Isuzu WW
▶
TRUCKS
▶
FXZ
▶
11317 - FXZ(AUST)EURO5
▶
2 - Clutch, Transmission, Trans Axle
▶
2-41 - AUTO TRANS CASE,CONVERTER AND OIL PUMP
▶
2-41 — AUTO TRANS CASE,CONVERTER AND OIL PUMP
(#116090) — 19 parça
15
34
238
234
104
350
285
349
419
209
362
349
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
15
BREATHER; A/T CASE
8-98231-815-0
01
1
1303-
34
FLANGE; OIL PUMP,A/T
8-98223-648-0
01
1
1303-
104
BOLT; RET
1-09029-100-0
01
1
1303-
209
BOLT; HARNESS BRKT
VIN MODEL YEAR 2015<VZF>
8-98327-841-0
04
1
1504-
209
BOLT; HARNESS BRKT
M4X16
9-03494-416-0
04
1
1303-1503
209
BOLT; HARNESS BRKT
EXC. VIN MODEL YEAR 2015<VZF> M4X16
9-03494-416-0
04
1
1504-
234
PLATE; RETAINER
8-98231-813-0
01
1
1303-
238
GASKET; PLUG
8-98231-812-0
01
1
1303-
285
BRACKET; HARNESS
8-98231-811-0
01
1
1303-
349
HARNESS; SENSOR
VIN MODEL YEAR 2015<VZF>
8-98327-867-0
01
1
1504-
349
HARNESS; SENSOR
8-98231-810-0
01
1
1303-1503
349
HARNESS; SENSOR
EXC. VIN MODEL YEAR 2015<VZF>
8-98231-810-0
01
1
1504-
350
GASKET; BOLT,FLANGE
1-09623-674-0
01
1
1303-
362
CLIP; HARNESS
VIN MODEL YEAR 2015<VZF>
8-98327-835-0
01
1
1504-
362
CLIP; HARNESS
ID=9 L=30
1-34119-089-0
02
1
1303-1503
362
CLIP; HARNESS
EXC. VIN MODEL YEAR 2015<VZF> ID=9 L=30
1-34119-089-0
02
1
1504-
419
NUT; HARNESS BRKT
VIN MODEL YEAR 2015<VZF>
8-98327-834-0
04
1
1504-
419
NUT; HARNESS BRKT
M4 FLANGE
8-97368-853-0
04
1
1303-1503
419
NUT; HARNESS BRKT
EXC. VIN MODEL YEAR 2015<VZF> M4 FLANGE
8-97368-853-0
04
1
1504-
