24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1405-1405 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1405-1405 |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
EXC. SINGAPORE EQUIPMENT(2G0)
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1405-1405 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1406- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1406- |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
EXC. SINGAPORE EQUIPMENT(2G0)
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1406- |
| |
24 |
CLIP; FUEL HOSE
(B)
ID=15 H=24 L=20
|
1-09700-606-0 |
01 |
1 |
1302- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
1302-1404 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
02 |
1 |
1405- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
01 |
1 |
1302-1405 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
01 |
1 |
1406- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
04 |
1 |
1302-1405 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
04 |
1 |
1406-1412 |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
03 |
1 |
1501- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
03 |
1 |
1501- |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(D)
ID=16.5 & 10.5-14
|
8-98147-093-0 |
01 |
1 |
1302-1405 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
EURO4 SPECIFICATION<NT4>
(D)
ID=16.5 & 10.5-14
|
8-98147-093-0 |
01 |
1 |
1406- |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1302-1404 |
| |
24 |
CLIP; FUEL HOSE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1302-1404 |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1302-1404 |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1405- |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1405- |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
03 |
1 |
1302-1412 |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W)
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
05 |
1 |
1302- |
| |
24 |
CLIP; FUEL HOSE
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
08 |
1 |
1302- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(I)
L=750
|
8-98225-816-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
(I)
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
(I)
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W)
(I)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W)
(I)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=1250
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(I)
L=1250
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(I)
L=1250
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(I)
L=1250
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
|
8-98078-194-3 |
01 |
1 |
1302- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
|
8-98078-195-1 |
01 |
1 |
1302- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98208-726-0 |
01 |
1 |
1302-1307 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
ID=9.3
|
8-98239-029-0 |
01 |
1 |
1308- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(F)
|
8-98208-728-0 |
01 |
1 |
1302-1307 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(F)
ID=7.5
|
8-98239-030-0 |
01 |
1 |
1308- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(C)
|
8-98136-901-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EURO4 SPECIFICATION<NT4>
(C)
|
8-98136-901-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(D)
|
8-98147-183-0 |
01 |
1 |
1302-1405 |
| |
29 |
HOSE; FUEL
4HK1-TCS ENG(RJS)
EURO4 SPECIFICATION<NT4>
(D)
|
8-98147-183-0 |
01 |
1 |
1406- |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
(G)
|
8-98078-196-2 |
01 |
1 |
1302- |
| |
29 |
HOSE; FUEL
6HK1-TCN ENG(82L)
(H)
|
8-98078-197-1 |
01 |
1 |
1302- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(C)
ID=14
|
1-09704-102-0 |
06 |
1 |
1302- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(D)
ID=16
|
8-94238-568-0 |
02 |
1 |
1302- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=13
|
8-94238-571-0 |
06 |
1 |
1302- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
1302-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG(82L)
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
1302-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG(82L)
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. EURO4 SPECIFICATION<NT4>,HEAVY DUTY PACKAGE
TRUCK VAR3<Y48>
(E)
L=250
|
5-09707-030-1 |
05 |
1 |
1302- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
04 |
1 |
1302-1404 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
04 |
1 |
1302-1404 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
04 |
1 |
1405-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
04 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
04 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1302-1404 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1405-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1405-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1406- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(E)
L=250
|
5-09707-030-1 |
04 |
1 |
1302-1405 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCN ENG(82L)
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
02 |
1 |
1302- |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1900
|
8-98227-901-0 |
01 |
1 |
1302-1404 |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1619
|
8-98239-080-0 |
01 |
1 |
1405- |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1588
|
8-98208-975-0 |
01 |
1 |
1302-1405 |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
L=1588
|
8-98208-975-0 |
01 |
1 |
1302-1405 |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1588
|
8-98208-975-0 |
01 |
1 |
1406- |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2240
|
8-98220-907-0 |
01 |
1 |
1302-1405 |
| |
47 |
PIPE; FUEL,RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2240
|
8-98220-907-0 |
01 |
1 |
1406- |
| |
47 |
PIPE; FUEL,RETURN
6HK1-TCN ENG(82L)
L=413
|
8-98078-210-0 |
01 |
1 |
1302- |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=800
|
1-09361-018-0 |
01 |
1 |
1302-1405 |
| |
55 |
COVER; PIPE,FUEL TANK
6HK1-TCN ENG(82L)
L=800
|
1-09361-018-0 |
01 |
1 |
1302-1405 |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=800
|
1-09361-018-0 |
01 |
1 |
1406- |
| |
55 |
COVER; PIPE,FUEL TANK
6HK1-TCN ENG(82L)
L=800
|
1-09361-018-0 |
01 |
1 |
1406- |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. EURO4 SPECIFICATION<NT4>,HEAVY DUTY PACKAGE
TRUCK VAR3<Y48>
ID=27 L=500
|
8-98119-327-0 |
01 |
1 |
1302- |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=250
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1302- |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1302-1405 |
| |
55 |
COVER; PIPE,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
L=350
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1302-1405 |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X25 FLANGE
|
0-28650-825-0 |
01 |
1 |
1302-1404 |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1405-1405 |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1405-1405 |
| |
62 |
BOLT; CLIP FIX
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
EXC. SINGAPORE EQUIPMENT(2G0)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1405-1405 |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
62 |
BOLT; CLIP FIX
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
EXC. SINGAPORE EQUIPMENT(2G0)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
62 |
BOLT; CLIP FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302-1404 |
| |
62 |
BOLT; CLIP FIX
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302-1404 |
| |
62 |
BOLT; CLIP FIX
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1405- |
| |
64 |
NUT; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302-1405 |
| |
64 |
NUT; CLIP
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302-1405 |
| |
64 |
NUT; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1406- |
| |
64 |
NUT; CLIP
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1406- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1150
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1404 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1450
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1405- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1200
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1200
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2100
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2100
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1406- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
L=1100
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302-1405 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1700
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W)
EURO2 SPECIFICATION<NT2>
L=2600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1302- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
L=3300
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
1302- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
02 |
1 |
1302- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
03 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
03 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X50 FLANGE
|
0-28050-850-0 |
03 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
6HK1-TCN ENG(82L)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302-1404 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
6HK1-TCN ENG(82L)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1405-1405 |
| |
80 |
BOLT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1406- |
| |
80 |
BOLT; CLIP,FUEL TANK
6HK1-TCN ENG(82L)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1406- |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
1302- |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
1302-1405 |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
1302-1405 |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
1406- |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
06 |
1 |
1302-1405 |
| |
83 |
NUT; CLIP,FUEL TANK
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
M8 FLANGE
|
0-91180-108-0 |
06 |
1 |
1406- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCN ENG(82L)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302- |
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=17
|
9-09956-256-2 |
01 |
1 |
1302- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
L=50
|
1-47475-299-2 |
01 |
1 |
1302- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(C)
|
8-98078-201-0 |
01 |
1 |
1302- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(D)
|
8-98083-537-0 |
01 |
1 |
1302- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(G)
|
8-98117-691-0 |
03 |
1 |
1302-1404 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(G)
|
8-98117-691-0 |
02 |
1 |
1405- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(H)
|
8-98234-127-0 |
01 |
1 |
1302- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(G)
|
8-98117-691-0 |
01 |
1 |
1302-1405 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(G)
|
8-98117-691-0 |
01 |
1 |
1302-1405 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(G)
|
8-98117-691-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(F)
|
8-98100-216-1 |
01 |
1 |
1302-1404 |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
(F)
|
8-98100-216-1 |
01 |
1 |
1302-1404 |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(F)
|
8-98100-216-1 |
01 |
1 |
1405- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98109-768-0 |
01 |
1 |
1302-1404 |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
(E)
|
8-98109-768-0 |
01 |
1 |
1302-1404 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98109-768-0 |
01 |
1 |
1405-1405 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98109-768-0 |
01 |
1 |
1405-1405 |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
(E)
|
8-98109-768-0 |
01 |
1 |
1405-1405 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98109-768-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(E)
|
8-98109-768-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
(E)
|
8-98109-768-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
|
8-98083-349-0 |
01 |
1 |
1302-1405 |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
|
8-98083-349-0 |
01 |
1 |
1302-1405 |
| |
97 |
BRACKET; CLIP
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
|
8-98083-349-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
|
8-98083-349-0 |
01 |
1 |
1406- |
| |
97 |
BRACKET; CLIP
6HK1-TCN ENG(82L)
(I)
|
8-98077-896-0 |
01 |
1 |
1302- |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
|
8-98227-900-0 |
01 |
1 |
1302-1404 |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1488
|
8-98239-079-0 |
01 |
1 |
1405- |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1414
|
8-98208-965-0 |
01 |
1 |
1302-1405 |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
L=1414
|
8-98208-965-0 |
01 |
1 |
1302-1405 |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1414
|
8-98208-965-0 |
01 |
1 |
1406- |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2080
|
8-98220-906-0 |
01 |
1 |
1302-1405 |
| |
174 |
PIPE; FUEL,FEED,FRT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=2080
|
8-98220-906-0 |
01 |
1 |
1406- |
| |
174 |
PIPE; FUEL,FEED,FRT
6HK1-TCN ENG(82L)
|
8-98078-209-0 |
01 |
1 |
1302- |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
01 |
1 |
1302-1404 |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
01 |
1 |
1302-1404 |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
01 |
1 |
1405-1405 |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
01 |
1 |
1406- |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
02 |
1 |
1302- |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
03 |
1 |
1302-1404 |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
03 |
1 |
1405-1405 |
| |
217 |
COLLAR; FUEL PIPE FIX
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
ID=8
|
1-47459-011-0 |
03 |
1 |
1406- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1302-1405 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1302-1405 |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1302-1405 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8X25 FLANGE
|
0-28650-825-0 |
02 |
1 |
1302- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
03 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
02 |
1 |
1405- |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W),WHEEL BASE 4300MM(43W),
WHEELBASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1302-1404 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1405-1405 |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
6HK1-TCN ENG(82L)
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1406- |
| |
303 |
BOLT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W),WHEEL BASE 4300MM(43W),
WHEELBASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
(B)
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1302- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302-1405 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302-1405 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302-1405 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
(A)
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
TURBO - CONVENTIONAL<Q5T>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
(A)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
TURBO - CONVENTIONAL<Q5T>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1405- |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
(A)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
1405- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W),
WHEELBASE 5500MM(55W)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1302-1404 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1405-1405 |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1405-1405 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1405-1405 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1405-1405 |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
WHEEL BASE 5500MM(55W)
SINGAPORE EQUIPMENT(2G0)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1406- |
| |
304 |
NUT; BRKT
6HK1-TCN ENG(82L)
(B)
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1406- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
01 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
01 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
01 |
1 |
1405-1405 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
01 |
1 |
1406- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
01 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
01 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
01 |
1 |
1405-1405 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
01 |
1 |
1406- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
02 |
1 |
1302- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
02 |
1 |
1302- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
03 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
03 |
1 |
1405-1405 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(A)
ID=10 & 10
|
1-09709-241-0 |
03 |
1 |
1406- |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
03 |
1 |
1302-1404 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
03 |
1 |
1405-1405 |
| |
309 |
CLIP; PIPE
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W),WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
(B)
ID=10 & 10
|
1-09709-243-0 |
03 |
1 |
1406- |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=700
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302-1404 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=700
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302-1404 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=700
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1405-1405 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 3700MM(37W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=700
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1406- |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=800
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302-1404 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=800
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1405-1405 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4300MM(43W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=800
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1406- |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO2 SPECIFICATION<NT2>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1500
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302-1404 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1500
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1405-1405 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
FUEL TANK 200L FRAME SIDE<N20>
HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1500
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1406- |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
WHEEL BASE 4800MM(48W)
EURO4 SPECIFICATION<NT4>
|
8-98225-815-0 |
01 |
1 |
1302-1404 |
| |
634 |
HOSE; RUBBER RETURN
4HK1-TCS ENG(RJS)
EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48>
L=1000
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1405- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCN ENG(82L)
WHEEL BASE 3700MM(37W)
L=1200
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCN ENG(82L)
WHEEL BASE 4300MM(43W)
L=2000
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCN ENG(82L)
WHEEL BASE 4800MM(48W),WHEEL BASE 5500MM(55W)
L=2850
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1302- |
