◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FVR ▶ 10630 - FVR-RHD ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#1142) — 34 parça
çizim 27540
6 69
BalonParca AdiParca NoAdetTipApplied Date A B
6 PLATE; CAUTION,SPARE TIRE
CAUTIONS ARABIAN<WJ7> 		1-85883-114-0 01 1 9202- ● ●
6 PLATE; CAUTION,SPARE TIRE
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-53639-004-0 01 1 9202- ● ●
6 PLATE; CAUTION,SPARE TIRE
CAUTIONS FRENCH<WJ8> 		1-85883-108-0 01 1 9202- ● ●
69 PLATE; CAUTION,STARTER SW
CAUTIONS ARABIAN<WJ7> 		1-85887-537-0 01 1 9202- ● ●
69 PLATE; CAUTION,STARTER SW
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-85887-389-0 01 1 9202- ● ●
69 PLATE; CAUTION,STARTER SW
CAUTIONS FRENCH<WJ8> 		1-85887-535-0 01 1 9202- ● ●
çizim 92804
4 63 2
BalonParca AdiParca NoAdetTipApplied Date A B
2 LABEL; FUEL CAUTION
FUEL TANK 200L FMCSR<PK6> 		8-94414-353-0 01 1 9202- ● ●
4 LABEL; ENG MAINTENANCE
6SA1 STD ENG(06L) 		1-85886-670-0 01 1 9202-9412 ● ●
4 LABEL; ENG MAINTENANCE 1-85886-670-0 01 1 9501- ●
4 LABEL; ENG MAINTENANCE
6SA1 STD ENG(06L) EXC. ANTI NOISE EQUIPMENT VAR2<TAK> 		1-85886-670-0 01 1 9501- ●
4 LABEL; ENG MAINTENANCE
6SA1TC ENG(28L) 		1-85886-314-0 01 1 9202- ● ●
4 LABEL; ENG MAINTENANCE
6HE1 STD ENG(46L) 		8-94393-471-0 01 1 9202- ●
4 LABEL; ENG MAINTENANCE
6SA1 STD ENG(06L) ANTI NOISE EQUIPMENT VAR2<TAK> 		1-85886-795-0 01 1 9501- ●
63 PLATE; CAUTION,SEAT AIR
CAUTIONS ARABIAN<WJ7> SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> 		1-75537-202-0 01 1 9202- ● ●
63 PLATE; CAUTION,SEAT AIR
CAUTIONS FRENCH<WJ8> SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> 		1-75537-201-0 01 1 9202- ● ●
63 PLATE; CAUTION,SEAT AIR
SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-75537-199-0 01 1 9202- ● ●
çizim 95500
51 119 1 51 1 119 49
BalonParca AdiParca NoAdetTipApplied Date A B
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT6609 M/T(X8M) (A) 		1-85881-598-0 01 1 9202- ● ●
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT6609 M/T(X8M) (B) 		1-85881-599-0 01 1 9202- ● ●
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (B) 		1-85881-639-0 01 1 9209- ●
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (A) 		1-85881-640-0 01 1 9209- ●
49 PLATE; CAUTION,FUSE BOX 1-85887-685-1 01 1 9202-9301 ● ●
49 PLATE; CAUTION,FUSE BOX 1-85887-685-2 01 1 9302- ●
49 PLATE; CAUTION,FUSE BOX
EXC. POWER WINDOW<A30> 		1-85887-685-2 01 1 9302- ●
49 PLATE; CAUTION,FUSE BOX
POWER WINDOW<A30> HEAD LAMP RECTANGULAR W/FOG LAMP<TAN> 		1-85888-310-0 01 1 9308- ●
49 PLATE; CAUTION,FUSE BOX
POWER WINDOW<A30> EXC. HEAD LAMP RECTANGULAR W/FOG LAMP<TAN> 		1-85888-297-0 01 1 9302- ●
51 PLATE; CAUTION,WARNING
CAUTIONS ARABIAN<WJ7> (A) 		1-85880-581-0 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (B) 		1-85888-229-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (A) 		1-85880-576-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (B) 		1-85888-217-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
CAUTIONS FRENCH<WJ8> (A) 		1-85880-580-0 01 1 9202- ● ●
119 PLATE; CAUTION,HAND BRK LEVER
(B) 		1-85881-373-0 01 1 9202- ● ●
119 PLATE; CAUTION,HAND BRK LEVER
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3) (A) 		1-85881-667-0 01 1 9202-9208 ● ●
119 PLATE; CAUTION,HAND BRK LEVER
AUSTRALIA EQUIPMENT(RR3) (A) 		1-85881-667-0 01 1 9209- ●
119 PLATE; CAUTION,HAND BRK LEVER
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3) (A) 		1-85881-667-0 01 1 9209- ●
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
