Isuzu WW
▶
TRUCKS
▶
NPR
▶
51492 - NPR BUS CHAS(THAI)
▶
8 - Chassis Electrical, Heating / Air Conditioning, Wipers, Radio
▶
8-01 - LAMP; FRONT AND FRONT SIDE
▶
8-01 — LAMP; FRONT AND FRONT SIDE
(#119442) — 30 parça
◀
[801A] COMPONENT;FRT TURN SIGNAL AND HEADLAMP (21 parça)
[801A] FIXING;FRONT LAMP (9 parça)
▶
4
408
420
20
5
5
382
457
23
1
331
431
357
399
355
432
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
LAMP ASM; HEAD
8-98225-640-0
01
1
1304-1305
1
LAMP ASM; HEAD
8-98241-325-0
01
1
1306-
1
LAMP ASM; HEAD
8-98225-641-0
01
1
1304-1305
1
LAMP ASM; HEAD
8-98241-326-0
01
1
1306-
4
HEADLAMP UNIT
8-98226-182-0
01
1
1304-
4
HEADLAMP UNIT
8-98226-183-0
01
1
1304-
5
BULB; HEADLAMP
(B) 24V 5W THA
1-82194-042-0
02
1
1304-
5
BULB; HEADLAMP
(A) 24V 75/70W THA
1-82194-063-0
02
1
1304-
20
SCREW; HEADLAMP
THA
8-97378-871-0
06
1
1304-
23
COVER; BULB,HEADLAMP
THA
8-97232-491-0
02
1
1304-
331
LAMP; TURN SIGNAL
8-98155-458-0
01
1
1304-
331
LAMP; TURN SIGNAL
8-98155-459-0
01
1
1304-
355
SCREW; TURN SIGNAL
THA
8-98051-428-0
04
1
1304-
357
BULB; TURN SIGNAL
24V 21W AMBER THA
8-97323-806-0
02
1
1304-
382
PLUG; SOCKET,HEADLAMP
THA
8-98225-685-0
02
1
1304-
399
SOCKET; TURN SIGNAL
THA
8-98051-387-0
02
1
1304-
408
CAP; BREATHER,HEADLAMP
THA
8-97378-874-0
02
1
1304-
420
SPRING; BULB,HEADLAMP
THA
8-98218-601-0
02
1
1304-
431
CAP; TURN SIGNAL,LAMP
THA
8-97378-874-0
02
1
1304-
432
FASTENER; TURN SIGNAL,LAMP
THA
8-98051-431-0
04
1
1304-
457
GRIP; HEADLAMP
THA
8-98241-354-0
02
1
1306-
331
355
28
28
427
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
LAMP ASM; HEAD
8-98225-640-0
01
1
1304-1305
1
LAMP ASM; HEAD
8-98241-325-0
01
1
1306-
1
LAMP ASM; HEAD
8-98225-641-0
01
1
1304-1305
1
LAMP ASM; HEAD
8-98241-326-0
01
1
1306-
28
BOLT; HEADLAMP
M6X23.5 W/LK&PL WASHER IMA
8-98164-723-0
08
1
1304-
331
LAMP; TURN SIGNAL
8-98155-458-0
01
1
1304-
331
LAMP; TURN SIGNAL
8-98155-459-0
01
1
1304-
355
SCREW; TURN SIGNAL
THA
8-98051-428-0
04
1
1304-
427
NUT; TURN SIGNAL LAMP
M6 FLANGE THA
0-91180-106-0
02
1
1304-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
