Isuzu WW
▶
PICKUP
▶
TFR
▶
51472 - TFR/TFS MIDDLE EAST
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-10 - CAUTION PLATE AND LABEL
▶
7-10 — CAUTION PLATE AND LABEL
(#117849) — 22 parça
Tümü
A - TFB6SF
B - TFB6WF
C - TFS6SF
D - TFS6WF
◀
[710A] NO.1 (12 parça)
[710A] NO.2 (10 parça)
▶
8
2
135
214
179
321
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
2
03.680 LABEL; FUEL CAUTION
REAR BODY DBL WALL CTR PULL(E63)
8-98147-133-0
01
1
1304-1510
●
●
2
03.680 LABEL; FUEL CAUTION
4JJ1-TCS ENG(LFB),4JK1-TCS ENG(LKZ) REAR BODY DBL WALL CTR PULL(E63)
8-98147-133-0
01
1
1304-1510
●
●
8
03.680 LABEL; FUSE
4JJ1-TCS ENG(LFB),4JK1-TCS ENG(LKZ) A/T 5 SPEED-AISIN(MA1),M/T MUA 5 SPEED 5H(MWQ) (A)
8-98166-842-3
01
1
1304-
●
●
●
●
8
03.680 LABEL; FUSE
4JA1-T ENG(LP0) M/T MSG 5 SPEED(M75),M/T MUA 5 SPEED 5G(RSP) (A)
8-98181-920-1
01
1
1304-
●
●
8
03.680 LABEL; FUSE
(B)
8-98213-358-0
01
1
1304-
●
●
8
03.680 LABEL; FUSE
4JJ1-TCS ENG(LFB),4JK1-TCS ENG(LKZ) (B)
8-98213-358-0
01
1
1304-
●
●
135
08.808 PLATE; CAUTION,ENGINE
4JJ1-TCS ENG(LFB)
8-98200-830-0
01
1
1304-
●
●
●
●
135
08.808 PLATE; CAUTION,ENGINE
4JK1-TCS ENG(LKZ)
8-98200-831-0
01
1
1304-
●
●
●
●
135
08.808 PLATE; CAUTION,ENGINE
4JA1-T ENG(LP0)
8-97332-377-1
01
1
1304-
●
●
179
08.808 PLATE; CAUTION,SERVICE
8-97356-568-0
01
1
1304-
●
●
●
●
214
08.808 LABEL; JACK
8-97943-121-0
01
1
1304-
●
●
●
●
321
08.808 LABEL; WARNING,POWER
ACCESSORY SOCKET FRT CONSOLE<KC5>
8-98183-494-1
01
1
1304-
●
●
●
●
8
16
88
109
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
8
03.680 LABEL; FUSE
4JJ1-TCS ENG(LFB),4JK1-TCS ENG(LKZ) A/T 5 SPEED-AISIN(MA1),M/T MUA 5 SPEED 5H(MWQ) (A)
8-98166-842-3
01
1
1304-
●
●
●
●
8
03.680 LABEL; FUSE
4JA1-T ENG(LP0) M/T MSG 5 SPEED(M75),M/T MUA 5 SPEED 5G(RSP) (A)
8-98181-920-1
01
1
1304-
●
●
8
03.680 LABEL; FUSE
(B)
8-98213-358-0
01
1
1304-
●
●
8
03.680 LABEL; FUSE
4JJ1-TCS ENG(LFB),4JK1-TCS ENG(LKZ) (B)
8-98213-358-0
01
1
1304-
●
●
16
08.808 PLATE; CAUTION,SIR
AIR BAG DRIVER & PASSENGER(AK5)
8-97378-569-0
01
1
1304-
●
●
●
●
88
08.808 LABEL; ANTI THEFT
REMOTE CONT DOOR LOCK W/ANTI THEFT<7KY>
8-98141-993-2
02
1
1304-
●
●
●
●
109
08.808 PLATE; CAUTION,TIRE PLACARD
FRT&RR 215/70R15C DUNLOP TIRE(CWP), FRT&RR 195R15C(QZO)
8-98100-752-1
01
1
1304-
●
109
08.808 PLATE; CAUTION,TIRE PLACARD
EXC. HIGH RIDE SUSPENSION(7YC)
8-98100-752-1
01
1
1304-
●
109
08.808 PLATE; CAUTION,TIRE PLACARD
HIGH RIDE SUSPENSION(7YC)
8-98102-346-1
01
1
1304-
●
109
08.808 PLATE; CAUTION,TIRE PLACARD
FRT&RR 205R16C(CUY),FRT&RR 245/70R16(QCQ),FRT&RR 255/65R17(QZX)
8-98102-346-1
01
1
1304-
●
●
