1 |
CABLE; SHIFT,TRANS CONT
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
L=3515
|
8-98050-357-5 |
01 |
1 |
1302- |
| |
1 |
CABLE; SHIFT,TRANS CONT
MZW6P M/T(RSZ)
EXC. ASSISTOR SHIFT CONTROL<WX8>
L=3540
|
8-98050-356-6 |
01 |
1 |
1302- |
| |
3 |
CABLE; SELECT,TRANS CONT
MZW6P M/T(RSZ)
L=3720
|
8-98050-361-3 |
01 |
1 |
1302- |
| |
6 |
CLIP; CABLE
LCT2000 A/T ALLISON(Y4F)
(C)
ID=13 L=20
|
0-95235-236-0 |
01 |
1 |
1302- |
| |
6 |
CLIP; CABLE
MZW6P M/T(RSZ)
(A)
ID=11 & 11 L=17.5 & 17.5
|
1-09700-739-0 |
01 |
1 |
1302- |
| |
6 |
CLIP; CABLE
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1302- |
| |
199 |
WASHER; PL,SELECT
MZW6P M/T(RSZ)
ID=8.4 OD=16
|
0-91614-508-0 |
01 |
1 |
1302- |
| |
201 |
BOLT; BRKT
LCT2000 A/T ALLISON(Y4F)
M8X20 FLANGE
|
0-28050-820-0 |
01 |
1 |
1302- |
| |
201 |
BOLT; BRKT
MZW6P M/T(RSZ)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
1302- |
| |
201 |
BOLT; BRKT
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
1302- |
| |
201 |
BOLT; BRKT
MZW6P M/T(RSZ)
M8X20 FLANGE
|
0-28050-820-0 |
01 |
1 |
1302- |
| |
221 |
NUT; SHIFT WIRE TO LEVER
MZW6P M/T(RSZ)
M8 FLANGE
|
1-09440-062-1 |
01 |
1 |
1302- |
| |
225 |
PIN; SELECT CABLE
MZW6P M/T(RSZ)
L=27.7
|
8-94111-137-0 |
01 |
1 |
1302- |
| |
282 |
BRACKET; TRANS SIDE
MZW6P M/T(RSZ)
(A)
|
1-82699-199-0 |
01 |
1 |
1302- |
| |
282 |
BRACKET; TRANS SIDE
MZW6P M/T(RSZ)
(B)
|
8-98098-265-2 |
01 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
LCT2000 A/T ALLISON(Y4F)
(C)
ID=13 L=24
|
0-95235-245-0 |
02 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
LCT2000 A/T ALLISON(Y4F)
(D)
ID=13 L=28
|
0-95235-255-0 |
01 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
LCT2000 A/T ALLISON(Y4F)
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
MANUAL TRANSMISSION<X9C>
(A)
ID=11X2 L=16
|
0-95325-026-0 |
01 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
MANUAL TRANSMISSION<X9C>
(A)
ID=11X2 L=16
|
0-95325-026-0 |
01 |
1 |
1302- |
| |
291 |
CLIP; SHIFT TO SELECT,FRAME
MANUAL TRANSMISSION<X9C>
(B)
ID=13 & 10 & 10 L=35.5
|
8-98023-991-0 |
01 |
1 |
1302- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
(B)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
1302- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
MZW6P M/T(RSZ)
(A)
M8X20 FLANGE
|
0-28050-820-0 |
01 |
1 |
1302- |
| |
293 |
BOLT; CLIP,SHIFT TO SELECT
MZW6P M/T(RSZ)
(C)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302- |
| |
297 |
NUT; CLIP
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1302- |
| |
300 |
BOLT; CLIP
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1302- |
| |
316 |
BRACKET; CLIP
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
|
8-98073-017-1 |
01 |
1 |
1302- |
| |
474 |
BOLT; BRKT
LCT2000 A/T ALLISON(Y4F)
M8X25 W/WASHER
|
0-51640-825-0 |
02 |
1 |
1302- |
| |
474 |
BOLT; BRKT
MZW6P M/T(RSZ)
M8X25 W/WASHER
|
0-51640-825-0 |
03 |
1 |
1302- |
| |
487 |
BRACKET; CONT CABLE
|
8-98183-009-0 |
01 |
1 |
1302- |
