Isuzu WW
▶
TRUCKS
▶
GXR
▶
11528 - GXR(RHD)EURO3
▶
2 - Clutch, Transmission, Trans Axle
▶
2-36 - MANUAL TRANSMISSION CONT LINK AND CABLE
▶
2-36 — MANUAL TRANSMISSION CONT LINK AND CABLE
(#118151) — 25 parça
◀
[236A] BRACKET AND CLIP (20 parça)
[236A] CABLE;TRANS CONT (5 parça)
▶
296
3
1
316
474
1
221
225
3
199
296
296
3
1
474
474
316
300
6
493
474
49
6
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98054-888-2
01
1
1304-1311
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98246-040-0
01
1
1312-1505
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98054-888-2
01
1
1506-
3
CABLE; SELECT,TRANS CONT
L=3105
8-98054-894-3
01
1
1304-
6
CLIP; CABLE
(A) ID=11 & 11 L=17.5 & 17.5
1-09700-739-0
01
1
1304-
6
CLIP; CABLE
(B) ID=10 & 10 M8
1-09701-220-0
01
1
1304-
49
WASHER; LK
ID=14.2
0-91510-614-0
01
1
1304-
199
WASHER; PL,SELECT
ID=8.4 OD=16
0-91614-508-0
01
1
1304-
221
NUT; SHIFT WIRE TO LEVER
M8 FLANGE
1-09440-062-1
01
1
1304-
225
PIN; SELECT CABLE
L=27.7
8-94111-137-0
01
1
1304-
296
BOLT; CLIP,SHIFT & SELECT
M8X20 FLANGE
0-28050-820-0
03
1
1304-
300
BOLT; CLIP
M8X20 FLANGE
0-28050-820-0
01
1
1304-
316
BRACKET; CLIP
(A)
8-98055-446-1
01
1
1304-
316
BRACKET; CLIP
(B)
8-98216-689-0
01
1
1304-1412
316
BRACKET; CLIP
(B)
8-98294-156-0
01
1
1501-
474
BOLT; BRKT
(A) M14X45
0-20801-445-0
01
1
1304-
474
BOLT; BRKT
(B) M8X20 FLANGE
0-28050-820-0
02
1
1304-
474
BOLT; BRKT
(C) M8X30 FLANGE
0-28050-830-0
01
1
1304-
474
BOLT; BRKT
(D) M8X25 W/WASHER
0-51640-825-0
01
1
1304-
493
SEAL; CABLE
OD=36 T=0.05 BLACK
5-76777-035-0
01
1
1304-
201
1
3
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98054-888-2
01
1
1304-1311
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98246-040-0
01
1
1312-1505
1
CABLE; SHIFT,TRANS CONT
L=3205
8-98054-888-2
01
1
1506-
3
CABLE; SELECT,TRANS CONT
L=3105
8-98054-894-3
01
1
1304-
201
BOLT; BRKT
M8X16 FLANGE
0-28050-816-0
01
1
1304-
