Isuzu WW
▶
TRUCKS
▶
NPS
▶
51500 - NPS(MALAYSIA)
▶
4 - Propeller Shaft, Axles, Steering, Suspension
▶
4-50 - FRONT SUSPENSION
▶
4-50 — FRONT SUSPENSION
(#125181) — 28 parça
201
193
192
175
185
201
103
65
68
65
62
17
65
185
201
183
183
173
168
171
197
197
192
53
193
185
2
197
188
191
17
18
65
14
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
2
SPRING ASM; LEAF,FRT
SEE FIG-NO 4-55 FOR COMPONENT. 5-LEAF
8-98090-401-0
01
1
1306-
2
SPRING ASM; LEAF,FRT
SEE FIG-NO 4-55 FOR COMPONENT. 5-LEAF
8-98090-402-0
01
1
1306-
14
NUT; S/ABS,UPR
M10 T=8 MAL
9-09640-020-0
02
1
1306-
17
BUSHING; RUBBER,S/ABS
TOKICO MAL
9-51631-603-0
04
1
1306-
18
WASHER; CENTERING,S/ABS
TOKICO MAL
8-94412-791-0
02
1
1306-
53
NUT; LWR LINK
M14 FLANGE
8-97360-124-0
02
1
1306-
62
ABSORBER ASM; SHOCK,FRT
8-97367-351-1
02
1
1306-
65
WASHER; S/ABS
(A) ID=21 OD=40
0-91614-620-0
02
1
1306-
65
WASHER; S/ABS
(B) ID=15
8-97360-056-0
02
1
1306-
65
WASHER; S/ABS
(C) OD=40 MAL
9-51631-614-0
04
1
1306-
68
BUSHING; S/ABS
TOKICO MAL
8-94382-149-0
02
1
1306-
103
NUT; S/ABS TO LWR LINK
M14 MAL
0-91110-514-0
02
1
1306-
168
BRACKET; S/ABS,FRT SUSP
8-98049-995-4
01
1
1306-
171
BOLT; S/ABS BRKT
M12X35 FLANGE
0-28651-235-0
04
1
1306-
173
NUT; S/ABS
M12
8-97360-126-0
03
1
1306-
175
SPACER; BRKT,S/ABS
8-94311-841-2
02
1
1306-
183
SHACKLE; FRT SUSP
MAL
8-94110-399-3
04
1
1306-
185
WASHER; LK,PIN
KD PREPARATORY PACK<6HF> ID=16.5
8-98011-489-0
06
1
1306-
188
RUBBER; CLAMP,U-BOLT,FRT SPR
8-98090-443-0
02
1
1306-
191
U-BOLT; FRT SPR
L=185 MAL
8-94461-227-4
02
1
1306-
191
U-BOLT; FRT SPR
L=275 MAL
8-94461-228-2
02
1
1306-
192
PIECE; DIST
(A)
8-94462-218-2
01
1
1306-
192
PIECE; DIST
(B)
8-98049-991-0
02
1
1306-
193
NUT; U BOLT
M14 FLANGE
8-97360-124-0
08
1
1306-
197
PIN; FRT SPR,FRT
KD PREPARATORY PACK<6HF> M16X122 MAL
8-98011-487-0
06
1
1306-
197
PIN; FRT SPR,FRT
EXC. KD PREPARATORY PACK<6HF> M16X122 FLANGE
8-97360-110-0
06
1
1306-
201
NUT; PIN LK
KD PREPARATORY PACK<6HF> M16
0-91110-516-0
06
1
1306-
201
NUT; PIN LK
EXC. KD PREPARATORY PACK<6HF> M16 FLANGE
8-97360-125-0
06
1
1306-
