THA
|
8-97416-859-2 |
01 |
1 |
1310- |
● |
|
| |
100 |
HARNESS; STRG WHEEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
STRG WHL AUDIO CONTROL SW<8NE>
THA
|
8-98108-695-0 |
01 |
1 |
1310- |
● |
|
| |
100 |
HARNESS; STRG WHEEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STRG WHL AUDIO CONTROL SW<8NE>
THA
|
8-98108-695-0 |
01 |
1 |
1310- |
|
● |
| |
102 |
SWITCH ASM; AUDIO CONT,STRG WHEEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
STRG WHL AUDIO CONTROL SW<8NE>
THA
|
8-98196-493-0 |
01 |
1 |
1310- |
● |
|
| |
102 |
SWITCH ASM; AUDIO CONT,STRG WHEEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STRG WHL AUDIO CONTROL SW<8NE>
THA
|
8-98196-493-0 |
01 |
1 |
1310- |
|
● |
| |
103 |
BEZEL; COVER,SWITCH HOLE
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
(A)
THA
|
8-98196-497-0 |
01 |
1 |
1310- |
● |
|
| |
103 |
BEZEL; COVER,SWITCH HOLE
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
(A)
THA
|
8-98196-497-0 |
01 |
1 |
1310- |
|
● |
| |
103 |
BEZEL; COVER,SWITCH HOLE
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
EXC. STRG WHL AUDIO CONTROL SW<8NE>
(B)
THA
|
8-98196-496-0 |
01 |
1 |
1310- |
● |
|
| |
103 |
BEZEL; COVER,SWITCH HOLE
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
EXC. STRG WHL AUDIO CONTROL SW<8NE>
(B)
THA
|
8-98196-496-0 |
01 |
1 |
1310- |
|
● |
| |
104 |
SCREW; SWITCH AND BEZEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
STEERING WHEEL LEATHER<NP5>
M4X10 TAPPING
THA
|
0-71240-410-0 |
04 |
1 |
1310- |
● |
|
| |
104 |
SCREW; SWITCH AND BEZEL
AIR BAG DRIVER & PASSENGER<AK5>,AIR BAG DRIVER &
PASSENGER & SIDE & ROOF<AY0>
M4X10 TAPPING
THA
|
0-71240-410-0 |
04 |
1 |
1310- |
|
● |
