29 |
HOSE; FUEL
(C)
L=60
|
8-98009-718-0 |
01 |
1 |
1304- |
| |
29 |
HOSE; FUEL
(A)
|
8-98078-196-2 |
01 |
1 |
1304-1306 |
| |
29 |
HOSE; FUEL
(A)
THA
|
8-97948-223-0 |
01 |
1 |
1307- |
| |
29 |
HOSE; FUEL
(B)
|
8-98078-197-1 |
01 |
1 |
1304-1306 |
| |
29 |
HOSE; FUEL
(B)
THA
|
8-97948-224-0 |
01 |
1 |
1307- |
| |
39 |
PIPE; FUEL
(B)
OD=10 & OD=8 L=60
THA
|
8-97924-060-0 |
01 |
1 |
1304- |
| |
39 |
PIPE; FUEL
POOR QUALITY DIESEL FUEL<KF0>
(A)
NPTF3/8-18 OD=10
|
8-98122-953-0 |
02 |
1 |
1304-1306 |
| |
39 |
PIPE; FUEL
POOR QUALITY DIESEL FUEL<KF0>
(A)
NPTF3/8-18 OD=10
THA
|
8-97948-254-0 |
02 |
1 |
1307- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(D)
ID=16
|
8-94238-568-0 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
POOR QUALITY DIESEL FUEL<KF0>
(C)
ID=14
|
1-09704-102-0 |
08 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
POOR QUALITY DIESEL FUEL<KF0>
(F)
L=250
|
5-09707-030-1 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
EXC. POOR QUALITY DIESEL FUEL<KF0>
(C)
ID=14
|
1-09704-102-0 |
06 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
EXC. POOR QUALITY DIESEL FUEL<KF0>
(F)
L=250
|
5-09707-030-1 |
01 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG<82L>
(E)
ID=13
|
8-94238-571-0 |
06 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG<82L>
POOR QUALITY DIESEL FUEL<KF0>
(G)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
03 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
(A)
ID=9 & 9 L=17 & 17
|
1-09700-651-0 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
(E)
ID=13
|
8-94238-571-0 |
08 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
POOR QUALITY DIESEL FUEL<KF0>
(H)
ID=15 H=24 L=20
|
1-09700-606-0 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
POOR QUALITY DIESEL FUEL<KF0>
(G)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG<82L>
EXC. POOR QUALITY DIESEL FUEL<KF0>
(G)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
EXC. POOR QUALITY DIESEL FUEL<KF0>
(H)
ID=15 H=24 L=20
|
1-09700-606-0 |
01 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG<82L>
POOR QUALITY DIESEL FUEL<KF0>
(H)
ID=15 H=24 L=20
|
1-09700-606-0 |
01 |
1 |
1304- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG<80L>
EXC. POOR QUALITY DIESEL FUEL<KF0>
(G)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1304- |
| |
47 |
PIPE; FUEL,RETURN
(A)
L=766
THA
|
8-98105-178-0 |
01 |
1 |
1304- |
| |
47 |
PIPE; FUEL,RETURN
6HK1-TCS ENG<80L>
(B)
|
8-98079-273-0 |
01 |
1 |
1304- |
| |
55 |
COVER; PIPE,FUEL TANK
POOR QUALITY DIESEL FUEL<KF0>
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
02 |
1 |
1304- |
| |
55 |
COVER; PIPE,FUEL TANK
EXC. POOR QUALITY DIESEL FUEL<KF0>
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1304- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
POOR QUALITY DIESEL FUEL<KF0>
L=1100
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1304- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
POOR QUALITY DIESEL FUEL<KF0>
L=2200
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1304- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
EXC. POOR QUALITY DIESEL FUEL<KF0>
L=1400
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1304- |
| |
66 |
HOSE; FUEL,RETURN PIPE
6HK1-TCS ENG<80L>
L=160
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1304- |
| |
80 |
BOLT; CLIP,FUEL TANK
M8X20 FLANGE
THA
|
0-28650-820-0 |
02 |
1 |
1304- |
| |
80 |
BOLT; CLIP,FUEL TANK
POOR QUALITY DIESEL FUEL<KF0>
M8X30 FLANGE
THA
|
0-28650-830-0 |
04 |
1 |
1304- |
| |
80 |
BOLT; CLIP,FUEL TANK
EXC. POOR QUALITY DIESEL FUEL<KF0>
M8X30 FLANGE
THA
|
0-28650-830-0 |
02 |
1 |
1304- |
| |
80 |
BOLT; CLIP,FUEL TANK
6HK1-TCS ENG<80L>
M8X16 FLANGE
THA
|
0-28050-816-0 |
02 |
1 |
1304- |
| |
83 |
NUT; CLIP,FUEL TANK
M8 FLANGE
THA
|
0-91180-108-0 |
03 |
1 |
1304- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCN ENG<82L>
EXC. POOR QUALITY DIESEL FUEL<KF0>
M8 FLANGE
THA
|
0-91180-108-0 |
02 |
1 |
1304- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCS ENG<80L>
POOR QUALITY DIESEL FUEL<KF0>
M8 FLANGE
THA
|
0-91180-108-0 |
06 |
1 |
1304- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCS ENG<80L>
EXC. POOR QUALITY DIESEL FUEL<KF0>
M8 FLANGE
THA
|
0-91180-108-0 |
04 |
1 |
1304- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCN ENG<82L>
POOR QUALITY DIESEL FUEL<KF0>
M8 FLANGE
THA
|
0-91180-108-0 |
04 |
1 |
1304- |
| |
95 |
BUSHING; PIPE,FUEL TANK
6HK1-TCS ENG<80L>
ID=28 OD=35 T=25
|
1-09332-011-1 |
02 |
1 |
1304- |
| |
97 |
BRACKET; CLIP
(A)
L=50
|
1-47475-299-2 |
01 |
1 |
1304- |
| |
97 |
BRACKET; CLIP
(B)
|
8-98053-654-0 |
01 |
1 |
1304- |
| |
97 |
BRACKET; CLIP
(C)
|
8-98076-024-0 |
01 |
1 |
1304- |
| |
98 |
BOLT; BRKT,FUEL PIPE
6HK1-TCS ENG<80L>
M8X30 FLANGE
THA
|
0-28650-830-0 |
02 |
1 |
1304- |
| |
103 |
NUT; BRKT
6HK1-TCS ENG<80L>
M8 FLANGE
THA
|
0-91180-108-0 |
02 |
1 |
1304- |
| |
174 |
PIPE; FUEL,FEED,FRT
THA
|
8-98105-179-0 |
01 |
1 |
1304- |
| |
303 |
BOLT; BRKT
M8X30 FLANGE
THA
|
0-28650-830-0 |
02 |
1 |
1304- |
| |
304 |
NUT; BRKT
(A)
M8 FLANGE
THA
|
0-91180-108-0 |
03 |
1 |
1304- |
| |
304 |
NUT; BRKT
POOR QUALITY DIESEL FUEL<KF0>
(B)
M10 FLANGE
THA
|
0-91180-210-0 |
02 |
1 |
1304- |
| |
308 |
BRACKET; FUEL PIPE
6HK1-TCS ENG<80L>
L=75
|
1-47478-323-0 |
02 |
1 |
1304- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCN ENG<82L>
L=1200
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1304- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCS ENG<80L>
L=1050
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1304- |
