1 |
CABLE; SHIFT,TRANS CONT
MZW6P M/T<RSZ>
L=3510
|
8-98017-469-3 |
01 |
1 |
1304-1308 |
| |
1 |
CABLE; SHIFT,TRANS CONT
MZW6P M/T<RSZ>
L=3510
THA
|
8-97948-242-0 |
01 |
1 |
1309- |
| |
1 |
CABLE; SHIFT,TRANS CONT
6HK1-TCN ENG<82L>
ZF9S1110 M/T<Y5E>
L=3535
THA
|
8-98047-801-4 |
01 |
1 |
1304- |
| |
1 |
CABLE; SHIFT,TRANS CONT
6HK1-TCS ENG<80L>
ZF9S1110 M/T<Y5E>
L=3600
THA
|
8-98017-474-5 |
01 |
1 |
1304- |
| |
3 |
CABLE; SELECT,TRANS CONT
MZW6P M/T<RSZ>
L=3690
|
8-98010-474-2 |
01 |
1 |
1304-1306 |
| |
3 |
CABLE; SELECT,TRANS CONT
MZW6P M/T<RSZ>
L=3690
THA
|
8-97948-243-0 |
01 |
1 |
1307- |
| |
3 |
CABLE; SELECT,TRANS CONT
6HK1-TCN ENG<82L>
ZF9S1110 M/T<Y5E>
L=3505
THA
|
8-98047-815-2 |
01 |
1 |
1304- |
| |
3 |
CABLE; SELECT,TRANS CONT
6HK1-TCS ENG<80L>
ZF9S1110 M/T<Y5E>
L=3560
|
8-98017-495-3 |
01 |
1 |
1304-1306 |
| |
3 |
CABLE; SELECT,TRANS CONT
6HK1-TCS ENG<80L>
ZF9S1110 M/T<Y5E>
L=3560
THA
|
8-97948-244-0 |
01 |
1 |
1307- |
| |
6 |
CLIP; CABLE
(A)
ID=11 & 11 L=17.5 & 17.5
|
1-09700-739-0 |
01 |
1 |
1304- |
| |
6 |
CLIP; CABLE
ZF9S1110 M/T<Y5E>
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1304- |
| |
199 |
WASHER; PL,SELECT
ID=8.4 OD=16
|
0-91614-508-0 |
01 |
1 |
1304- |
| |
201 |
BOLT; BRKT
M8X16 FLANGE
THA
|
0-28050-816-0 |
01 |
1 |
1304- |
| |
201 |
BOLT; BRKT
ZF9S1110 M/T<Y5E>
M8X16 FLANGE
THA
|
0-28050-816-0 |
01 |
1 |
1304- |
| |
201 |
BOLT; BRKT
M8X20 FLANGE
THA
|
0-28050-820-0 |
01 |
1 |
1304- |
| |
201 |
BOLT; BRKT
ZF9S1110 M/T<Y5E>
M12X35 FLANGE
|
0-28151-235-0 |
01 |
1 |
1304- |
| |
221 |
NUT; SHIFT WIRE TO LEVER
M8 FLANGE
|
1-09440-062-1 |
01 |
1 |
1304- |
| |
225 |
PIN; SELECT CABLE
L=27.7
|
8-94111-137-0 |
01 |
1 |
1304- |
| |
282 |
BRACKET; TRANS SIDE
(B)
|
1-82699-199-0 |
01 |
1 |
1304- |
| |
282 |
BRACKET; TRANS SIDE
6HK1-TCN ENG<82L>
(A)
|
8-98010-418-0 |
01 |
1 |
1304- |
| |
282 |
BRACKET; TRANS SIDE
6HK1-TCS ENG<80L>
(A)
|
8-98098-265-2 |
01 |
1 |
1304- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(A)
ID=11X2 L=16
|
0-95325-026-0 |
02 |
1 |
1304- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1304- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
(A)
M8X16 FLANGE
THA
|
0-28050-816-0 |
01 |
1 |
1304- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
(C)
M8X25 FLANGE
THA
|
0-28050-825-0 |
01 |
1 |
1304- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
(B)
M8X20 FLANGE
THA
|
0-28650-820-0 |
01 |
1 |
1304- |
| |
297 |
NUT; CLIP
M8 FLANGE
THA
|
0-91180-108-0 |
01 |
1 |
1304- |
| |
300 |
BOLT; CLIP
ZF9S1110 M/T<Y5E>
M8X20 FLANGE
THA
|
0-28650-820-0 |
01 |
1 |
1304- |
| |
316 |
BRACKET; CLIP
ZF9S1110 M/T<Y5E>
|
8-98086-439-0 |
01 |
1 |
1304- |
| |
474 |
BOLT; BRKT
M8X25 W/WASHER
|
0-51640-825-0 |
03 |
1 |
1304- |
| |
487 |
BRACKET; CONT CABLE
6HK1-TCN ENG<82L>
(B)
|
8-98183-009-0 |
01 |
1 |
1304- |
| |
487 |
BRACKET; CONT CABLE
6HK1-TCS ENG<80L>
(A)
|
8-98100-413-0 |
01 |
1 |
1304- |
