7-10 — CAUTION PLATE AND LABEL (#10493) — 13 parça

çizim 137456

2 6 6 6 4

	Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
	2	LABEL; FUEL CAUTION	1-85889-068-0	02	1	0103-
	4	LABEL; ENG MAINTENANCE 6SD1 TC(32L) EURO2 SPECIFICATION(THN)	1-85886-841-0	01	1	0103-
	4	LABEL; ENG MAINTENANCE 6SD1 TC(32L) EXC. EURO2 SPECIFICATION(THN)	1-85886-788-0	01	1	0103-
	4	LABEL; ENG MAINTENANCE 6WA1 TC-C(55L)	1-85886-840-1	01	1	0103-
	6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER<SFB> CAUTIONS SPANISH<YN1> (B)	1-53639-005-0	01	1	0103-0708
	6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER<SFB> CAUTIONS SPANISH<YN1> (C)	8-98082-439-0	01	1	0709-
	6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER<SFB> EXC. CAUTIONS SPANISH<YN1> (A)	1-53639-004-0	01	1	0103-0708
	6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER<SFB> EXC. CAUTIONS SPANISH<YN1> (C)	8-98082-437-0	01	1	0709-

çizim 137468

181 228

	Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
	181	PLATE; CAUTION,AIR CLEANER	1-85886-796-1	01	1	0103-
	228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7>	1-85887-935-0	01	1	0103-1001

çizim 137470

49 49 150

	Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
	49	PLATE; CAUTION,FUSE BOX CAUTIONS SPANISH<YN1> (B)	1-85878-297-0	01	1	0103-
	49	PLATE; CAUTION,FUSE BOX EXC. CAUTIONS SPANISH<YN1> (A)	1-85878-298-1	01	1	0103-
	150	PLATE; CAUTION,INSTRUCTION ELECTRIC SWITCH BOX ENGINE ROOM<TEK>	1-85888-543-0	01	1	0103-
