7-70 — SEPARATER AND BED (#128865) — 40 parça

51 44 92 51 44 64 92

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
44	CURTAIN ASM; CABIN CENTER HONG KONG EQUIPMENT(B14) (A) BLUE	8-97407-945-1	01	1	1310-
44	CURTAIN ASM; CABIN CENTER HONG KONG EQUIPMENT(B14) (B) BLUE	8-97407-946-1	01	1	1310-
51	CURTAIN; BACK HONG KONG EQUIPMENT(B14) (A) BLUE	8-97407-758-1	01	1	1310-
51	CURTAIN; BACK HONG KONG EQUIPMENT(B14) (B) BLUE	8-97407-759-1	01	1	1310-
64	CURTAIN KIT HONG KONG EQUIPMENT(B14)	8-97415-694-0	01	1	1310-
92	CURTAIN ASM; ROUND HONG KONG EQUIPMENT(B14) (A) BLUE	8-97415-696-0	01	1	1310-
92	CURTAIN ASM; ROUND HONG KONG EQUIPMENT(B14) (B) BLUE	8-97415-700-0	01	1	1310-

73 130 73 58 59 47 41 42 45 50 41 50 85 84 50 85 47 47 42 42 85 84 45 41 50 47 41 42 48 84 50 45 84 47 50 50

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
41	HOOK; CURTAIN RAIL HONG KONG EQUIPMENT(B14) H=14.5 WHITE	1-73996-398-0	12	1	1310-
41	HOOK; CURTAIN RAIL HONG KONG EQUIPMENT(B14) ROUND CURTAIN RAIL<EDH> H=14.5 WHITE	1-73996-398-0	42	1	1310-
42	STOPPER; CURTAIN RAIL (B) DARK GRAY	8-97407-972-2	01	1	1310-
42	STOPPER; CURTAIN RAIL (B) DARK GRAY	8-97407-499-2	01	1	1310-
42	STOPPER; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> (A) LIGHT GRAY	8-97408-038-0	03	1	1310-
45	RAIL; CURTAIN,FRT HONG KONG EQUIPMENT(B14) (A) DARK GRAY	8-97407-487-1	01	1	1310-
45	RAIL; CURTAIN,FRT HONG KONG EQUIPMENT(B14) ROUND CURTAIN RAIL<EDH> (B) LIGHT GRAY	8-97415-678-0	01	1	1310-
45	RAIL; CURTAIN,FRT HONG KONG EQUIPMENT(B14) ROUND CURTAIN RAIL<EDH> (B) LIGHT GRAY	8-97415-677-0	01	1	1310-
45	RAIL; CURTAIN,FRT SINGAPORE EQUIPMENT(2G0) (A) DARK GRAY	8-97407-485-0	01	1	1310-
45	RAIL; CURTAIN,FRT SINGAPORE EQUIPMENT(2G0) ROUND CURTAIN RAIL<EDH> (B) LIGHT GRAY	8-97415-672-0	01	1	1310-
45	RAIL; CURTAIN,FRT SINGAPORE EQUIPMENT(2G0) ROUND CURTAIN RAIL<EDH> (B) LIGHT GRAY	8-97415-671-0	01	1	1310-
47	SCREW; CURTAIN RAIL M5X20	5-09981-059-0	06	1	1310-
47	SCREW; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	14	1	1310-
48	RAIL; CURTAIN,BACK HONG KONG EQUIPMENT(B14) ROUND CURTAIN RAIL<EDH> DARK GRAY	8-97407-490-2	01	1	1310-
48	RAIL; CURTAIN,BACK SINGAPORE EQUIPMENT(2G0) ROUND CURTAIN RAIL<EDH> DARK GRAY	8-97407-866-2	01	1	1310-
50	GROMMET; SCREW,CURTAIN RAIL EXC. ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	04	1	1406-
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1310-1405
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1310-1405
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1406-
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	14	1	1310-1405
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	20	1	1406-
58	BED; MAT MATTRESS SLEEPER CAB<E40> SEAT CLOTH<7FL> DARK GRAY	8-97407-382-2	01	1	1310-
58	BED; MAT VINYL SEAT<A83> MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97409-772-1	01	1	1310-
59	COVER ASM; TRIM,BED MAT MATTRESS SLEEPER CAB<E40> SEAT CLOTH<7FL> DARK GRAY	8-97412-045-1	01	1	1310-
59	COVER ASM; TRIM,BED MAT VINYL SEAT<A83> MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97414-106-0	01	1	1310-
73	BOLT; GUARD PIPE MATTRESS SLEEPER CAB<E40> M8X20 FLANGE	0-28450-820-0	04	1	1310-
84	BRACKET; CURTAIN RAIL (A)	8-98028-326-1	02	1	1310-1405
84	BRACKET; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> (A)	8-98028-326-1	02	1	1406-
84	BRACKET; CURTAIN RAIL (B)	8-98042-152-0	04	1	1310-
85	SCREW; BRKT EXC. ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	04	1	1406-
85	SCREW; BRKT M5X20	5-09981-059-0	06	1	1310-1405
85	SCREW; BRKT ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	06	1	1406-
130	PIPE; GUARD,BED MATTRESS SLEEPER CAB<E40>	8-98014-968-0	01	1	1310-
