5 |
SEAL; OIL,BRG CASE,PTO
ENGINE REAR PTO<SV1>
|
8-97388-533-0 |
01 |
1 |
1302- |
| |
6 |
BEARING; FLYWHEEL PTO
ENGINE REAR PTO<SV1>
JTEKT
|
8-98171-254-0 |
02 |
1 |
1302- |
| |
6 |
BEARING; FLYWHEEL PTO
ENGINE REAR PTO<SV1>
NSK
|
9-00093-149-0 |
02 |
1 |
1302- |
| |
8 |
GEAR; FLYWHEEL PTO
ENGINE REAR PTO<SV1>
|
8-97603-907-0 |
01 |
1 |
1302- |
| |
11 |
SHAFT; PTO,FLYWHEEL
ENGINE REAR PTO<SV1>
|
8-97603-908-0 |
01 |
1 |
1302- |
| |
13 |
NUT; SHAFT,FLYWHEEL PTO
ENGINE REAR PTO<SV1>
M27 H=25
|
8-97360-410-0 |
01 |
1 |
1302- |
| |
14 |
SPACER; FLYWHEEL PTO
ENGINE REAR PTO<SV1>
T=19.20
|
9-38226-050-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.39
|
8-97382-615-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.44
|
8-97382-616-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.49
|
8-97382-617-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.54
|
8-97382-618-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.59
|
8-97382-619-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.64
|
8-97382-620-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.69
|
8-97382-621-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.74
|
8-97382-622-0 |
01 |
1 |
1302- |
| |
15 |
SHIM; PTO
ENGINE REAR PTO<SV1>
T=0.79
|
8-97382-623-0 |
01 |
1 |
1302- |
| |
16 |
THROWER; OIL,FLYWHEEL PTO
ENGINE REAR PTO<SV1>
(A)
|
8-97605-070-1 |
01 |
1 |
1302- |
| |
16 |
THROWER; OIL,FLYWHEEL PTO
ENGINE REAR PTO<SV1>
(B)
|
8-97605-071-0 |
01 |
1 |
1302- |
| |
17 |
FLANGE; PTO,FLYWHEEL
ENGINE REAR PTO<SV1>
|
1-38189-010-2 |
01 |
1 |
1302- |
| |
19 |
BOLT; FLANGE
ENGINE REAR PTO<SV1>
M12X40
|
0-20951-240-0 |
04 |
1 |
1302- |
| |
21 |
WASHER; LK,FLANGE
ENGINE REAR PTO<SV1>
ID=12.2
|
0-91510-812-0 |
04 |
1 |
1302- |
| |
22 |
NUT; FLANGE
ENGINE REAR PTO<SV1>
M12
|
0-91110-512-0 |
04 |
1 |
1302- |
| |
25 |
BEARING; IDLE DRIVEN GEAR,FLYWHEEL PTO
ENGINE REAR PTO<SV1>
|
1-09820-105-0 |
01 |
1 |
1302- |
| |
29 |
SPINDLE; IDLE GEAR,PTO
ENGINE REAR PTO<SV1>
|
1-12531-108-0 |
01 |
1 |
1302- |
| |
30 |
BOLT; SPINDLE
ENGINE REAR PTO<SV1>
|
9-09805-081-1 |
01 |
1 |
1302- |
| |
31 |
NUT; IDLE GEAR
ENGINE REAR PTO<SV1>
|
9-09843-063-0 |
01 |
1 |
1302- |
| |
52 |
CASE; BRG,PTO
ENGINE REAR PTO<SV1>
|
8-97603-906-1 |
01 |
1 |
1302- |
| |
53 |
COVER; PTO
ENGINE REAR PTO<SV1>
(A)
|
8-97603-909-1 |
01 |
1 |
1302- |
| |
53 |
COVER; PTO
ENGINE REAR PTO<SV1>
(B)
|
8-98002-481-1 |
01 |
1 |
1302- |
| |
57 |
GASKET; FLANGE,PTO,FLYWHEEL
ENGINE REAR PTO<SV1>
|
9-09920-533-0 |
01 |
1 |
1302- |
| |
59 |
GASKET; COVER
ENGINE REAR PTO<SV1>
(A)
|
1-09623-422-0 |
01 |
1 |
1302- |
| |
59 |
GASKET; COVER
ENGINE REAR PTO<SV1>
(B)
ID=62.6
|
1-09623-505-0 |
01 |
1 |
1302- |
| |
61 |
BOLT; COVER
ENGINE REAR PTO<SV1>
(A)
M8X20 FLANGE
THA
|
0-28650-820-0 |
04 |
1 |
1302- |
| |
61 |
BOLT; COVER
ENGINE REAR PTO<SV1>
(B)
M8X25 FLANGE
THA
|
0-28650-825-0 |
04 |
1 |
1302- |
| |
70 |
GEAR; IDLE DRIVEN,PTO
ENGINE REAR PTO<SV1>
|
8-97603-911-0 |
01 |
1 |
1302- |
| |
75 |
BOLT; COVER
ENGINE REAR PTO<SV1>
(A)
M10X90 FLANGE
|
0-28151-090-0 |
06 |
1 |
1302- |
| |
75 |
BOLT; COVER
ENGINE REAR PTO<SV1>
(B)
M10X150 FLANGE
|
0-28156-015-0 |
04 |
1 |
1302- |
| |
76 |
WASHER; LK,IDLE GEAR
ENGINE REAR PTO<SV1>
|
9-09854-034-0 |
01 |
1 |
1302- |
| |
101 |
GASKET; PTO
ENGINE REAR PTO<SV1>
|
8-97603-914-0 |
01 |
1 |
1302- |
| |
107 |
WASHER; PL,FLANGE
ENGINE REAR PTO<SV1>
ID=12.5 OD=22
|
0-91610-512-0 |
04 |
1 |
1302- |
