Isuzu WW
▶
TRUCKS
▶
FRR
▶
11548 - FRR AUST/NZ EURO5 EXC.SPACECAB
▶
3 - Brakes, Brake System
▶
3-11 - PARKING BRAKE CONTROL
▶
3-11 — PARKING BRAKE CONTROL
(#123686) — 10 parça
Tümü
A - FCR5MS
B - FCR5WS
C - FCD5MS
97
236
235
336
228
228
336
336
228
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
97
GROMMET; PARKING BRK CABLE
8-98029-219-1
01
1
1307-1312
●
●
97
GROMMET; PARKING BRK CABLE
8-98029-219-1
01
1
1401-
●
●
●
228
BOLT; CLIP RAD MTG
4HK1-TCS ENG(RJS) ASSISTOR SHIFT CONTROL<WX8> (B) M8X16 W/LK&PL WASHER
1-09980-498-0
02
1
1307-
●
228
BOLT; CLIP RAD MTG
4HK1-TCS ENG(RJS) MZW6P M/T(RSZ) GENERATOR 24V90A(K44) ASSISTOR SHIFT CONTROL<WX8> TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) (A) M8X25 FLANGE
0-28650-825-0
02
1
1307-
●
235
BRACKET; CONT CABLE TO FRAME
4HK1-TCS ENG(RJS) ASSISTOR SHIFT CONTROL<WX8>
8-98126-426-0
01
1
1307-
●
236
BOLT; BRKT TO FRAME
4HK1-TCS ENG(RJS) ASSISTOR SHIFT CONTROL<WX8> M8X25 FLANGE
0-28650-825-0
01
1
1307-
●
336
BRACKET; RADIATOR
4HK1-TCS ENG(RJS) MZW6P M/T(RSZ) GENERATOR 24V60A(KG2),GENERATOR 24V50A(K89) ASSISTOR SHIFT CONTROL<WX8> TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) (C)
8-98065-276-0
01
1
1307-
●
336
BRACKET; RADIATOR
4HK1-TCS ENG(RJS) MZW6P M/T(RSZ) GENERATOR 24V90A(K44) ASSISTOR SHIFT CONTROL<WX8> TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) (A)
8-98080-965-0
01
1
1307-1309
●
336
BRACKET; RADIATOR
4HK1-TCS ENG(RJS) MZW6P M/T(RSZ) GENERATOR 24V90A(K44) ASSISTOR SHIFT CONTROL<WX8> TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) (A)
8-98251-969-0
01
1
1310-
●
336
BRACKET; RADIATOR
4HK1-TCS ENG(RJS) MZW6P M/T(RSZ) GENERATOR 24V90A(K44) ASSISTOR SHIFT CONTROL<WX8> TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) (B)
8-98139-517-0
01
1
1307-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
