1 |
CABLE; SHIFT,TRANS CONT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
L=3020
|
8-98177-697-1 |
01 |
1 |
1310- |
| |
1 |
CABLE; SHIFT,TRANS CONT
GENERATOR 24V90A(K44)
L=3090
|
8-98177-669-1 |
01 |
1 |
1310- |
| |
3 |
CABLE; SELECT,TRANS CONT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
L=3105
|
8-98177-701-1 |
01 |
1 |
1310- |
| |
3 |
CABLE; SELECT,TRANS CONT
GENERATOR 24V90A(K44)
L=3215
|
8-98177-671-1 |
01 |
1 |
1310- |
| |
6 |
CLIP; CABLE
ID=11 & 11 L=17.5 & 17.5
|
1-09700-739-0 |
01 |
1 |
1310- |
| |
199 |
WASHER; PL,SELECT
ID=8.4 OD=16
|
0-91614-508-0 |
01 |
1 |
1310- |
| |
201 |
BOLT; BRKT
M8X25 FLANGE
|
0-28650-825-0 |
01 |
1 |
1310- |
| |
201 |
BOLT; BRKT
M8X16 W/LK&PL WASHER
|
1-09980-498-0 |
02 |
1 |
1310- |
| |
201 |
BOLT; BRKT
GENERATOR 24V90A(K44)
M8X25 FLANGE
|
0-28650-825-0 |
02 |
1 |
1310- |
| |
221 |
NUT; SHIFT WIRE TO LEVER
M8 FLANGE
|
1-09440-062-1 |
01 |
1 |
1310- |
| |
225 |
PIN; SELECT CABLE
L=27.7
|
8-94111-137-0 |
01 |
1 |
1310- |
| |
282 |
BRACKET; TRANS SIDE
GENERATOR 24V90A(K44)
(C)
|
8-98150-905-0 |
01 |
1 |
1310- |
| |
282 |
BRACKET; TRANS SIDE
GENERATOR 24V90A(K44)
(B)
|
8-98251-969-0 |
01 |
1 |
1310- |
| |
282 |
BRACKET; TRANS SIDE
(D)
|
8-98126-426-0 |
01 |
1 |
1310- |
| |
282 |
BRACKET; TRANS SIDE
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
(A)
|
8-98065-276-0 |
01 |
1 |
1310- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
GENERATOR 24V90A(K44)
(A)
ID=11X2 L=50
|
0-95325-085-0 |
01 |
1 |
1310- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(C)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1310-1504 |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(C)
ID=13 & 10 & 10 L=43.5
|
8-98292-921-0 |
01 |
1 |
1505- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(A)
ID=11X2 L=16
|
0-95325-026-0 |
01 |
1 |
1310- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(B)
ID=13 & 13 L=32
|
8-97389-264-0 |
01 |
1 |
1310- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
1310- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89)
M8X25 FLANGE
|
0-28650-825-0 |
02 |
1 |
1310- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
GENERATOR 24V90A(K44)
M8X25 FLANGE
|
0-28650-825-0 |
03 |
1 |
1310- |
| |
297 |
NUT; CLIP
GENERATOR 24V90A(K44)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1310- |
| |
297 |
NUT; CLIP
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1310- |
| |
474 |
BOLT; BRKT
M8X25 W/WASHER
|
0-51640-825-0 |
03 |
1 |
1310- |
| |
487 |
BRACKET; CONT CABLE
|
8-98183-009-0 |
01 |
1 |
1310- |
