16 |
CLIP; FLEX HOSE
ID=10 & 12
|
1-09709-278-1 |
01 |
1 |
1302- |
| |
22 |
UNION; CLU PIPE
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
M12 3WAY
|
0-92138-706-0 |
01 |
1 |
1302- |
| |
28 |
CLIP; OIL PIPE
(B)
ID=6.35
|
1-09701-247-1 |
01 |
1 |
1302- |
| |
28 |
CLIP; OIL PIPE
(A)
ID=6.35 & 10.0
|
1-09709-274-1 |
03 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZW6P M/T(RSZ)
(B)
L=390
|
8-98080-980-0 |
01 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
(A)
L=660
|
1-09363-971-0 |
01 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZW6P M/T(RSZ)
EXC. ASSISTOR SHIFT CONTROL<WX8>
(C)
L=740
|
1-09363-674-0 |
01 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZZ6W M/T(RSA)
(B)
L=440
|
8-98072-346-0 |
01 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZZ6W M/T(RSA)
ASSISTOR SHIFT CONTROL<WX8>
(A)
L=720
|
1-09363-970-0 |
01 |
1 |
1302- |
| |
47 |
HOSE; FLEX,CLU CONT
MZZ6W M/T(RSA)
EXC. ASSISTOR SHIFT CONTROL<WX8>
(C)
L=720
|
1-09363-801-0 |
01 |
1 |
1302- |
| |
48 |
GASKET; FLEX HOSE,CLU CONT
ID=10.2 OD=16.0
|
9-09571-410-0 |
02 |
1 |
1302- |
| |
49 |
PIPE; AIR,FLEX HOSE TO CLU BOOSTER
MZZ6W M/T(RSA)
EXC. ASSISTOR SHIFT CONTROL<WX8>
L=207
|
1-49124-782-0 |
01 |
1 |
1302- |
| |
49 |
PIPE; AIR,FLEX HOSE TO CLU BOOSTER
MZW6P M/T(RSZ)
L=204
|
1-49117-400-0 |
01 |
1 |
1302- |
| |
50 |
NUT; UNION
(B)
M12
|
0-91111-512-0 |
01 |
1 |
1302- |
| |
50 |
NUT; UNION
MANUAL TRANSMISSION<X9C>
EXC. ASSISTOR SHIFT CONTROL<WX8>
(A)
M12
|
9-09840-280-0 |
01 |
1 |
1302- |
| |
50 |
NUT; UNION
MZW6P M/T(RSZ)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
(A)
M12
|
9-09840-280-0 |
01 |
1 |
1302- |
| |
50 |
NUT; UNION
(A)
M12
|
9-09840-280-0 |
01 |
1 |
1302- |
| |
51 |
WASHER; LK
MANUAL TRANSMISSION<X9C>
EXC. ASSISTOR SHIFT CONTROL<WX8>
ID=12.2
|
0-91510-512-0 |
01 |
1 |
1302- |
| |
51 |
WASHER; LK
MZW6P M/T(RSZ)
ASSISTOR SHIFT CONTROL<WX8>
ID=12.2
|
0-91510-812-0 |
01 |
1 |
1302- |
| |
102 |
NUT; FLEX HOSE,CLU CONT
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1302- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
(B)
L=336
|
8-98067-058-0 |
01 |
1 |
1302- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
MZW6P M/T(RSZ)
(A)
L=2039
|
8-98078-086-1 |
01 |
1 |
1302- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
MZZ6W M/T(RSA)
(A)
L=2683
|
8-98162-742-1 |
01 |
1 |
1302- |
| |
106 |
UNION; OIL PIPE
H.S.A SYSTEM<6EP>
(B)
M12 3WAY
|
8-98051-113-0 |
01 |
1 |
1302- |
| |
106 |
UNION; OIL PIPE
MZW6P M/T(RSZ)
(A)
M12 ELBOW
|
0-92125-206-0 |
01 |
1 |
1302- |
| |
106 |
UNION; OIL PIPE
4HK1-TCC ENG(RDV)
(C)
M12 2WAY
|
1-09654-059-2 |
01 |
1 |
1302- |
| |
107 |
NUT; UNION,OIL PIPE
MZW6P M/T(RSZ)
M12
|
9-09840-280-0 |
01 |
1 |
1302- |
| |
107 |
NUT; UNION,OIL PIPE
4HK1-TCC ENG(RDV)
M12
|
0-91111-512-0 |
01 |
1 |
1302- |
| |
167 |
BRACKET; UNION
MZW6P M/T(RSZ)
(A)
|
8-98078-147-0 |
01 |
1 |
1302- |
| |
167 |
BRACKET; UNION
MZZ6W M/T(RSA)
(B)
|
8-98086-811-1 |
01 |
1 |
1302- |
