2 |
CASE; PINION,STARTER
ASM PART: A = 8-98222-018-1
|
8-98055-786-1 |
02 |
1 |
- |
| |
7 |
CLUTCH ASM; PINION,STARTER
ASM PART: A = 8-98222-018-1
|
8-98222-100-0 |
02 |
1 |
- |
| |
9 |
BEARING; GEAR SHAFT STARTER
(C) ASM PART: A = 8-98222-018-1
|
8-97025-673-0 |
02 |
1 |
- |
| |
9 |
BEARING; GEAR SHAFT STARTER
(A) ASM PART: A = 8-98222-018-1
|
8-97025-674-0 |
02 |
1 |
- |
| |
9 |
BEARING; GEAR SHAFT STARTER
(B) ASM PART: A = 8-98222-018-1
|
8-97025-676-0 |
02 |
1 |
- |
| |
10 |
SHAFT; GEAR STARTER
ASM PART: A = 8-98222-018-1
|
8-97179-772-0 |
02 |
1 |
- |
| |
16 |
ARMATURE; STARTER
ASM PART: A = 8-98222-018-1
|
8-97192-299-0 |
02 |
1 |
- |
| |
17 |
BEARING; ARMATURE,STARTER
(A), IMA
ASM PART: A = 8-98222-018-1
|
8-94228-436-0 |
02 |
1 |
- |
| |
17 |
BEARING; ARMATURE,STARTER
(B) ASM PART: A = 8-98222-018-1
|
8-97030-387-0 |
02 |
1 |
- |
| |
19 |
COIL; FIELD,STARTER
ASM PART: A = 8-98222-018-1
|
8-98055-295-0 |
02 |
1 |
- |
| |
20 |
BRUSH; (+),STARTER
ASM PART: A = 8-98222-018-1
|
8-98055-296-0 |
04 |
1 |
- |
| |
21 |
SPRING; BRUSH HOLDER STARTER
ASM PART: A = 8-98222-018-1
|
8-94152-972-0 |
08 |
1 |
- |
| |
22 |
HOLDER; BRUSH STARTER
ASM PART: A = 8-98222-018-1
|
8-98055-298-0 |
02 |
1 |
- |
| |
23 |
COVER; RR COVER STARTER
THA ASM PART: A = 8-98222-018-1
|
8-97227-901-0 |
01 |
1 |
- |
| |
23 |
COVER; RR COVER STARTER
IMA ASM PART: A = 8-98222-018-1
|
8-98246-185-0 |
01 |
1 |
- |
| |
27 |
BOLT; THROUGH,STARTER
ASM PART: A = 8-98222-018-1
|
8-97192-423-0 |
04 |
1 |
- |
| |
28 |
LEVER; SHIFT,STARTER
ASM PART: A = 8-98222-018-1
|
8-97179-776-0 |
02 |
1 |
- |
| |
31 |
SWITCH; ENGAGE STARTER
ASM PART: A = 8-98222-018-1
|
8-97161-789-0 |
02 |
1 |
- |
| |
32 |
COVER; RUBBER,STARTER
ASM PART: A = 8-98222-018-1
|
5-81129-069-0 |
02 |
1 |
- |
| |
38 |
GASKET; RR COVER,STARTER
ASM PART: A = 8-98222-018-1
|
8-97115-763-0 |
02 |
1 |
- |
| |
41 |
SCREW; RR COVER,STARTER
ASM PART: A = 8-98222-018-1
|
8-97117-107-0 |
04 |
1 |
- |
| |
45 |
RETAINER; BEARING,STARTER
(A) ASM PART: A = 8-98222-018-1
|
8-94435-567-0 |
02 |
1 |
- |
| |
45 |
RETAINER; BEARING,STARTER
(B) ASM PART: A = 8-98222-018-1
|
8-97179-774-0 |
02 |
1 |
- |
| |
50 |
BRUSH; (-),STARTER
ASM PART: A = 8-98222-018-1
|
8-98055-297-0 |
04 |
1 |
- |
| |
54 |
CLUTCH; PINION,STARTER
ASM PART: A = 8-98222-018-1
|
8-98222-101-0 |
02 |
1 |
- |
| |
73 |
STOPPER SET; PINION
ASM PART: A = 8-98222-018-1
|
8-97030-396-0 |
02 |
1 |
- |
| |
85 |
BOLT; ENGAGE SW FIX,STARTER
THA ASM PART: A = 8-98222-018-1
|
8-94408-500-0 |
04 |
1 |
- |
