1 |
CABLE; SHIFT,TRANS CONT
FRONT STABILIZER SHAFT<F59>
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
L=2985
|
8-98133-215-2 |
01 |
1 |
1403- |
| |
1 |
CABLE; SHIFT,TRANS CONT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
L=2930
|
8-98041-379-4 |
01 |
1 |
1403- |
| |
1 |
CABLE; SHIFT,TRANS CONT
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
EXC. FRONT STABILIZER SHAFT<F59>
L=2970
|
8-98098-037-3 |
01 |
1 |
1403- |
| |
3 |
CABLE; SELECT,TRANS CONT
FRONT STABILIZER SHAFT<F59>
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
L=3110
|
8-98133-222-2 |
01 |
1 |
1403- |
| |
3 |
CABLE; SELECT,TRANS CONT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
L=3055
|
8-98041-384-4 |
01 |
1 |
1403- |
| |
3 |
CABLE; SELECT,TRANS CONT
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
EXC. FRONT STABILIZER SHAFT<F59>
L=3075
|
8-98098-038-3 |
01 |
1 |
1403- |
| |
6 |
CLIP; CABLE
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
ID=11 & 11 L=17.5 & 17.5
|
1-09700-739-0 |
01 |
1 |
1403- |
| |
199 |
WASHER; PL,SELECT
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
ID=8.4 OD=16
|
0-91614-508-0 |
01 |
1 |
1403- |
| |
221 |
NUT; SHIFT WIRE TO LEVER
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
M8 FLANGE
|
1-09440-062-1 |
01 |
1 |
1403- |
| |
225 |
PIN; SELECT CABLE
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
L=27.7
|
8-94111-137-0 |
01 |
1 |
1403- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(A)
ID=11X2 L=16
|
0-95325-026-0 |
01 |
1 |
1403- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(C)
ID=13 & 13 L=32
|
8-97389-264-0 |
01 |
1 |
1403- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(C)
ID=13 & 13 L=32
|
8-97389-264-0 |
02 |
1 |
1403- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(D)
|
8-98080-966-0 |
01 |
1 |
1403- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1403-1504 |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(B)
ID=13 & 10 & 10 L=43.5
|
8-98292-921-0 |
01 |
1 |
1505- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(A)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
1403- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(B)
M8X25 FLANGE
|
0-28650-825-0 |
02 |
1 |
1403- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
(B)
M8X25 FLANGE
|
0-28650-825-0 |
03 |
1 |
1403- |
| |
297 |
NUT; CLIP
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
GENERATOR 24V90A(K44)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1403- |
| |
297 |
NUT; CLIP
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1403- |
| |
474 |
BOLT; BRKT
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
M8X25 W/WASHER
|
0-51640-825-0 |
03 |
1 |
1403- |
| |
474 |
BOLT; BRKT
TRANSMISSION CONTROL-SMOOTHER(8GF)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
M8X25 W/WASHER
|
0-51640-825-0 |
02 |
1 |
1403- |
| |
487 |
BRACKET; CONT CABLE
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)
|
8-98183-009-0 |
01 |
1 |
1403- |
| |
487 |
BRACKET; CONT CABLE
TRANSMISSION CONTROL-SMOOTHER(8GF)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
|
8-98183-009-0 |
01 |
1 |
1403- |
