Isuzu WW
▶
TRUCKS
▶
NLR
▶
51497 - NLR/NMR RHD EUROPE EURO5B+,6
▶
3 - Brakes, Brake System
▶
3-01 - FRONT WHEEL BRAKE
▶
3-01 — FRONT WHEEL BRAKE
(#126696) — 12 parça
Tümü
A - NMR5SE
B - NMR5SN
C - NMR5WE
66
72
66
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
66
05.815 BOLT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0) (B) M14X43
8-97168-638-1
06
1
1309-1310
●
66
05.815 BOLT; OIL SHIELD COVER
(B) M14X43
8-97168-638-1
06
1
1309-1310
●
66
05.815 BOLT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0) (B) M14X43
8-97168-638-1
06
1
1311-
●
●
66
05.815 BOLT; OIL SHIELD COVER
(B) M14X43
8-97168-638-1
06
1
1311-
●
66
05.815 BOLT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0) (A) M14X23.5
8-97359-814-0
02
1
1309-1310
●
66
05.815 BOLT; OIL SHIELD COVER
(A) M14X23.5
8-97359-814-0
02
1
1309-1310
●
66
05.815 BOLT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0) (A) M14X23.5
8-97359-814-0
02
1
1311-
●
●
66
05.815 BOLT; OIL SHIELD COVER
(A) M14X23.5
8-97359-814-0
02
1
1311-
●
72
05.815 NUT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0)
8-97359-815-0
06
1
1309-1310
●
72
05.815 NUT; OIL SHIELD COVER
8-97359-815-0
06
1
1309-1310
●
72
05.815 NUT; OIL SHIELD COVER
EXC. FRT INDEPENDENT SUSPENSION(FF0)
8-97359-815-0
06
1
1311-
●
●
72
05.815 NUT; OIL SHIELD COVER
8-97359-815-0
06
1
1311-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
