2 |
BOLT; EYE,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
M14X30 EYE-BOLT
|
8-94455-144-0 |
01 |
1 |
1307- |
| |
2 |
BOLT; EYE,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
M10X25
|
8-98072-919-0 |
01 |
1 |
1307- |
| |
3 |
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
ID=14.2 OD=19.2
|
1-09630-085-0 |
02 |
1 |
1307-1312 |
| |
3 |
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
ID=14.2 OD=19.2
|
8-98251-345-0 |
02 |
1 |
1401- |
| |
3 |
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
|
9-09571-410-0 |
02 |
1 |
1307- |
| |
3 |
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
ID=10.2 OD=16.0
|
9-09571-410-0 |
02 |
1 |
1307- |
| |
40 |
BOLT; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(C)
M8X16 FLANGE
|
0-28050-816-0 |
03 |
1 |
1307- |
| |
40 |
BOLT; OIL PIPE
EXC. POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
1307- |
| |
40 |
BOLT; OIL PIPE
EXC. POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
M8X20 FLANGE
|
0-28050-820-0 |
03 |
1 |
1307- |
| |
48 |
CLIP; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(C)
|
1-09701-240-0 |
02 |
1 |
1307- |
| |
48 |
CLIP; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
ID=8 & 9 L=25
|
8-97603-522-0 |
01 |
1 |
1307- |
| |
48 |
CLIP; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
ID=8 & 9 L=25
|
8-97603-523-0 |
01 |
1 |
1307- |
| |
63 |
PIPE; OIL,TURBOCHARGER FEED
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
|
8-98095-875-0 |
01 |
1 |
1307- |
| |
63 |
PIPE; OIL,TURBOCHARGER FEED
EXC. POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
|
8-98076-311-0 |
01 |
1 |
1307-1509 |
| |
63 |
PIPE; OIL,TURBOCHARGER FEED
EXC. POWER TAKE OFF-FLYWHEEL<6SZ>
|
8-98204-176-1 |
01 |
1 |
1510- |
| |
68 |
BOLT; EYE,OIL PIPE,TURBOCHARGER SIDE
M10X26
|
8-98037-825-0 |
01 |
1 |
1307- |
| |
157 |
BRACKET; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(C)
|
8-98055-852-0 |
01 |
1 |
1307- |
| |
157 |
BRACKET; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
|
8-98077-632-2 |
01 |
1 |
1307- |
| |
157 |
BRACKET; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(D)
|
8-98077-634-0 |
01 |
1 |
1307- |
| |
157 |
BRACKET; OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
|
8-98080-218-1 |
01 |
1 |
1307- |
| |
181 |
GASKET
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
04 |
1 |
1307- |
| |
233 |
BOLT; EYE
(A)
M10X22
|
1-09675-028-0 |
01 |
1 |
1307- |
| |
233 |
BOLT; EYE
(B)
M10X28
|
8-98037-823-0 |
01 |
1 |
1307- |
| |
262 |
NUT; CLIP,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
M6 FLANGE
|
0-91180-106-0 |
02 |
1 |
1307- |
| |
304 |
BOLT; BRKT,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(A)
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1307- |
| |
304 |
BOLT; BRKT,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(B)
M10X20 FLANGE
|
0-28751-020-0 |
03 |
1 |
1307- |
| |
304 |
BOLT; BRKT,OIL PIPE
POWER TAKE OFF-FLYWHEEL<6SZ>
(C)
M10X25 FLANGE
|
0-28751-025-0 |
01 |
1 |
1307- |
| |
501 |
PIPE; OIL,PTO FEED
POWER TAKE OFF-FLYWHEEL<6SZ>
|
8-98055-846-0 |
01 |
1 |
1307- |
