16 |
GEAR ASM; FRT PLANETARY,A/T
(A)
|
8-98189-682-0 |
01 |
1 |
1305- |
| |
16 |
GEAR ASM; FRT PLANETARY,A/T
(B)
|
8-98189-686-0 |
01 |
1 |
1305- |
| |
17 |
RACE; THRUST BRG,PLANETARY SHAFT,A/T
ID=38
|
8-98189-684-0 |
01 |
1 |
1305- |
| |
18 |
BEARING; THRUST,RR PLANETARY GEAR,A/T
(A)
|
8-98189-708-0 |
01 |
1 |
1305- |
| |
18 |
BEARING; THRUST,RR PLANETARY GEAR,A/T
(B)
|
8-98189-712-0 |
01 |
1 |
1305- |
| |
19 |
RACE; THRUST BRG,PLANETARY SHAFT,A/T
|
8-98189-692-0 |
01 |
1 |
1305- |
| |
20 |
RING; RET,PLANETARY GEAR,A/T
T=1.4
|
8-98189-691-0 |
01 |
1 |
1305- |
| |
21 |
GEAR; PLANETARY,INTERNAL FRT,A/T
|
8-98189-688-0 |
01 |
1 |
1305- |
| |
23 |
BEARING; THRUST,PLANETARY SHAFT,A/T
|
8-98189-695-0 |
01 |
1 |
1305- |
| |
26 |
RACE; ONEWAY CLU,A/T
|
8-98189-701-0 |
01 |
1 |
1305- |
| |
27 |
WASHER; THRUST,FRT PLANETARY,A/T
ID=64
|
8-98189-683-0 |
01 |
1 |
1305- |
| |
28 |
GEAR ASM; RR PLANETARY,A/T
4X2(TFB***)
4 WHEEL ANTI LOCK BRAKE<JE5>
|
8-98189-707-0 |
01 |
1 |
1305- |
| |
28 |
GEAR ASM; RR PLANETARY,A/T
4X2(TFB***)
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5>
|
8-98189-774-0 |
01 |
1 |
1305- |
| |
28 |
GEAR ASM; RR PLANETARY,A/T
4X4(TFS***)
4JK1-TCX ENG(LR0)
|
8-98189-784-0 |
01 |
1 |
1305- |
| |
30 |
RACE; THRUST BRG,RR PLANETARY FLANGE
|
8-98189-711-0 |
01 |
1 |
1305- |
| |
31 |
GEAR ASM; INTERNAL,PLANETARY,A/T
|
8-98189-694-0 |
01 |
1 |
1305- |
| |
33 |
RING; RET,PLANETARY GEAR,A/T
T=1.4
|
8-98189-710-0 |
01 |
1 |
1305- |
| |
34 |
BEARING; THRUST,FRT PLANETARY SHAFT,A/
|
8-98189-685-0 |
01 |
1 |
1305- |
| |
73 |
WASHER; THRUST,CARRIER
ID=74
|
8-98189-679-0 |
01 |
1 |
1305- |
| |
76 |
BEARING; THRUST,CARRIER
|
8-98189-673-0 |
01 |
1 |
1305- |
| |
124 |
RING; SLEEVE,OIL SEAL,RR PLANETARY GEA
4X2(TFB***)
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5>
ID=33
|
8-98189-775-0 |
02 |
1 |
1305- |
| |
125 |
SHAFT ASM; INTERMEDIATE,PLANETARY GEAR
|
8-98189-698-0 |
01 |
1 |
1305- |
| |
165 |
RING; RET
ID=151
|
8-98189-702-0 |
01 |
1 |
1305- |
| |
178 |
RING; RET
4X2(TFB***)
4JK1-TCX ENG(LR0)
ID=34
|
8-98189-730-0 |
01 |
1 |
1305- |
| |
189 |
RACE; INNER,LOW CLU
ID=23
|
8-98189-670-0 |
01 |
1 |
1305- |
| |
203 |
GEAR; SUN
Z=31
|
8-98189-699-0 |
01 |
1 |
1305- |
| |
217 |
RACE; THRUST BRG,INTERNAL GEAR
(A)
|
8-98189-696-0 |
01 |
1 |
1305- |
| |
217 |
RACE; THRUST BRG,INTERNAL GEAR
(B)
|
8-98189-697-0 |
01 |
1 |
1305- |
| |
218 |
BEARING; THRUST,INTERNAL GEAR
|
8-98189-680-0 |
01 |
1 |
1305- |
| |
223 |
RACE; BRG,CARRIER
|
8-98189-675-0 |
01 |
1 |
1305- |
| |
233 |
FLANGE; FR PLANETARY
|
8-98189-687-0 |
01 |
1 |
1305- |
| |
234 |
HUB; FORWARD CLUTCH
|
8-98189-674-0 |
01 |
1 |
1305- |
| |
235 |
HUB; REVERSE CLUTCH
|
8-98189-681-0 |
01 |
1 |
1305- |
| |
236 |
HUB; CLUTCH
|
8-98189-678-0 |
01 |
1 |
1305- |
| |
237 |
BEARING; THRUST
(A)
|
8-98189-676-0 |
01 |
1 |
1305- |
| |
237 |
BEARING; THRUST
(B)
|
8-98189-693-0 |
01 |
1 |
1305- |
| |
238 |
CLUTCH ASM; 1WAY
|
8-98189-700-0 |
01 |
1 |
1305- |
| |
239 |
RACE; INTERMEDIATE SHAFT
(A)
|
8-98189-703-0 |
01 |
1 |
1305- |
| |
239 |
RACE; INTERMEDIATE SHAFT
(B)
|
8-98189-704-0 |
01 |
1 |
1305- |
| |
240 |
BEARING; THRUST NEEDLE ROLLER
4X2(TFB***)
4JK1-TCX ENG(LR0)
(B)
|
8-98189-729-0 |
01 |
1 |
1305- |
| |
240 |
BEARING; THRUST NEEDLE ROLLER
(A)
|
8-98189-705-0 |
01 |
1 |
1305- |
| |
241 |
FLANGE; RR PLANETARY
|
8-98189-706-0 |
01 |
1 |
1305- |
| |
242 |
GEAR; RR PLANETARY
|
8-98189-709-0 |
01 |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=3.8
|
8-98189-716-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=3.9
|
8-98189-717-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.0
|
8-98189-718-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.1
|
8-98189-719-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.2
|
8-98189-720-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=3.85
|
8-98189-721-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=3.95
|
8-98189-722-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.05
|
8-98189-723-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.15
|
8-98189-724-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.25
|
8-98189-725-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.30
|
8-98189-726-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(A)
T=4.35
|
8-98189-727-0 |
AR |
1 |
1305- |
| |
243 |
RACE; THRUST BEARING
4X2(TFB***)
4JK1-TCX ENG(LR0)
(B)
T=2.0
|
8-98189-728-0 |
01 |
1 |
1305- |
| |
244 |
KEY; WOODRUF,PLANETARY GEAR
4X2(TFB***)
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5>
|
8-94479-904-0 |
01 |
1 |
1305- |
